9.1. Installation of the aquasuite software

9.1. Installation of the aquasuite software
9.1. Installation of the aquasuite software 9.1. Installation of the aquasuite software
For configuration and monitoring of the mps product series, the aquasuite soft-
ware is available for download from our website www.aqua-computer.de. You will
find the most up-to-date version in the support section of the website.
After downloading, install the aquasuite software. Depending on your selection
during the installation process, the aquasuite software may start automatically
upon restart or may be accessed through a symbol on your desktop or in the start
menu.

9.2. Basic operation

9.2. Basic operation 9.2. Basic operation 9.2. Basic operation
The program window is divided into two main areas. On the left side, a list of
"overview pages", data logger, device pages and the basic configuration page of
the software is displayed, the right side shows the details of the currently selected
list element. The list can be hidden or restored by clicking the arrow symbol in the
upper left corner.
List elements may be minimized or maximized for easier access by clicking the title
bar. The title bars may contain various symbols that will be explained in the follow-
ing chapter.
9.3. 9.3.

9.3. Symbols in the headlines

9.3. Symbols in the headlines Symbols in the headlines Symbols in the headlines
Click the plus symbol in the "Overview pages" headline to create a new
overview page.
Clicking the monitor symbol will toggle desktop mode for this overview
page. While desktop mode is active, the arrow in the symbol will have
an orange color.
Clicking the padlock symbol will unlock or lock this overview page for
editing.
Clicking the gear wheel symbol will access the basic configuration page
of the selected list element.
In order to save all settings into a device, click the disk symbol in the
headline.
This symbol indicates that communication with this device is not possible
at the moment. Check USB connection and power supply of the device if
necessary.
Clicking this symbol in the lower left corner of the aquasuite window will
display the news feed on aquasuite updates.
