Summary of Contents for R&S RTO

Page 1 ® R&S Digital Oscilloscope User Manual (=@8K2) 1316.0827.02 ─ 06...
Page 2 R&S RTO-K3, CAN and LIN (1304.8534.02) ● ® R&S RTO-K4, FlexRay (1304.8540.02) ● ® R&S RTO-K301 Tek DPO7000 Emulation mode (3127.2981.02) ● ® R&S RTO-B1, MSO (1304.9901.03) ● ® R&S RTO-B4, OCXO (1304.8305.02) The firmware of the instrument makes use of several valuable open source software packages. For information, see the "Open Source Acknowledgement"...
Page 3 Basic Safety Instructions Always read through and comply with the following safety instructions! All plants and locations of the Rohde & Schwarz group of companies make every effort to keep the safety standards of our products up to date and to offer our customers the highest possible degree of safety. Our products and the auxiliary equipment they require are designed, built and tested in accordance with the safety standards that apply in each case.
Page 4 Basic Safety Instructions Tags and their meaning The following signal words are used in the product documentation in order to warn the reader about risks and dangers. indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Page 5 Basic Safety Instructions Electrical safety If the information on electrical safety is not observed either at all to the extent necessary, electric shock, fire and/or serious personal injury or death may occur. 1. Prior to switching on the product, always ensure that the nominal voltage setting on the product matches the nominal voltage of the AC supply network.
Page 6 Basic Safety Instructions 14. Use suitable overvoltage protection to ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the product. Otherwise, the person operating the product will be exposed to the danger of an electric shock. 15.
Page 7 Basic Safety Instructions Repair and service 1. The product may be opened only by authorized, specially trained personnel. Before any work is performed on the product or before the product is opened, it must be disconnected from the AC supply network.
Page 8 Informaciones elementales de seguridad 2. Handles on the products are designed exclusively to enable personnel to transport the product. It is therefore not permissible to use handles to fasten the product to or on transport equipment such as cranes, fork lifts, wagons, etc. The user is responsible for securely fastening the products to or on the means of transport or lifting.
Page 9 Informaciones elementales de seguridad Se parte del uso correcto del producto para los fines definidos si el producto es utilizado conforme a las indicaciones de la correspondiente documentación del producto y dentro del margen de rendimiento definido (ver hoja de datos, documentación, informaciones de seguridad que siguen). El uso del producto hace necesarios conocimientos técnicos y ciertos conocimientos del idioma inglés.
Page 10 Informaciones elementales de seguridad Palabras de señal y su significado En la documentación del producto se utilizan las siguientes palabras de señal con el fin de advertir contra riesgos y peligros. PELIGRO identifica un peligro inminente con riesgo elevado que provocará...
Page 11 Informaciones elementales de seguridad Seguridad eléctrica Si no se siguen (o se siguen de modo insuficiente) las indicaciones del fabricante en cuanto a seguridad eléctrica, pueden producirse choques eléctricos, incendios y/o lesiones graves con posible consecuencia de muerte. 1. Antes de la puesta en marcha del producto se deberá comprobar siempre que la tensión preseleccionada en el producto coincida con la de la red de alimentación eléctrica.
Page 12 Informaciones elementales de seguridad 12. Si un producto se instala en un lugar fijo, se deberá primero conectar el conductor de protección fijo con el conductor de protección del producto antes de hacer cualquier otra conexión. La instalación y la conexión deberán ser efectuadas por un electricista especializado. 13.
Page 13 Informaciones elementales de seguridad 5. Ciertos productos, como p. ej. las instalaciones de radiocomunicación RF, pueden a causa de su función natural, emitir una radiación electromagnética aumentada. Deben tomarse todas las medidas necesarias para la protección de las mujeres embarazadas. También las personas con marcapasos pueden correr peligro a causa de la radiación electromagnética.
Page 14 Informaciones elementales de seguridad 6. En caso de falta de estanqueidad de una celda, el líquido vertido no debe entrar en contacto con la piel ni los ojos. Si se produce contacto, lavar con agua abundante la zona afectada y avisar a un médico.
Page 15 Customer Information Regarding Product Disposal The German Electrical and Electronic Equipment (ElektroG) Act is an implementation of the following EC directives: • 2002/96/EC on waste electrical and electronic equipment (WEEE) and • 2002/95/EC on the restriction of the use of certain hazardous substances in e lectrical and electronic equipment (RoHS).
Page 16 Customer Support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer Support Centers. A team of highly qualified engineers provides telephone support and will work with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde &...
Page 17 Qualitätszertifikat Certified Quality System ISO 9001 Certificate of quality Certified Environmental System Certificat de qualité ISO 14001 Sehr geehrter Kunde, Dear Customer, Cher client, Sie haben sich für den Kauf eines You have decided to buy a Vous avez choisi d’acheter un pro- Rohde &...
Page 19: Table Of Contents
® Contents R&S Contents 1 Preface....................11 Documentation Overview...................11 Conventions Used in the Documentation..............12 1.2.1 Typographical Conventions...................12 1.2.2 Conventions for Procedure Descriptions...............12 2 Acquisition and Setup.................13 Basics...........................13 2.1.1 Vertical System......................13 2.1.2 Sampling and Acquisition....................15 2.1.3 Horizontal System......................19 2.1.4 Probes...........................20 Setting Up the Waveform...................24 2.2.1 Setting Up the Signal Input with Autoset...............24 2.2.2...
Page 20 ® Contents R&S 3.2.4 Setting Up a Trigger Sequence..................56 3.2.5 Qualifying the Trigger....................57 Reference for Triggers....................57 3.3.1 Events...........................58 3.3.2 Trigger Qualification......................77 3.3.3 Noise Reject........................79 3.3.4 Sequence........................80 3.3.5 Trigger Position......................83 3.3.6 Control...........................85 4 Display....................88 Display Customization....................88 4.1.1 Display Settings......................88 4.1.2 Adjusting the Display.....................89 4.1.3 Reference for Display Settings..................93 Zoom..........................101...
Page 21 ® Contents R&S 5.2.3 Reference for Automatic Measurements..............152 6 Mathematics..................181 +Mathematical Waveforms..................181 6.1.1 Displaying Math Waveforms..................181 6.1.2 Math Setup........................182 Mathematical Functions and Formulas..............185 6.2.1 Optimized Graphical Editor..................185 6.2.2 Advanced Expressions....................187 FFT Analysis......................192 6.3.1 Fundamentals of FFT Analysis...................192 6.3.2 Configuring FFT Waveforms..................196 6.3.3 FFT Configuration Settings..................198 7 Reference Waveforms...............208...
Page 22 ® Contents R&S 8.3.4 Mask Display.......................235 9 Search Functions................236 Search Conditions and Results................236 9.1.1 Search Conditions.......................236 9.1.2 Search Results......................236 Configuring and Performing Searches..............237 9.2.1 Configuring a Trigger Search..................237 9.2.2 Configuring a Frequency Marker Search..............238 9.2.3 Configuring the Search Results Presentation.............239 9.2.4 Clearing Search Results.....................241 9.2.5...
Page 23 10.6.1 The LIN Protocol......................296 10.6.2 Reference for LIN......................297 10.7 FlexRay (Option R&S RTO-K4)................307 10.7.1 Reference for FlexRay....................307 11 Mixed Signal Option (MSO, R&S RTO-B1)........320 11.1 About MSO.........................321 11.2 Analyzing Digital Signals..................324 11.2.1 Using Digital Probes....................324 11.2.2 Configuring Digital Channels and Parallel Buses............325 11.2.3...
Page 24 ® Contents R&S 12.2.4 File Selection Dialog....................355 12.3 Reference for PRINT Settings..................357 13 General Instrument Setup..............360 13.1 Setting Up the Instrument..................360 13.2 Reference for General Instrument Settings............360 13.2.1 Setup...........................360 13.2.2 Front Panel Setup.......................368 13.2.3 Self-alignment......................369 14 Software and Network Operation.............371 14.1 Operating System.....................371 14.1.1...
Page 25 Automatic Measurements...................522 16.2.10 Mathematics........................575 16.2.11 Reference Waveforms....................590 16.2.12 Mask Testing.......................597 16.2.13 Search Commands.....................611 16.2.14 Protocols........................643 16.2.15 Mixed Signal Option (MSO, R&S RTO-B1)..............738 16.2.16 Data Management.......................753 16.2.17 General Instrument Setup...................767 16.2.18 Maintenance........................771 16.2.19 Status Reporting......................771 A Menu Overview...................776 File Menu........................776 Horizontal Menu......................777 Trigger Menu......................777...
Page 26 ® Contents R&S Meas Menu.........................779 Masks Menu.......................779 Search Menu......................779 A.10 Protocol Menu......................780 A.11 Display Menu......................780 List of Commands................782 Index....................804 User Manual 1316.0827.02 ─ 06...
Page 27: Preface
® Preface R&S Documentation Overview 1 Preface 1.1 Documentation Overview The user documentation delivered with the R&S RTO consists of the following parts: ● Online Help system on the instrument ● "Getting Started" printed manual in English ● Documentation CD-ROM with: –...
