GE ImageQuant LAS 500 Site Preparation Manual page 7

Dimensions and weight
The following illustration shows the dimensions of the ImageQuant LAS 500 imager.
The ImageQuant LAS 500 imager weighs 15 kg.
Environmental requirements
ImageQuant LAS 500 is intended for indoor use only.
The installation site must compliy with the following specifications:
Parameter
Ambient temperature, operation
Relative humidity, operation
Ambient temperature, transportation/stor-
age
Ambient humidity, transportation/storage
ImageQuant LAS 500 Site Preparation Guide 29-1358-76 AA
300 mm
2 Site preparation overview
570 mm
280 mm
Specification
18°C to 28°C
Temperature fluctuation < 10°C per hour
15% to 70% RH, non-condensing
-25°C to 70°C
5% to 95% RH, non-condensing
7
