Specifications

Specifications
Characteristic
RF Transmission Rate
Ethernet Throughput
Output Power
Receiver Sensitivity
Range
Radio Channels / Bandwidth
Manual Frequency Select
Connector Types
Status LEDs
Error Correction Technique
Adjacent Band Rejection
Regulator Type
Browser Management Tools
Power Consumption
Voltage
Temperature Range
Transmit Current Draw
Size
Weatherproofing
Certifications and
Compliance
XPress Wireless Ethernet Bridge User Guide
Specification/Description
1.536 Mb/s
935 kb/s
+21 dBm (125 mW), (4 W EIRP with 15 dBi antenna)
-97 dBm at 10 bit error rate
-4
Up to 1000 ft (300 m) indoor with 2.1 dBi dipole antennas
Up to 2 miles (3.2 km) outdoor line of sight with 2.1 dBi dipole antennas
Up to 15 miles (24 km) outdoor line of sight with high- gain antennas
12 channels (6 in international version) with 2.0833 MHz spacing and 1.75 MHz
occupied bandwidth
Channel selected with dip switch or via web browser interface
RF RPTNC female / Ethernet RJ-45 / Power Jack P5-2.1 mm center positive
Power, Ethernet Link, RF RX, RF TX, 4/Channel and 6/Link Quality
Sub-block error detection and retransmission
SAW receiver filter attenuates cellular interference
Switching regulator
QoS Statistics, Network Settings, Spectrum Analyzer and Firmware Upgrading
Transmit: 1.7 W Receive: 0.8 W
Power over Ethernet 9-48 VDC pins 4/5 positive and 7/8 ground
Radio/Enclosure: -40 C to 70 C; PoE Injector: -40 C to 85 C; Power Supply: 0 C to
40 C
175 mA @ 9 VDC; 140 mA @ 12 VDC; 35 mA @ 48 VDC
9.22" L x 3.60" W x 2.19" H; 320 grams
The XPress enclosure is IP65 rated and tested for weatherproof installation. The
PoE injector and power supply are not weatherproof and should be installed
indoors.
FCC Part 15; Industry Canada (IC); contains FCC ID: R4N-AW900MR and IC: 5305A-
AW900MR; UL 60950-1; CSA C22.2, No. 60950-1, E112790; RoHS
Specifications
7