Page 28: Conventions Used In The Documentation
® Preface R&S Conventions Used in the Documentation The current online help is part of the instrument firmware, and it is installed together with the firmware. Updates are also available in the "Downloads > Firmware" section on the Rohde & Schwarz "Scope of the Art" Web page. 1.2 Conventions Used in the Documentation 1.2.1 Typographical Conventions The following text markers are used throughout this documentation:...
Page 29: Acquisition And Setup
® Acquisition and Setup R&S Basics 2 Acquisition and Setup This chapter describes the horizontal and vertical settings as well as the acquisition and probe setup. 2.1 Basics This chapter provides background information on the essential settings in the vertical and horizontal systems, on acquisition setup and probing.
Page 30 Basics Fig. 2-1: Input range and resolution of the ADC With R&S RTO, you can work with multiple diagrams, and each diagram obtains the full vertical resolution, no matter where the diagram is placed. Therefore, use a separate diagram for each waveform instead of the traditional setup that arranges the waveforms side by side in one diagram.
Page 31: Sampling And Acquisition
® Acquisition and Setup R&S Basics Fig. 2-3: R&S RTO setup of multiple waveforms in separate diagrams: best resolution 2.1.1.3 Bandwidth For analog applications the highest signal frequency determines the required oscillo- scope bandwidth. The oscilloscope bandwidth should be slightly higher than the maxi- mum frequency included in the analog test signal to measure the amplitude with very little measurement error.
Page 32 - either channel 1 or channel 2, and either channel 3 or 4. Using a channel on R&S RTO oscilloscopes is more than displaying it. In the background, without displaying the channel, it can serve as trigger source, as source of a math wave- form, cursor or automatic measurement.
Page 33 The R&S RTO provides the following acquisition features: ● You can combine resolution enhancement and waveform decimation modes with waveform arithmetic.
Page 34 Acquisition and Setup R&S Basics 2.1.2.3 Acquisition Control You can run the R&S RTO in two ways: ● Continuous: the instrument acquires data until you stop it manually. ● NxSingle: the instrument samples and processes a specified number of acquisitions.
Page 35: Horizontal System
® Acquisition and Setup R&S Basics 2.1.3 Horizontal System 2.1.3.1 Parameters of the Horizontal System The control parameters of the horizontal system are tightly connected. Thus, changing one parameter affects the other parameters as well. The mathematical dependencies can be summarized as follows: The time scale can be changed, all other parameters are adjusted automatically.
Page 36: Probes
® Acquisition and Setup R&S Basics Two parameters set the position of the horizontal acquisition window in relation to the trigger point: reference point (time reference) and trigger offset. With these parameters you choose the part of the waveform you want to see: around the trigger, before, or after the trigger.
Page 37 50 Ω Active, differential 10:1 Floating For a list of recommended probes refer to the R&S RTO product brochure. Besides the possible input voltage range, two factors are very important when selecting a voltage probe: Bandwidth and impedance over frequency. ●...
Page 38 When you connect an R&S RT-ZSxx active probe to a channel input of the R&S RTO, the oscilloscope recognizes the probe, reads the identification and calibration data from the probe box and shows the result in the "Setup"...
Page 39 ® Acquisition and Setup R&S Basics length on both paths. It is also immune to interference and noise and occupies only one input channel. A differential probe has three sockets: the positive signal socket (+), the negative signal socket (-), and the ground socket. Differential probes provide multiple input voltages: ●...
Page 40: Setting Up The Waveform
® Acquisition and Setup R&S Setting Up the Waveform 2.2 Setting Up the Waveform This chapter contains the fundamental procedures for setting up the acquisition and adjusting the channel waveforms. 2.2.1 Setting Up the Signal Input with Autoset Autoset is the solution for the major part of routine test-setup. It is also a good start if you need to use more complex trigger settings.
Page 41: Starting And Stopping Acquisition
® Acquisition and Setup R&S Setting Up the Waveform 2. Select the "Enhancement". If "Interpolated time" is set, select also the "Interpolation mode". Enhancement affects all waveforms of all channels. The instrument uses enhance- ment settings if the "ADC sample rate" is less than the "Sample rate"; otherwise these settings are ignored.
Page 42: Using The Roll Mode
® Acquisition and Setup R&S Setting Up the Waveform To acquire a limited number of acquisitions 1. On the "Trigger" menu, tap "Trigger Events Setup". 2. In the "Control" area, select the "Normal" trigger mode. 3. Enter the number of acquisitions in the "Average count" field. 4.
Page 43: Reference For Acquisition And Setup
® Acquisition and Setup R&S Reference for Acquisition and Setup For details on filter settings and dependencies, see c hapter 2.3.4, "Digital Filter Setup", on page 49. To filter the input channels only 1. On the "Vertical" menu, tap "Digital Filter Setup". 2.
Page 44 ® Acquisition and Setup R&S Reference for Acquisition and Setup Time scale Sets the horizontal scale for all channel and math waveforms in seconds per division. Increase the scale to see a longer time interval of the waveform. Decrease the scale to see it in more detail.
Page 45 ® Acquisition and Setup R&S Reference for Acquisition and Setup Restrict offset to acquisition range Ensures that the trigger occurs within one acquisition cycle. If enabled, the trigger cannot be set outside the waveform diagram. SCPI command: on page 489 T RIGger<m>:...
Page 46 ® Acquisition and Setup R&S Reference for Acquisition and Setup Sample rate Sets the number of recorded waveform points per second. The sample rate is the recip- rocal value of the resolution and thus also depends on the acquisition time and the record length.
Page 47 ® Acquisition and Setup R&S Reference for Acquisition and Setup Acquisition time Shows the time of one acquisition, that is the time across the 10 divisions of the diagram: Acquisition time = Time scale * 10 divisions Changing the acquisition time changes the time scale too. SCPI command: ...
Page 48 ® Acquisition and Setup R&S Reference for Acquisition and Setup Channel-dependent settings The "Decimation" and "Wfm arithmetic" are specific for each waveform. Make sure to select the channel tab first, then set up the waveforms. Resolution enhancement If the ADC sample rate is too slow to capture sufficient samples to achieve the required resolution, the sample rate can be increased by adding calculated points to the waveform record.
Page 49 After a number of acquisitions, the oscilloscope builds the waveform from the sampled points. The R&S RTO uses the sequential equivalent-time sampling method. When a trigger occurs, a sample is taken after a very short delay time.
Page 50 Decimation reduces the data stream of the ADC to a stream of waveform points with lower sample rate and a less precise time resolution. The R&S RTO uses decimation, if the waveform "Sample rate" is less than the "ADC sample rate". In this case, enhance- ment settings are ignored.
Page 51 ® Acquisition and Setup R&S Reference for Acquisition and Setup Reset Now Forces the immediate restart of the envelope and average calculation for all waveforms, ignoring the reset settings. Acquisition/average count Access: ● TRIGGER > "Control" tab > "Average count (N-single count)" ●...
Page 52 ® Acquisition and Setup R&S Reference for Acquisition and Setup Fig. 2-5: Normal acquisition with blind time With Ultra Segmentation, a number of triggered acquisitions is captured very fast, with hardly any dead time between the acquisitions. The data is processed and the waveforms are displayed when the acquisition of the series has been completed.
Page 53 ® Acquisition and Setup R&S Reference for Acquisition and Setup Enable ultra segmentation Switches the Ultra Segmentation mode on and off. If "Equivalent time" sampling is selected in the "Acquisition" tab, enabling Ultra Segmen- tation switches the resolution enhancement to "Interpolated time". SCPI command: ...
Page 54: Vertical Settings
® Acquisition and Setup R&S Reference for Acquisition and Setup Show history Enables the history mode and displays the history viewing functions in the "Ultra Seg- mentation" tab. For details, see c hapter 4.4.3.1, "Viewer", on page 118. 2.3.2 Vertical Settings The "Vertical"...
Page 55 ® Acquisition and Setup R&S Reference for Acquisition and Setup Coupling 50 Ω Selects the connection of the channel signal determining what part of the signal is used for waveform analysis and triggering. In addition to coupling, the signal can be filtered for high frequency rejection, see c hap- 1 MΩ...
Page 56 ® Acquisition and Setup R&S Reference for Acquisition and Setup "800 MHz, Frequencies above the selected limit are removed to reduce noise at 200MHz, different levels. 20MHz" SCPI command: on page 439 C HANnel<m>: B ANDwidth Position Moves the selected signal up or down in the diagram. The visual effect is the same as for ...
Page 57: Probes
2.3.3 Probes With R&S RTO, you can use various probe types, most of all these are passive and active voltage probes. The "Probes" dialog box provides all probe-relevant information. For background information, see ...
Page 58 ® Acquisition and Setup R&S Reference for Acquisition and Setup Fig. 2-7: Probe setup for passive probes Fig. 2-8: Probe setup for active single-ende probes User Manual 1316.0827.02 ─ 06...
Page 59 ® Acquisition and Setup R&S Reference for Acquisition and Setup Fig. 2-9: Probe setup for differential single-ende probes Fig. 2-10: Probe setup for R&S RT-ZS10E active single-ende probe User Manual 1316.0827.02 ─ 06...
Page 60 ® Acquisition and Setup R&S Reference for Acquisition and Setup Fig. 2-11: Probe setup for current probes Make sure that the correct channel tab is selected. Show channel Switches the channel signal on or off. The signal icon appears on the signal bar. The waveform of the last acquisition is displayed in the diagram.
