- Page 1 Panoramic Fisheye Network Camera Quick Start Guide ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.1...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury. - Page 3 Quick Start Guide occurring when using the device. If there is any uncertainty or controversy, we reserve the right of final explanation. ...
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings Electrical safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited Power Source requirement according to IEC60950-1. - Page 5 Quick Start Guide It is recommended connect the grounding hole to the ground to enhance the reliability of the device. Do not touch the image sensor directly (CMOS). Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. Device body can be cleaned with soft dry cloth, which can also be used to remove stubborn ...
-
Page 6: Table Of Contents
Quick Start Guide Table of Contents Foreword ................................II Important Safeguards and Warnings ......................IV 1 Introduction ..............................1 Cable ....................................... 1 Connecting Alarm Input/output ............................2 2 Network Configuration ..........................4 Initializing Device ..................................4 Modifying Device IP Address ..............................5 Logging in to Web Interface.............................. -
Page 7: Introduction
Quick Start Guide Introduction Cable Cable type might vary with different devices, and the actual product shall prevail. Please waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For detailed operation, see the FAQ manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1. -
Page 8: Connecting Alarm Input/Output
Quick Start Guide Port Name Description Ethernet Port Connects to network with network cable. Provides power to the device with PoE. PoE is available on select model. Audio input Connects to sound-pick-up device to receive audio signal. Audio output Connects to speaker to output audio signal. - Page 9 Quick Start Guide Figure 1-2 Alarm input Step 2 Connect alarm output device to the alarm output end of the I/O port. The alarm output is relay switch output, which can only connect to NO alarm devices. The ALARM_OUT port and the ALM_OUT_GND port with the same number constitute a switch for alarm output, see Figure 1-3.
-
Page 10: Network Configuration
Quick Start Guide Network Configuration Device initialization and IP setting can be finished with the "ConfigTool" or in web interface. For more information, see the WEB operation manual. Device initialization is available on select models, and it is required at first use and after device is ... -
Page 11: Modifying Device Ip Address
Quick Start Guide The Device initialization interface is displayed. Select the devices that need initialization, and then click initialize. Step 6 The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting interface Step 7 Set and confirm the password of the devices, and then enter a valid email address. Click Next. -
Page 12: Logging In To Web Interface
Quick Start Guide After clicking Search setting, please make sure the username and password are the same as what you set during initialization, otherwise there will be "wrong password" notice. Select the devices which IP addresses need to be modified, and then click Modify IP. Step 2 The Modify IP Address interface is displayed. - Page 13 Quick Start Guide Figure 2-4 Main interface...
-
Page 14: Installation
Quick Start Guide Installation Packing List The tools required for the installation including electric drill are not provided in the packing. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. -
Page 15: Installing Device
Quick Start Guide Installing Device 3.3.1 Installation Method Installation Type Covering Mode Find the gap on the camera body; align it with the “TOP” on the corresponding quick mounting board, rotate the camera body clockwise to complete installation. -
Page 16: Installing Sd Card (Optional)
Quick Start Guide 3.3.2 Installing SD Card (Optional) SD card slot is available on select models. Please disconnect the power from the device before installing the SD card. Press the reset button for 10 seconds to reset the device. ... - Page 17 Quick Start Guide Cable going through ceiling-mount...
- Page 18 Quick Start Guide...
-
Page 19: Installing Waterproof Connector
Quick Start Guide Cable going through wall-mount 3.3.4 Installing Waterproof Connector This part is only needed when a waterproof connector comes with the device and the device is used outdoors. - Page 20 Quick Start Guide...
- Page 21 Quick Start Guide...
