2 Site preparation overview
Space requirements
Prepare a clean working area on a stable laboratory bench. The bench must comply
with the specifications in the following table.
Parameter
Minimum bench area for operating
ImageQuant LAS 500
Free space required around the imager
Load capacity
Inclination of bench surface
Note:
6
WARNING
Access to power cord. Do not block access to the power cord. The
power cord must always be easy to disconnect.
There must be additional space on the bench to place samples on the tray.
Specification
60 x 60 cm
At least 20 cm free space in front of the
imager.
10 cm free space on all other sides.
490 N (50 kg) or higher
Horizontal ±2°