Page 61 ® Acquisition and Setup R&S Reference for Acquisition and Setup For detected active voltage probes, manual settings are not possible. Current probes are not recognized automatically but the parameters of R&S current probes (R&S RT-ZCxx) are known to the instrument. On the "Manual" mini-tab, select the probe type with "Predefined probe".
Page 62 ® Acquisition and Setup R&S Reference for Acquisition and Setup Auto Zero, AutoZero DC offset, Use AutoZero Differences in DUT and oscilloscope ground levels may cause larger zero errors affecting the waveform. If the DUT is ground-referenced, the Auto Zero function corrects the zero error of the probe to optimize measurement results at small signal levels.The validation limit depends on the probe attenuation because probes with high attenation often have to compensate high offsets.
Page 63 ® Acquisition and Setup R&S Reference for Acquisition and Setup ProbeMeter: Enable Enbles the integrated R&S Probe Meter of active R&S probes. This voltmeter measures DC voltages between the probe tip and ground connection with very high precision and enables ground-referenced measurements of voltages. The DC measurement is per- formed continuously and in parallel to the measurements of the oscilloscope.
Page 64 Probe FW update A new firmware for R&S probes is delivered together with the R&S RTO firmware. To install the new probe firmware, you download it from the instrument to the probe.
Page 65: Digital Filter Setup
® Acquisition and Setup R&S Reference for Acquisition and Setup The current installation progress is shown on the progress bar. The "State" field below the progress bar shows the following update states: "Measuring" "Updating" The update is running. "Failed" The update has failed. SCPI command: ...
Page 66 ® Acquisition and Setup R&S Reference for Acquisition and Setup Use filter Enables the DSP filter. The number of filters depends on the instrument model: ● R&S RTO1022 and R&S RTO1024 have a filter for each input channel. ● R&S RTO1012 and R&S RTO1014 have filters affecting two channels: One filter for Ch1 and Ch2, and the second filter for Ch3 and Ch4 (R&S RTO1014 only).
Page 67: Horizontal Accuracy
External reference Sets the frequency of an external reference input signal that is connected to the external reference input on the rear panel of R&S RTO. A frequency range from 1 MHz to 20 MHz is supported. SCPI command: ...
Page 68 ® Acquisition and Setup R&S Reference for Acquisition and Setup Make sure that the correct channel tab is selected. Show channel Switches the channel signal on or off. The signal icon appears on the signal bar. The waveform of the last acquisition is displayed in the diagram. SCPI command: ...
Page 69: Triggers
● Trigger mode The R&S RTO provides various trigger types for troubleshooting and signal analysis, for example, edge trigger, glitch trigger, interval trigger, slew rate trigger, and pattern trigger. For complex tasks like verifying and debugging designs, advanced trigger settings are available: ●...
Page 70 External trigger input, analog and digital trigger system In R&S RTO, the trigger types use either an analog or a digitized signal as the trigger signal. If the trigger source is a channel input, the trigger types use a digitized signal. The trigger system of the instrument is a separate system, thus the signal processing by enhance- ment, decimation and arithmetic has no impact on the trigger signal.
Page 71: Setting Up The Trigger
® Triggers R&S Setting Up the Trigger 3.2 Setting Up the Trigger This chapter provides step-by-step procedures for the important stages of trigger setup. The dialog boxes and settings are described in detail in c hapter 3.3, "Reference for Trig- gers", on page 57.
Page 72: Using Holdoff
® Triggers R&S Setting Up the Trigger Alternatively, tap the "Trigger" menu and then "Trigger Position". 2. Set the "Reference point" and the "Trigger offset". If you want to set the trigger position outside the waveform display, disable "Restrict offset to acquisition range". 3.2.3 Using Holdoff Holdoff conditions define a waiting time after the current trigger until the next trigger can be recognized.
Page 73: Qualifying The Trigger
® Triggers R&S Reference for Triggers 8. Additionally, you can define a reset condition: "Enable reset by timeout" and/or "Enable reset event". The sequence restarts with the A-event if no B-event occurs and the reset condition is fulfilled. a) If "Enable reset by timeout" is selected, enter the time in "Reset timeout". b) If "Enable reset event"...
Page 74: Events
® Triggers R&S Reference for Triggers This is the critical part of the oscilloscope setup to capture the relevant part of the waveform. ● Trigger mode: " Trigger mode" on page 85 ● Trigger position: c hapter 3.3.5, "Trigger Position", on page 83 Optional settings are: ●...
Page 75 Triggers R&S Reference for Triggers Additionally, you can let the R&S RTO find the trigger level, set the trigger levels to the same value for all channels and enable trigger qualification. These settings are located under "Trigger type dependent settings".
Page 76 ® Triggers R&S Reference for Triggers ● I nterval, see page 70 ● S lew Rate, see page 71 ● D ata2Clock, see page 72 ● P attern, see page 74 ● S erial Pattern, see page 75 Restrictions: ●...
Page 77 ® Triggers R&S Reference for Triggers "Lowpass" Frequencies higher than the "Cut-off" frequency are rejected, lower fre- quencies pass the filter. You can adjust the "Cut-off" frequency, the default is 50 kHz. SCPI command: on page 458 T RIGger<m>: A NEDge: F ILTer ...
Page 78: Edge
® Triggers R&S Reference for Triggers Fig. 3-2: Standard width trigger ThrRising = ThrFalling = Trigger thresholds for rising and falling edge are the same. The instrument misses the falling edge at T=0,27 because the signal stays below the hysteresis threshold. No trigger occurs.
Page 79: Glitch
® Triggers R&S Reference for Triggers If the trigger source is a channel signal, the edge trigger uses the digitized trigger signal. This signal can be qualified and filtered with the DSP filter. If the trigger source is the EXT TRIGGER INPUT, the analog trigger signal is used, and the coupling and filter for this signal is set directly in the trigger setup.
Page 80: Width
® Triggers R&S Reference for Triggers Polarity Indicates the polarity of a pulse, that is the direction of the first pulse slope. "Positive" Selects positive going pulses. "Negative" Selects negative going pulses. "Either" Selects both positive and negative going pulses. SCPI command: ...
Page 81 ® Triggers R&S Reference for Triggers While the width trigger can only analyze either positive or negative polarity, searching for a width is also possible for both polarities at the same time ("Either"). Polarity Indicates the polarity of a pulse, that is the direction of the first pulse slope. "Positive"...
Page 82: Runt
® Triggers R&S Reference for Triggers Trigger level Sets the voltage level for the trigger event. You can also drag the trigger level marker on the display (TA or TB on the right edge of the display). The range of the trigger level is limited in a way so that always a hysteresis for stable trigger conditions is available.
Page 83: Window
® Triggers R&S Reference for Triggers Range Selects how the time limit of the runt pulse is defined: "Any runt" Triggers on all runts fulfilling the level condition, without time limitation. "Longer" Triggers on runts longer than the given "Runt width". "Shorter"...
Page 84 ® Triggers R&S Reference for Triggers Vertical condition Selects how the signal run is compared with the window: "Enter" Triggers when the signal crosses the upper or lower level and thus enters the window made up of these two levels. "Exit"...
Page 85: Timeout
® Triggers R&S Reference for Triggers For the ranges "Shorter" and "Longer", it defines the maximum and minimum time lapse, respectively. SCPI command: on page 467 T RIGger<m>: W INDow: W IDTh ±Delta Defines a range around the "Width" value. SCPI command: ...
Page 86: Interval
® Triggers R&S Reference for Triggers 3.3.1.8 Interval The interval trigger analyzes the time between two pulses. While the interval trigger can only analyze either positive or negative polarity, searching for an interval is also possible for both polarities at the same time ("Either"). Polarity Indicates the polarity of a pulse, that is the direction of the first pulse slope.
Page 87: Slew Rate
® Triggers R&S Reference for Triggers Interv. width Defines the time between two pulses. SCPI command: on page 469 T RIGger<m>: I NTerval: W IDTh ±Delta Defines a range around the "Interval width" value. SCPI command: on page 470 T RIGger<m>:...
Page 88: Data2Clock
® Triggers R&S Reference for Triggers Lower level Sets the lower voltage threshold. When the signal crosses this level, the slew rate mea- surement starts or stops depending on the selected slope. SCPI command: on page 471 T RIGger<m>: L EVel<n>: S LEW: L OWer Range Selects how the time limit for the slew rate is defined.
Page 89 ® Triggers R&S Reference for Triggers Clock source Selects the input channel of the clock signal. SCPI command: on page 473 T RIGger<m>: D ATatoclock: C SOurce[: V ALue] on page 477 T RIGger<m>: S PATtern: C SOurce[: V ALue] Clock edge Sets the edge of the clock signal to define the time reference point for the setup and hold time:...
Page 90: Pattern
® Triggers R&S Reference for Triggers Setup time Sets the minimum time before the clock edge while the data signal must stay steady above or below the data level. The setup time can be negative. In this case, the hold time is always positive. If you set a negative setup time, the hold time is adjusted by the instrument.
Page 91: Serial Pattern
® Triggers R&S Reference for Triggers "Timeout" Defines how long the result of the state pattern condition must be true or false. "Width" Defines a time range for keeping up the true result of the state pattern condition. The range is defined in the same way as for width and interval triggers, see ...
