SPECIFICATIONS

CELLULAR CONNECTIVITY
5G NR
4G LTE-ADVANCED PRO
3G HSPA+
ANTENNA CONNECTORS
SIM SLOTS
SOFTWARE AND MANAGEMENT
SOFTWARE
REMOTE MANAGEMENT
LOCAL MANAGEMENT
PERFORMANCE
ETHERNET THROUGHPUT
CELLULAR THROUGHPUT
IPSEC VPN THROUGHPUT
VPN TUNNELS
CLIENT COUNT
PROCESSOR
APPLICATION PROCESSOR
MEMORY
ETHERNET
PORTS
WI-FI
RADIOS
ANTENNAS
SECURITY
MODES
SERIAL
PORTS
PHYSICAL
DIMENSIONS (L x W x H)
WEIGHT
STATUS LEDs
ENCLOSURE
POWER REQUIREMENTS
DC BARREL INPUT
POWER OVER ETHERNET
POWER CONSUMPTION
ENVIRONMENTAL
OPERATING TEMPERATURE
RELATIVE HUMIDITY
APPROVALS
CELLULAR
EMISSIONS / IMMUNITY
SAFETY
WARRANTY
PRODUCT WARRANTY
*Standard 3-year warranty upgradeable to 5 years with purchase of a Digi Remote Manager Premier 5-year subscription applicable to the product purchased only at the time of product purchase and with product
registration at that time in Digi Remote Manager.
DIGI EX40
Bands: not supported
Bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B46, B48,
B66, B71; CBRS, LAA
Bands: B1, B2, B3, B4, B5, B6, B8, B9, B19
(4) 50 Ω SMA (center pin: female)
(2) Mini-SIM (2FF); sof ware selectable, hardware switchable; SIM slot cover plate
Digi Accelerated Linux (DAL OS); secure, reliable, intelligent, customizable
Digi Remote Manager®; security, management, updates, alerts, scheduling and intelligence
Web Interface (HTTPS); Command Line Interface (SSH, serial port)
2.0 Gbps
1.0 Gbps
500 Mbps
10 tunnels
50 clients (typical)
ARM® Cortex®-A53, 1.8 GHz, quad-core, 64-bit
512 MB RAM, 512 MB flash
(2) RJ-45; 10/100/1000/2500 Mbps (auto-sensing)
Wi-Fi 6 / 802.11ax, enterprise-grade, dual-band simultaneous, 2x2 MIMO; 2.4 GHz: 802.11b/g/n/ax; 2.4 GHz and 5 GHz: 802.11a/n/ac/ax
Integrated 2x2 MIMO, 2.4 GHz (8 dBi gain) and 5 GHz (5 dBi gain)
Open, Enhanced Open, WPA, WPA2, WPA3; Personal, Enterprise
(4) Wi-Fi access points; (2) Wi-Fi clients; (50) Wi-Fi users (typical)
(1) RS-232 (RJ-45); Cisco straight-through pinout; for out-of-band management of network appliances and servers
158 mm x 158 mm x 35 mm (6.2 in x 6.2 in x 1.4 in)
600 g (21 oz)
(14) total for easy visual troubleshooting; Power, LAN, WAN, Wi-Fi 2.4/5, Online, Cellular Signal, Cellular Service, SIM 1/2
Hybrid (die-cast aluminum + ABS plastic); Kensington Security Slot
19 VDC / 2.5 A barrel connector, 2.5 mm pin, center-positive
Standards-based, IEEE 802.3at, PoE+ (25.5 W)
8 W (idle), 15 W (typical), 25 W (maximum)
0° C to 40° C (32° F to 104° F) with included commercial-rated power supply; -30° C to 60° C (-22° F to 140° F) with Power over Ethernet or
industrial-rated power supply
5% to 95% (non-condensing)
Visit www.digi.com/resources/certifications
CE; RED; FCC Part 15 Subpart B; CAN ICES-003
IEC62368-1, CB, EN62311
3-year*
for latest certifications
