Dahua HD Pinhole Network Camera Quick Start Guide
Please refer to the table 1-3 for more details about each component.
No.
Name
1
Lens
2
Back cover
3
Binding wire
4
Network port
5
Power input port
6
Bracket
7
Bracket adjusting screw
8
Front cover
1.2 Bidirectional Talk
Note:
This function is only supported by HD modular pinhole network camera.
1.2.1 Device-end to PC-end
Device Connection
Figure 1-8 Structure of device
Table 1-3 Description of components
Function
Receive the optical signal from the environment.
-
It is used to fix the cable.
Connect to standard Ethernet cable.
Power port, input DC 12V。
It is used to fix the camera.
It is used to adjust the camera angle.
-
5