Page 92: Triggering On Serial Buses
® Triggers R&S Reference for Triggers Clock level Sets the voltage level for the clock signal. SCPI command: on page 478 T RIGger<m>: S PATtern: C SOurce: L EVel Data level Sets the voltage level for the data signal. If the signal value is higher than the data level, the state is 1.
Page 93: Trigger Qualification
® Triggers R&S Reference for Triggers 3.3.2 Trigger Qualification By qualifying a trigger event, you can logically combine the trigger signal with the state of other digital channel signals. The instrument triggers if both of the following apply: ● The basic conditions of the trigger event definition are fulfilled. ●...
Page 94 ® Triggers R&S Reference for Triggers defines the logic combination of two sources. The sources are channel "Logical 1/2 and channel 3/4 on the first step, and in the second step the logical operator" combination resulting from the first step. ●...
Page 95: Noise Reject
® Triggers R&S Reference for Triggers 3.3.3 Noise Reject The rejection of noise by settting a hysteresis avoids unwanted trigger events caused by noise oscillation around the trigger level. You can select the hysteresis mode and value for each channel separately, or couple the trigger levels and set the same hysteresis for channels.
Page 96: Sequence
® Triggers R&S Reference for Triggers Absolute hysteresis Defines a range in absolute values around the trigger level. If the signal jitters inside this range and crosses the trigger level thereby, no trigger event occurs. SCPI command: on page 483 T RIGger<m>:...
Page 97 ® Triggers R&S Reference for Triggers Holdoff mode Selects the method to define the holdoff condition. The trigger holdoff defines when the next trigger after the current will be recognized. Thus, it affects the next trigger to occur after the current one. Holdoff helps to obtain stable triggering when the oscilloscope is triggering on undesired events.
Page 98 ® Triggers R&S Reference for Triggers "Auto" The holdoff time is calculated automatically based on the current hori- zontal scale. "Auto time scaling" defines the factor the horizontal scale is multipied with. "Auto time" shows the resulting holdoff time: Auto time = Auto time scaling * Horizontal scale.
Page 99: Trigger Position
® Triggers R&S Reference for Triggers Example: If the "A Trigger" tab is selected in the "Events" tab, and the trigger level for Ch1 is 70 mV, the event coupling sets the trigger levels for Ch1 in the B- and R-events also to 70 mV.
Page 100 ® Triggers R&S Reference for Triggers The pretrigger part of the waveform can help troubleshooting, for example, to find the cause of a glitch. The posttrigger part shows what follows the trigger. Trigger offset Adds a time offset to the reference point to choose the part of the waveform to be captured and shown in the diagram.
Page 101: Control
In addition to the settings in the dialog box, you need the RUN keys on the front panel to start and stop the triggering and thus the acquisition. The R&S RTO can provide an external trigger signal to synchronize the measurements of other instruments. The trigger out signal is also adjusted and enabled in the "Con- trol"...
Page 102 ® Triggers R&S Reference for Triggers "Normal" The instrument acquires a waveform only if a trigger occurs, that is, if all trigger conditions are fulfilled. If no trigger occurs, no waveform is acquired and the last acquired waveform is displayed. If no waveform was captured before, none is displayed.
Page 103 ® Triggers R&S Reference for Triggers RUN CONT. / RUN N×SINGLE Front panel keys to start and stop a continuous acquisition or a defined number of acqui- sition cycles, respectively. The number of acquisitions is set with "Average count". SCPI command: ...
Page 104: Display
® Display R&S Display Customization 4 Display ● Display Customization.....................88 ● Zoom........................101 ● XY-diagram......................111 ● History........................114 4.1 Display Customization 4.1.1 Display Settings You can customize the various elements on the screen according to your needs: Signal bar The signal bar contains signal icons (mini windows) that display either real-time views of minimized waveforms, or labels with setting information for displayed waveforms.
Page 105: Adjusting The Display
® Display R&S Display Customization ● Single event: single events and very seldom events appear yellow, a higher cumu- lative occurance is shown with blue color. This view helps to indentify specific events. Dialog boxes and result boxes You can configure the font size, contrast and transparency in dialog and result boxes. Thus, you can optimize readability or keep track of the waveforms while changing settings in dialog boxes.
Page 106 ® Display R&S Display Customization 3. For each range of cumulative occurance of the values, insert an entry in the color table: ● To insert an entry at the end of the color table, tap "Append". ● To insert an entry before an existing entry, tap the existing row and tap "Insert". ●...
Page 107 ® Display R&S Display Customization 2. Under "Color Table Assignment", select the tab for the waveform. 3. Enable "Use Color table". 4. Under "Assign color table", select the color table you want to assign to the waveform. The waveform colors are displayed according to the definition in the color table. 4.1.2.2 Using the Signal bar The signal bar can hold a large number of signal and result icons.
Page 108 ® Display R&S Display Customization To configure auto-hide The signal bar can be hidden if the displayed information has not changed for a defined time, and is displayed again automatically when a setting in the signal bar changes. The signal bar is not hidden entirely, it simply fades and becomes less visible in the display. 1.
Page 109: Reference For Display Settings
® Display R&S Display Customization To change the transparency of dialog boxes and result boxes The transparency of the dialog box background lets you see the waveforms behind the box. You can configure the transparency separately for dialog boxes and result boxes. 1.
Page 110 ® Display R&S Display Customization 4.1.3.1 Signal Colors / Persistence The "Signal Colors / Persistence" tab contains settings for the general display of wave- form data. Enable persistence If enabled, each new data point in the diagram area remains on the screen for the duration defined under ...
Page 111 ® Display R&S Display Customization Note: Use of color tables. The exact mapping of the cumulative value occurences according to the assigned color table is guaranteed only if the intensity is set to 50%. All other intensity values falsify the mapping but may improve the visibility of the signal. See also: ...
Page 112 ® Display R&S Display Customization ● "False colors": color changes gradually in a wide color spectrum with increasing cumulative occurance. ● Spectrum: colors used to display the wave lengths of the light are assigned to the cumulative occurance. High cumulative occurance is displayed blue like high wave lenght.
Page 113 ® Display R&S Display Customization ● A ssigned color table Remote commands The following remote commands are used to configure color tables: on page 495 D ISPlay: C OLor: P ALette: C OUNt on page 494 D ISPlay: C OLor: P ALette: A DD ...
Page 114 ® Display R&S Display Customization Show crosshair If selected, a crosshair is displayed in the diagram area. A crosshair allows you to select a specific data point by its co-ordinates. SCPI command: on page 497 D ISPlay: D IAGram: C ROSshair Show labels If selected, labels mark values on the x- and y-axes in specified intervals in the diagram.
Page 115 ® Display R&S Display Customization SCPI command: on page 497 D ISPlay: S IGBar[: S TATe] Position The signal bar can be placed vertically at the right (default position), or at the left to ensure best visibility of the waveforms. SCPI command: ...
Page 116 ® Display R&S Display Customization Hide head also If selected, the "Auto hide" function hides also the horizontal and trigger label at the top of the signal bar. SCPI command: on page 498 D ISPlay: S IGBar: H IDE: H EAD Hiding transparency Sets the transparency of the signal bar when the signal bar is faded out with "Auto- hide".
Page 117: Zoom
4.2.1 Methods of Zooming The R&S RTO provides the usual way of zooming: You define the section of a diagram that you want to magnify, and the zoomed view is shown in a separate zoom diagram.
Page 118 ® Display R&S Zoom There are different ways to initiate and configure the zoom function: ● Graphically by drawing and moving the zoom area on the touch screen – a very quick and simple method for hardware zoom and zoom diagrams ●...
Page 119: Zooming For Details
® Display R&S Zoom 4.2.2 Zooming for Details Use one of the following zooming methods: ● T o define the zoom area graphically ● T o define the zoom area numerically using start-stop values ● T o define the zoom area numerically using position and range values ●...
Page 120 ® Display R&S Zoom 3. If the zoom area is not yet placed ideally, adjust the position by dragging the area or with the navigation knob. ● Drag the rectangle in the overview to the correct position. ● Turn the navigation knob to shift the zoom area. Press the knob twice to toggle between vertical and horizontal move.
Page 121 ® Display R&S Zoom 5. Under "Horizontal mode", select whether you want to define absolute or relative x- axis values. 6. Define the "Start" and "Stop" values that define the lower and upper borders (respec- tively) of the zoom area on the x-axis. When you close the dialog box, the specified area is magnified in a new zoom dia- gram.
Page 122 ® Display R&S Zoom To define multiple zoom areas You can define more than one zoom area for the same diagram, for example to compare several peaks in a measurement. Graphically, simply repeat the steps described in define the zoom area graphically - for each area.
Page 123 ® Display R&S Zoom To define coupled zoom areas You can define multiple zoom areas for one diagram that are coupled, i.e. if you change the size of one zoom area, the size of all coupled zoom areas is changed as well. This is useful, for example, if you want to compare recurring peaks in a signal.
Page 124: Reference For Zoom
® Display R&S Zoom 4.2.3 Reference for Zoom The zoom area, i.e. the section to be enlarged, can be defined using two different meth- ods: ● Specifying start and stop values for the x- and y-axes; the acquired data within those values is zoomed.
