"Full battery" icon is displayed in upper right corner.
The "Low battery" icon is displayed when the battery has 10% or less
remaining capacity left. In addition; a warning signal sounds every minute,
the LED flashing orange, and the dialog window "Battery low. Charge now."
appears.
The "Empty battery" icon is flashing when the battery has 5% or less
remaining capacity left. In addition; a warning signal sounds every second,
the LED flashing red, and the dialog window "Battery empty. Shutting
down." appears.
"Sound off" icon is displayed when the Sound off key is pressed, and when
the handset, with the in charger function "Sound off" enabled, is placed in
a charger.
"Microphone off" icon indicates a silenced microphone. It is displayed after
a long press on the Sound off key during a call.
The Volume 0 ("Silent") icon is displayed when the volume has been set to
"Silent".
"Loudspeaking" icon is displayed in the soft key bar during a call. Pressing
this icon will turn on the loudspeaker.
"Loudspeaking off" icon is displayed after the soft key for Loudspeaking
icon has been pressed. Pressing this icon will turn off the loudspeaker.
"Key lock" icon indicates a locked keypad.
"Locked entry" icon indicates that the contact cannot be edited or deleted
by the user.
"Phone lock" icon indicates a locked handset.
"Headset" icon indicates that a corded headset is connected to the
handset.
"Outgoing call" icon is added to all outgoing calls in the call list.
"Incoming call" icon is added to all answered calls in the call list.
"Missed call" icon is added to all missed calls in the call list.
"Missed call" icon is added in the status bar. This icon remains until the
"Call list" is opened.
"PDM/Device Manager communication" icon is visible when handset is
communicating with PDM/Device Manager via advanced charger.
