Dalsa QuickCam User Manual page 71

69
Enabled
Pixel Number
Coefficient Value
(DN)
Apply
Save Camera Settings
Diagnostics Tab
Command
Temperature/Voltage
Test Pattern
Camera Settings
IP Information
Timeouts and Packets
Pixel Coefficients
Signal Frequency
Refresh Settings
Save/Restore Tab
Command
Save to
Camera
(User Settings)
Restore from
Camera
(Factory
Settings)
03-032-10187-04
choose the gain setting.
Enables or disables PRNU coefficients.
The pixel number to set.
Sets the PRNU coefficient for the pixel
specified in the Pixel Number field.
Applies the PRNU coefficient to the
image output.
Saves the current settings to the
camera's non-volatile memory.
Purpose
Displays the camera's last measured
temperature and voltage.
Selects the test pattern to view.
Displays the camera's current settings.
Displays the camera's IP information.
Displays timeout and packet
information.
Displays the pixel coefficients for the
coefficient set selected from the
dropdown list.
Displays the signal frequency for the
camera control signal selected from the
dropdown list.
Refreshes the Diagnostics tab and
displays the latest camera settings.
Purpose
Saves the current user settings to the camera's
non-volatile memory. On reboot, the camera
operates using the last saved user settings.
Returns the current camera operating
conditions to the last saved user settings.
Returns the current camera operating
conditions to the camera's factory settings.
QuickCam User's Manul
55
56
56
56
10
Reference
Page
Number
62
61
62
62
62
62
62
62
Reference
Page
Number
10
11
11
DALSA corp.