Page 125 ® Display R&S Zoom Selected diagram Indicates which of the diagrams (waveframes) is selected for zooming. Vertical mode Defines whether absolute or relative values are used to specify the y-axis values. SCPI command: on page 506 L AYout: Z OOM: V ERTical: M ODE ...
Page 126 ® Display R&S Zoom Horizontal mode Defines whether absolute or relative values are used to specify the x-axis values. SCPI command: on page 503 L AYout: Z OOM: H ORZ: M ODE on page 637 S EARch: R ESDiagram: H ORZ: M ODE Start / Relative start Defines the lower limit of the zoom area on the x-axis.
Page 127: Xy-Diagram
® Display R&S XY-diagram Position / Relative position Defines the y-value of the centerpoint of the zoom area. SCPI command: on page 506 L AYout: Z OOM: V ERTical: A BSolute: P OSition on page 507 L AYout: Z OOM: V ERTical: R ELative: P OSition ...
Page 128: Displaying An Xy-Diagram
® Display R&S XY-diagram you to perform phase shift measurements, for example. You can display up to four dif- ferent XY-diagrams. XY-diagrams can be used to display the IQ representation of a signal. 4.3.1 Displaying an XY-diagram You can create the diagram from active waveforms with drag&drop, or use the dialog box for setup.
Page 129: Reference For Xy-Diagram
® Display R&S XY-diagram 3. In the "X-source" field, define the signal source that supplies the x-values of the XY- diagram. Select one of the following: ● One of the waveforms of any channel ● A reference waveform ● The results of a mathematical function 4.
Page 130: History
® Display R&S History SCPI command: on page 509 W AVeform<m>: X YCurve: S TATe X-source Defines the signal source that supplies the x-values of the XY-diagram. Select one of the following: ● One of the waveforms of any channel ●...
Page 131: About History
The shorter the record length, the less the number of channels, and the larger the memory, the more history waveforms are saved. The memory can be enhanced with optional memory extension: 50 MSa with RTO-B101 100 MSa with RTO-B102.
Page 132 ® Display R&S History ● " To save the history" on page 117 To open the history and get information 1. Press the HISTORY key on the front panel. The history mode is enabled and the quick-access "History" dialog box is displayed. The HISTORY key is illuminated as long as the history mode is active.
Page 133: Reference For History
® Display R&S History To enter the oldest or newest acquisition for either index, tap the appropriate button. The newest acquisition always has the index "0". The "Start index" is always negative. 4. Tap "Play" to start. To exit the history ►...
Page 134 ® Display R&S History 4.4.3.1 Viewer The settings in the "Viewer" tab control the display of history waveforms. The numbering of the waveforms refers to the current memory content. With every RUN CONT or RUN×SINGLE action, the memory content changes. Show history Enables the history mode and allows to save history waveforms to file.
Page 135 ® Display R&S History Current Sets the newest acquisition in the sample memory as "Stop acq" and "Current acq". This acquisition always has the index "0". Oldest Sets the oldest acquisition in the sample memory as "Start acq" and "Current acq". Auto repeat If selected, the replay of the history waveform sequence repeats automatically.
Page 136 ® Display R&S History 4.4.3.2 Information Max. acquisition count Displays the maximum number of acquisitions that can be saved in the sample memory and displayed with the history viewer. With Ultra Segmentation, it is also the maximum number of acquisitions in an Ultra Segmentation acquisition series. Available acquisitions Displays the number of acquisitions currently saved in the sample memory.
Page 137: Measurements
Cursor measurements 5 Measurements Using the R&S RTO you can perform and display different measurements simultane- ously, based on the active signal or math waveforms. The color of the results in the result table corresponds with the source waveform color.
Page 138: Performing Cursor Measurements
® Measurements R&S Cursor measurements For details on using the result box, see "Displaying results" in the "Getting Started" man- ual. The following information may be provided in the result box, depending on the selected source. Label Description t1, t2 The time at the position of the vertical cursors.
Page 139 ® Measurements R&S Cursor measurements ● Press the CURSOR key. ● Tap the "Cursor"icon, and then tap the diagram where you want to set the cursors, or draw a rectangle in the diagram to position the cursor lines. The cursor lines appear and the "Cursor Results" box for the selected waveform opens.
Page 140 ® Measurements R&S Cursor measurements b) To position the horizontal cursors automatically, select "Track waveform". In this case, cursor 1 indicates the current maximum, cursor 2 indicates the current minimum. If both horizontal and vertical cursors are displayed, the horizontal cur- sors are placed at the crossing points of the vertical cursors with the waveform.
Page 141: Reference For Cursor Measurements
® Measurements R&S Cursor measurements 5. Select "Show labels". 6. To display only the crossing points of the cursors with the waveform, select the cursor style "Rhombus". To display both the crossing points and the cursor lines, select the cursor style "Line &...
Page 142 ® Measurements R&S Cursor measurements "Horizontal cursors" The horizontal cursors are positioned along the waveform or can be positioned manually. "Vertical cursors" The vertical cursors are positioned manually. "Both horizontal and vertical cursors" The horizontal cursors are positioned along the waveform or can be positioned manually.
Page 143 ® Measurements R&S Cursor measurements Show in all diagrams Shows the enabled cursor measurements in all active diagrams of the same (time/spec- trum) domain. 5.1.3.2 Cursor Style and Label Tab The settings in this tab configure the display of the cursors. C1/C2/C3/C4 The settings for each of the four available cursor measurements are configured on sep- arate tabs.
Page 144 ® Measurements R&S Cursor measurements c1, c2 absolute Both cursors are set to the absolute peak value. SCPI command: on page 521 C URSor<m>: M AXimum[: P EAK] c2 next left Cursor 2 is set to the next peak to the left of the current position. SCPI command: ...
Page 145: Automatic Measurements
● positive pulse measurement for digital channels (MSO option R&S RTO-B1) Note that the "Measurement" icon and the MEAS key always configure and start a new default measurement for the selected waveform. Any previous configurations for that measurement are overwritten.
Page 146 ® Measurements R&S Automatic Measurements Environment sensors Environment sensors can provide additional information during a measurement, e.g. the temperature. The collected data can be displayed as a background color in the waveform diagram. Thus you can analyze, for example, temperature-dependant behavior during a measurement.
Page 147 ® Measurements R&S Automatic Measurements Icon Description Measurement and limit checks: The measurement result might not be correct due to insufficient amplitude level. Check your amplitude and reference level settings. Limit check only: ok Limit check only: margin failed Limit check only: limit failed Intermediate results You can display auxiliary result lines and reference levels required to perform some measurement types (e.g.
Page 148 5.2.1.2 Amplitude/Time Measurements The R&S RTO provides a variety of voltage, time, area and counting measurements in the "Measurements" dialog box, "Setup > Amp/Time" tab. All measurements can be used as main or additional measurement. Some measurements require reference levels to be set according to the measurement purpose.
Page 149 ® Measurements R&S Automatic Measurements Table 5-1: Voltage measurements Meas. type Symbol Description/Result High High signal level High Low signal level Amplitude Amplitude of the signal: the difference of high and low signal lev- Ampl els. Ampl High Absolute maximum value of the waveform Absolute minimum value of the waveform Peak to peak Peak-to-peak value of the waveform: the difference of maximum...
Page 150: Time Measurements
® Measurements R&S Automatic Measurements Meas. type Symbol Description/Result Cycle mean The mean value of one cycle Cycle RMS The RMS (Root Mean Square) value of one cycle Cycle σ (S-dev) The standard deviation of one cycle σ ProbeMeter The DC voltage from the connected probe Time Measurements Time measurements are provided in the "Measurements"...
Page 151 ® Measurements R&S Automatic Measurements Meas. type Symbol Description/Result Neg. duty cycle Negative duty cycle: Width of a negative pulse in relation to the NegCyc period in %. The measurement requires at least one complete period of a triggered signal. Multiple measurement is possible. NegPulse ...
Page 152 If the signal passes the mean value, an edge is counted. This measurement type is only available for digital channels (requires MSO option R&S RTO-B1). 5.2.1.3 Eye/Jitter Measurements The eye diagram is a significant means of visualizing jitter and allows you to analyze the reasons for it.
Page 153 Measurements R&S Automatic Measurements In the R&S RTO, the eye diagram is automatically set up for jitter measurements. The following characteristic values and jitter parameters can be determined: Fig. 5-2: Basic eye diagram characteristics The default eye/jitter measurement is extinction ratio (%).
Page 154 Histograms are used to plot density of data, i.e. to display graphically how often which signal values occur. In the R&S RTO, the histogram can be based on the input signal levels (amplitudes) or the time base in a time domain measurement, or on frequencies or frequency levels in a spectrum measurement.
Page 155 ® Measurements R&S Automatic Measurements Table 5-6: Histogram measurement types Meas. type Description/Result Waveform count The number of acquisitions (waveforms) the histogram is based on Waveform samples The number of samples from the most recent acquisition included in the cur- rent histogram Histogram samples The number of samples from all acquisitions included in the current histogram...
Page 156 ® Measurements R&S Automatic Measurements Meas. type Description/Result Mean The weighted arithmetic average of the histogram σ (S-dev) Standard deviation of the sample numbers Mean ±σ The range between (mean value + standard deviation) and (mean value - standard deviation) Mean ±2*σ...
Page 157: Performing Automatic Measurements
® Measurements R&S Automatic Measurements Table 5-7: Spectrum measurement types Meas. type Description/Result Channel power Power integrated over the sample values defined by a center frequency and a bandwidth; based on a defined impedance; the result is given in mW Occupied bandwidth From the defined center frequency, symmetric sample value pairs to the left and right are integrated until a user-defined percentage of the total power is...
Page 158 ® Measurements R&S Automatic Measurements 4. To display an active gate area, select "Show gate". 5. To display intermediate result lines, select "Display result lines". 6. To display reference levels, select "Display reference levels". To clear the measurement results 1. On the "Display" menu, tap "Clear screen results". The results of all measurements are cleared.
Page 159 ® Measurements R&S Automatic Measurements Note that the "Measurement" icon and the MEAS key always configure and start a new default measurement for the selected waveform. Any previous configurations for that measurement are overwritten. If no measurement is currently running, pressing the MEAS key has the same effect.
Page 160 ® Measurements R&S Automatic Measurements 2. Select the vertical tab for the measurement you want to configure. 3. Tap "Source" and select the waveform to be used as the measurement source. For histogram measurements, select the histogram. If you enabled the measurement with the toolbar icon or MEAS key, the source is already defined.
Page 161 ® Measurements R&S Automatic Measurements 9. Optionally, define a gate area to restrict the measurement to an extract of the wave- form, as described in c hapter 5.2.2.7, "Using Gate Areas", on page 150. If you enabled the measurement with the toolbar icon and drew a rectangle on the diagram, the gate area is automatically defined and enabled.
Page 162 Finally, if fixed levels are configured for the connected device, you can define the signal levels in the R&S RTO correspondingly and analyze the resulting measurement data. To determine reference and signal levels automatically By default, the histogram of the measurement data is evaluated to determine the required levels automatically.
Page 163 ® Measurements R&S Automatic Measurements 3. Define the "Source" from which the reference is taken. The source can be any signal input, math or reference waveform. 4. Select automatic "Reference level mode". 5. Define which signal level is used as a reference. For details see "...
Page 164 ® Measurements R&S Automatic Measurements 7. To define high and low signal levels: a) Enter the absolute high and low signal levels. b) By default, the lower reference level is defined at 10% of the selected signal level, the middle reference level at 50% and the upper reference level at 90%. Option- ally, select other "Relative levels", or define absolute "Top distance"...
Page 165 ® Measurements R&S Automatic Measurements 4. Enable the "Display result lines" or "Display reference levels" option, or both. The reference levels and intermediate results required for further measurements are displayed in the source diagram. 5.2.2.6 Performing Limit Checks Limit checks allow you to analyze the measured values. If the defined limits are exceeded, specific actions can be initiated.
Page 166 ® Measurements R&S Automatic Measurements 5.2.2.7 Using Gate Areas Gate areas limit the measurement to a user-defined range of the waveform. For basic amplitude vs. time or channel power measurements the gate area can be defined directly after selecting the corresponding toolbar icon. For all other measure- ments, or if you want to define a more precise gate area, configuration is done in the "Measurement >...
Page 167 ® Measurements R&S Automatic Measurements 7. Optionally, define statistics settings for the long-term measurement, as described in chapter 5.2.2.9, "Compiling Measurement Statistics", on page 151. 8. Tap the "State" icon to enable the long-term measurement. The measurement is performed until the defined number of measurement points have been generated.
Page 168: Reference For Automatic Measurements
® Measurements R&S Automatic Measurements 5. For averaging operations, define how many statistics values are used to calculate the average. 6. Tap the "Enable Statistics" icon to include statistics in the measurement results. As soon as the long-term measurement is performed, the statistics are compiled until the measurement is stopped.
Page 169 ® Measurements R&S Automatic Measurements ● Measurements Setup - Spectrum ................167 ● Measurements Setup - Histograms...............168 ● Measurements - Gate/Display Tab...............170 ● Measurements - Long Term/Statistics Tab............173 ● Measurements - Event Actions Tab..............176 ● Measurements - Sensors Tab................177 ● Histogram Setup....................179 5.2.3.1 Reference Level Settings...
Page 170 ® Measurements R&S Automatic Measurements Signal level mode In automatic reference level mode, the setting defines the high and low signal levels from which the reference levels are derived. The instrument analyzes the signal and its his- togram to define the signal level. "Auto select absolute probability"...
Page 171 ® Measurements R&S Automatic Measurements ● 5/50/95 ● 10/50/90 ● 20/50/80 ● User defined: Enter "Upper ref level", "Middle ref level", and "Lower ref level". For example, for "5/50/95": ● lower reference level = 5% of high signal level ● middle reference level = 50% of high signal level ●...
Page 172 ® Measurements R&S Automatic Measurements Upper level The upper reference level, required e.g. to determine a rise - for manual reference level mode, absolute level definition and user reference level. SCPI command: on page 534 R EFLevel<m>: A BSolute: U LEVel ...
Page 173 ® Measurements R&S Automatic Measurements For a description of "Selection" settings, see " Selection Settings" on page 153. Hysteresis Defines a hysteresis for the middle reference level. A rise or fall from the middle reference value that does not exceed the hysteresis is rejected as noise. SCPI command: ...
Page 174 ® Measurements R&S Automatic Measurements Bottom inner Defines an area above the low signal level which is still considered to be low level. SCPI command: on page 539 R EFLevel<m>: A BSolute: B ITube on page 540 M EASurement<m>: R EFLevel: R ESult: B INNer Bottom outer Defines an area beneath the low signal level which is still considered to be low level.
Page 175 ® Measurements R&S Automatic Measurements General settings in the upper part of the dialog box relate to all measurement types. Below, the measurement types are selected and configured. Depending on the selected source, not all measurement types are available. In the time domain, amplitude/time and eye/jitter measurements are available.
Page 176 ® Measurements R&S Automatic Measurements 2nd Source Defines the second source of the measurement for some amplitude vs. time measure- ments (e.g. delay, phase). The source can be any input signal, math or reference wave- form. SCPI command: on page 523 M EASurement<m>:...
Page 177 ® Measurements R&S Automatic Measurements "Margin and Margins and limits are checked for violation. Limit" SCPI command: on page 549 M EASurement<m>: A MPTime: L CHeck<n>: L OWer: L IMit on page 549 M EASurement<m>: A MPTime: L CHeck<n>: L OWer: M ARGin ...
Page 178 ® Measurements R&S Automatic Measurements Main measurement Defines the main amplitude/time measurement type. This measurement is the one refer- red to if the measurement waveform is used as a source for math calculations. The main measurement cannot be disabled in the measurement overview. The default measurement in the time domain is "Amplitude".
Page 179 ® Measurements R&S Automatic Measurements "All off" Deactivates all selected measurements in the table. SCPI command: on page 525 M EASurement<m>: A DDitional Envelope selection This setting is only relevant for measurements on envelope waveforms, see " Wfm Arith- metic"...
Page 180 ® Measurements R&S Automatic Measurements Example: With the settings shown in the picture, the time between the second rising edge and the third from last falling edge is measured. Selects the reference level on which the time is measured. "Level selec- tion"...
Page 181 ® Measurements R&S Automatic Measurements Hold Setup Hold Setup Data Clock Clock slope = Positive Clock slope = Either If at least one of the setup/hold measurements is selected, additional settings appear to specify the measurement. "Clock slope" Sets the edge of the clock from which the setup and hold times are measured: positive, negative, or either of them.
Page 182 ® Measurements R&S Automatic Measurements 5.2.3.4 Measurements Setup - Eye/Jitter Eye/jitter measurements are only available for sources in the time domain. To obtain optimized settings for an eye measurement, use the "Autoset" function that is provided on the right side of the "Eye/Jitter" tab. Main measurement Defines the main Eye/Jitter measurement type.
Page 183: Measurements Setup - Spectrum
® Measurements R&S Automatic Measurements "All on" enables all available additional measurements. "All off" Deactivates all selected measurements in the table. SCPI command: on page 525 M EASurement<m>: A DDitional Autoset Defines optimized settings to perform an eye measurement for the selected source. 5.2.3.5 Measurements Setup - Spectrum Spectrum measurements are only available if a source in the frequency domain is...
Page 184: Measurements Setup - Histograms
® Measurements R&S Automatic Measurements The overview table also contains the limit and margin definitions if a limit check is enabled, see " Limit check" on page 160. For a description of available measurement types, see " Main measure- ment"...
Page 185 ® Measurements R&S Automatic Measurements Histogram Selects the histogram on which the measurement is based. Histograms are defined via the "MEAS > Histogram" menu item. SCPI command: on page 561 M EASurement<m>: H ISTogram: S ELect Main measurement Defines the main histogram measurement type. This measurement is the one referred to if the measurement waveform is used as a source for math calculations.
Page 186: Measurements - Gate/Display Tab
® Measurements R&S Automatic Measurements "All off" Deactivates all selected measurements in the table. SCPI command: on page 525 M EASurement<m>: A DDitional Probability domain marker reference Defines the marker reference in the probability domain. "Peak" The y-value with the maximum sample value in the histogram "Upper Peak"...
Page 187 ® Measurements R&S Automatic Measurements Meas 1/2/3/4/5/6/7/8 Selects one of the eight available measurements. Use gate Considers the gating settings of the source waveform for the measurement. SCPI command: on page 572 M EASurement<m>: G ATE[: S TATe] Show gate Displays the gate area in the source diagram.
Page 188 ® Measurements R&S Automatic Measurements Zoom coupling can be set for measurement gates, FFT gates, and search gates. SCPI command: on page 586 C ALCulate: M ATH<m>: F FT: G ATE: Z COupling on page 573 M EASurement<m>: G ATE: Z COupling ...
Page 189: Measurements - Long Term/Statistics Tab
® Measurements R&S Automatic Measurements Multiple measurement Performs multiple measurements on the same source waveform, e.g. measures the rise time for all pulses in the waveform, not only the first. This is useful when calculating statistics; however, it reduces the performance of the instrument. SCPI command: ...
Page 190 ® Measurements R&S Automatic Measurements Meas 1/2/3/4/5/6/7/8 Selects one of the eight available measurements. State Enables long term measurement for a defined number of measurement points or a speci- fied time. SCPI command: on page 569 M EASurement<m>: L TMeas[: S TATe] Continuous auto scale Performs an automatical vertical scaling whenever the waveform does not fit in the dia- gram.
Page 191 ® Measurements R&S Automatic Measurements Vertical offset Defines a vertical offset for the long term measurement and the statistics histogram. SCPI command: on page 568 M EASurement<m>: V ERTical: O FFSet Enable histogram Displays a histogram of the statistical results. Enabling the histogram enables also the calculation and display of statistics for the measurement results if statistics were disabled.
Page 192: Measurements - Event Actions Tab
® Measurements R&S Automatic Measurements Reset count Defines the number of measurements after which the statistics are reset. SCPI command: on page 567 M EASurement<m>: S TATistics: R COunt Statistics average count Defines the number of measurements for which the statistical average is calculated. SCPI command: ...
Page 193: Measurements - Sensors Tab
® Measurements R&S Automatic Measurements Beep Generates a beep sound. "No function" The action is not initiated. "On violation" The action is initiated if the limits or margins are exceeded during the measurement. "On successful The action is initiated if the limits or margins were not exceeded during completion"...
Page 194 ® Measurements R&S Automatic Measurements To select the sensor and enable it for a measurement, select the c hapter 5.2.3.8, "Meas- urements - Long Term/Statistics Tab", on page 173. See also: c hapter 5.2.2.10, "Using Environment Sensors", on page 152 Environment sensor Environment sensors measure temperature and humidity around the instrument.
Page 195: Histogram Setup
® Measurements R&S Automatic Measurements Color table reference Assigns one of the available color tables to the sensor results. The background of the measurement diagrams using the selected sensor is colored according to the assigned color table. For details on color tables, see c hapter 4.1.2.1, "Editing Waveform Colors", on page 89.
Page 196 ® Measurements R&S Automatic Measurements Reset now Resets the values to begin a new histogram. SCPI command: on page 560 L AYout: H ISTogram: R ESet Range definition mode (Absolute/Relative) Defines whether the value range limits are entered as absolute or relative values. SCPI command: ...
Page 197: Mathematics
® Mathematics R&S +Mathematical Waveforms 6 Mathematics The R&S RTO provides different methods of creating mathematical waveforms: ● Applying mathematical functions to source data ● Performing FFT analysis on source data 6.1 +Mathematical Waveforms Math waveforms are the results of various calculations or FFT analysis. You can define up to four math waveforms and display them on the screen, and/or use it as source for further analysis.
Page 198: Math Setup
® Mathematics R&S +Mathematical Waveforms 5. If you need the envelope or average of the math waveform over several calculations, change the arithmetic mode for the waveform as for channel waveforms. See also: " Wfm Arithmetic" on page 34. 6.
Page 199 ® Mathematics R&S +Mathematical Waveforms Enable Math Signal If activated, a diagram for the defined math waveform is displayed on the touch screen. SCPI command: on page 576 C ALCulate: M ATH<m>: S TATe Vertical Scale Functions to set the vertical parameters of the math waveform. Note: If an FFT expression is defined, the vertical scaling for spectrum displays is avail- able: "Vertical maximum"...
Page 200 ® Mathematics R&S +Mathematical Waveforms Acquisition/average count ← Arithmetic Access: ● TRIGGER > "Control" tab > "Average count (N-single count)" ● ACQUISITION > "Average count" ● HORIZONTAL > "Ultra Segmentation" tab > disable "Acquire maximum" > "Required" ● MATH > "Setup" tab > "Average count" The acquisition and average count has several effects: ●...
Page 201: Mathematical Functions And Formulas
® Mathematics R&S Mathematical Functions and Formulas 6.2 Mathematical Functions and Formulas You can enter mathematical expressions using two different modes: ● "Optimized": a graphical editor allows you to define a simple math function quickly by selecting the source waveform(s) and the operator: c hapter 6.2.1, "Optimized Graph- ical Editor", on page 185.
Page 202 ® Mathematics R&S Mathematical Functions and Formulas Source 1 / 2 Defines the signal source to be evaluated by the math function. Waveform 1 of each channel waveform can be selected. Note: If you require other signal sources not listed here, use the formula editor provided in the "Advanced"...
Page 203: Advanced Expressions
® Mathematics R&S Mathematical Functions and Formulas ● "Cut-Off": sets the limit frequency for the FIR filter. The cut-off frequency depends on the horizontal resolution. The frequency for the low- pass filter can be set only in this range: f_g_3dB = (0.0025 ... 0.1)* f_a_in Where: f_g_3dB = cut-off frequency to be set for the lowpass filter, and f_a_in = reciprocal of the resolution, or sample rate.
Page 204 ® Mathematics R&S Mathematical Functions and Formulas d) Insert a closing square bracket using the "]" key. The resulting expression could be, for example: m[V] 6. To perform a rescaling function, proceed as follows: a) Select the rescaling function using the "ax+b" key. b) Behind the left bracket, insert the signal source that is to be rescaled using one of the following keys: ●...
Page 205 ® Mathematics R&S Mathematical Functions and Formulas Table 6-1: Basics Icon Description Usage/Comment, FormulaEditor expression left bracket enclose operands comma separates operands right bracket enclose operands e / π math. constants e: Euler number: 2.7182... Pi: 3.1415... left square bracket enclose unit V / A / Ω...
Page 206 ® Mathematics R&S Mathematical Functions and Formulas Table 6-3: Cursor keys Icon Description Usage/Comment, FormulaEditor expression move cursor to beginning |← ← move cursor 1 step to the left → move cursor 1 step to the right →| move cursor to end Table 6-4: Algebra Icon Description...
Page 207 ® Mathematics R&S Mathematical Functions and Formulas Icon Description Usage/Comment, FormulaEditor expression > greater > ≤ smaller or equal <= ≥ greater or equal >= More display additional keys Table 6-7: FFT ("More" keys) Icon Description Usage/Comment, FormulaEditor expression |FFT| magnitude of FFT value fftmag(x) FFT (φ)
Page 208: Fft Analysis
® Mathematics R&S FFT Analysis Table 6-10: Filter and power ("More" keys) Icon Description Usage/Comment, FormulaEditor expression Electric power Electric power is calculated from voltage, based on measurement impedance (see " Measurement impe- dance" on page 40) elecpower(x) = U Finite impulse response filter FIR(highpass,x,y) or FIR(lowpass,x,y) with: x = source, y = cut-off frequency...
Page 209 Conventional oscilloscopes calculate one FFT per capture. The R&S RTO can calculate multiple FFTs per capture by dividing one capture into several frames. Thus, the RTO can visualize how the frequency content of a signal changes over time which helps to detect intermittent or sporadic signal details.
Page 210 ® Mathematics R&S FFT Analysis Gate length Gate position Gate t[s] Center frequency f[Hz] Frequency span Restricting the result range You can restrict the results of the FFT analysis to a specified frequency range. The fre- quency range can be defined in two ways: ●...
Page 211 "Unwrap" function. Dependencies between FFT parameters FFT analysis in the R&S RTO is highly configurable. Several parameters, including the resolution bandwidth, frequency span and center frequency, can be defined according to the user's requirements. Note, however, that several parameters are correlated and not all can be configured independently of the others.
Page 212: Configuring Fft Waveforms
® Mathematics R&S FFT Analysis 6.3.2 Configuring FFT Waveforms During FFT analysis, a signal in the time domain is converted to a spectrum of frequen- cies. A basic FFT waveform can be displayed very quickly. By defining additional FFT parameters, the waveform can be configured in more detail. As a result, either the magnitude or the phase of the determined frequencies can be displayed, or more complex FFT functions.
Page 213 ® Mathematics R&S FFT Analysis d) Define the resolution bandwidth for the FFT result. The resolution bandwidth defines how precise the results are, i.e. how close together the individual frequencies can be. Small values result in a high precision, as the distance between two distinguishable frequencies is small. Higher values decrease the precision, but increase performance.
Page 214: Fft Configuration Settings
® Mathematics R&S FFT Analysis ● Select the "Relative" mode and enter the percentages of the total time base that define the "Relative Start" and "Relative Stop" times. ● If a zoom area has already been defined in the original diagram and you want to use the same time base for FFT analysis, select "Zoom coupling"...
Page 215: Enable Math Signal
® Mathematics R&S FFT Analysis Enable Math Signal.....................199 Center frequency......................199 Frequency span......................200 Full span........................200 Start frequency......................200 Stop frequency......................200 Span/RBW Coupling....................200 Span/RBW Ratio......................200 Resolution BW......................200 Window type........................201 Frame Arithmetics.......................201 Overlap Factor......................201 Max frame count......................202 Frame coverage......................202 Enable Math Signal If activated, a diagram for the defined math waveform is displayed on the touch screen. SCPI command: ...
Page 216: Frequency Span
® Mathematics R&S FFT Analysis Frequency span The span is specified in Hertz and defines the width of the displayed frequency range, which is (Center - Span/2) to (Center + Span/2). The position of the span is defined using the "Center frequency" setting. SCPI command: ...
Page 217: Window Type
Windowing helps minimize the discontinuities at the end of the measured signal interval and thus reduces the effect of spectral leakage, increasing the frequency resolution. Various different window functions are provided in the R&S RTO to suit different input signals. Each of the window functions has specific characteristics, including some advan- tages and some trade-offs.
Page 218: Max Frame Count
® Mathematics R&S FFT Analysis The higher the overlap factor, the more frames are used. This leads to more individual results and improves detection of transient signal effects. However, it also extends the duration of the calculation. SCPI command: on page 583 C ALCulate:...
Page 219: Enable Math Signal
® Mathematics R&S FFT Analysis Vertical scale mode (Manual/Auto)................203 Vertical maximum......................204 Vertical range......................204 Range..........................204 Phase unit........................204 Unwrap........................204 Suppression........................204 Threshold........................204 Enable Math Signal If activated, a diagram for the defined math waveform is displayed on the touch screen. SCPI command: on page 576 C ALCulate:...
Page 220 ® Mathematics R&S FFT Analysis Vertical maximum Defines the maximum value on y-axis for spectrum displays. Only available for "Man- ual" scale mode. Vertical range Defines the range of FFT values to be displayed. SCPI command: on page 576 C ALCulate:...
Page 221 ® Mathematics R&S FFT Analysis If no gate is used, you can define the type of "Record Length/RBW Coupling" here. Enable Math Signal.....................206 Gate........................206 Show gate........................206 Gate Definition......................206 └ Zoom coupling....................206 └ Gate Mode....................206 └ (Relative) Start....................207 └ (Relative) Stop....................207 Record Length/RBW Coupling..................207 Required acquisition...
Page 222 ® Mathematics R&S FFT Analysis Enable Math Signal If activated, a diagram for the defined math waveform is displayed on the touch screen. SCPI command: on page 576 C ALCulate: M ATH<m>: S TATe Use Gate Enables FFT gating. If enabled, the "Gate Definition"...
Page 223 ® Mathematics R&S FFT Analysis (Relative) Start ← Gate Definition Defines the starting value for the gate. SCPI command: on page 584 C ALCulate: M ATH<m>: F FT: G ATE: A BSolute: S TARt on page 585 C ALCulate: M ATH<m>: F FT: G ATE: R ELative: S TARt ...
Page 224: Reference Waveforms
® Reference Waveforms R&S Working with Reference Waveforms 7 Reference Waveforms 7.1 Working with Reference Waveforms You can configure up to four reference waveforms to display stored waveforms. Any active signal or mathematical waveform can be stored as a reference waveform. It can then be loaded again later to restore the waveform on the screen.
Page 225: Reference Waveforms
® Reference Waveforms R&S Reference Waveforms 4. To save the waveform to the currently selected file, select "Save". By default, the prefix for reference waveform files is "RefCurve". To save the waveform to a new file, select "Save As" and enter a file name, then select the directory and file type.
Page 226 ® Reference Waveforms R&S Reference Waveforms 1/2/3/4........................210 Source.........................210 Update with selected source..................210 Show reference waveform..................210 Clear reference waveform...................210 Save to or load from file....................211 Ref 1/2/3/4 Each tab contains the settings for one of the four available reference waveforms. Source Selects the source waveform from the active waveforms of input channels, math signals and other reference waveforms.
Page 227: Scaling
® Reference Waveforms R&S Reference Waveforms Save to or load from file Enter the file name of the stored reference waveform and select the file format with the format button on the right. Double-tap the file name to open the file selection dialog box, see also ...
Page 228 ® Reference Waveforms R&S Reference Waveforms "Independent" Scaling and position can be set specific to the reference waveform. SCPI command: on page 592 R EFCurve<m>: V MODe Vertical scale Sets the scale factor for the reference waveform, if vertical scaling is set to "Independ- ent".
Page 229: Original Attributes
® Reference Waveforms R&S Reference Waveforms "Adjust to X- The current horizontal settings of the diagram are used. Axis" "Original Scal- Horizontal scaling and reference point of the source waveform are ing" used. SCPI command: on page 594 R EFCurve<m>: H MODe Horizontal Stretching Stretching changes the display of the waveform independent of the horizontal settings of the source waveform and of the horizontal diagram settings.
Page 230 ® Reference Waveforms R&S Reference Waveforms ● " Time scale" on page 28 ● " Vertical scale" on page 39 ● " Resolution / Record length (Time scale dependency)" on page 31 ● " Source" on page 210 ●...
Page 231: Mask Testing
"mask", which is laid over the input signal in the display. Thus you can easily detect where the signal violates the mask. Mask testing with R&S RTO has only a minor impact on the acquisition rate, thus mask violations are detected very fast and reliably.
Page 232 ® Mask Testing R&S About Mask Testing Number of tested acquisitions. SCPI command: on page 609 M TESt: R ESult: C OUNt: W AVeforms Acq. remaining Remaining acquisitions until "Average count / Nx Single count" is reached. The value is useful if you test a specified number of acquisitions with action "Stop acqui- sition"...
Page 233: Working With Masks
® Mask Testing R&S Working with Masks Test result A test has failed if the number of sample hits or acquisition hits exceeds the limit of "Violation tolerance" hits. SCPI command: on page 609 M TESt: R ESult[: R ESult] 8.2 Working with Masks ●...
Page 234 ® Mask Testing R&S Working with Masks as mask. If the line is in the upper half of the display, the region above the line becomes the mask (upper region). If the line is in the lower half, the region below the line is taken (lower region).
Page 235 ® Mask Testing R&S Working with Masks 2. Tap the "Masks" icon on the toolbar. 3. Tap the corner points of the new mask segment on the touch screen. 4. To finish the segment and mask definition, double-tap the last point, or tap the "Select"...
Page 236 ® Mask Testing R&S Working with Masks 2. Select the "Mask Definition" tab. 3. On the left, select the mask test for which you want to change the mask definition. 4. To add or delete a mask segment, tap the segment's row in the "Mask segments" table and tap the required button below: ●...
Page 237: Setting Up A Mask Test
® Mask Testing R&S Working with Masks 5. To stretch or compress the selected mask segment, enter the "X-Factor" for hori- zontal scaling and the "Y-Factor" for vertical scaling. The x-values and y-values of all points are multiplied with the corresponding factor. Factors >1 stretch the mask seg- ment, while factors between 0 and 1 compress it.
Page 238: Running A Mask Test
® Mask Testing R&S Working with Masks 3. Select "Show mask" to display the masks of all enabled mask tests on the screen. 4. Define how the sample hits are displayed: a) Select "Highlight hits" to display the sample hits. b) Set the "Highlight time"...
Page 239: Saving And Loading Masks
® Mask Testing R&S Working with Masks ● The mask display is configured, see c hapter 8.2.3, "Configuring the Mask and Hit Display", on page 221. You can perform continuous testing or test a specified number of acquisitions. 1. Press the MASKS key on the front panel. 2.
Page 240: Mask Testing On History Acquisitions
® Mask Testing R&S Reference for Masks 8.2.6 Mask Testing on History Acquisitions In the same way as for running acquisitions, you can set up and perform the mask testing also on history waveforms. The requirements for mask testing on history waveforms are also the same: ●...
Page 241 ® Mask Testing R&S Reference for Masks The content of the "Test Definition" tab depends on the selected definition type: "User" or "Waveform". If "Waveform" is selected, the main mask settings can be set directly on the "Test Definition" tab. For a description of these settings, see c hapter 8.3.2.2, "Mask Definition: Waveform Mask", on page 230.
Page 242 M TESt: T OLerance Save / load mask test Provides all functions to store and recall a mask test. The mask definition, defined actions and fail conditions are stored in an R&S RTO-specific xml file. "Load, Save" Recalls or stores the specified file.
Page 243: Mask Definition
® Mask Testing R&S Reference for Masks 8.3.2 Mask Definition With mask definition, you define the shape of the mask - the form and position of its limit lines. The content of the "Mask Definition" tab depends on the selected "Definition type": "User"...
Page 244 ® Mask Testing R&S Reference for Masks Make sure that the correct "Mask Test" tab is selected on the left side before you enter the settings. Mask segments Defines the number and state of mask segments for the selected mask test. Here you can: ●...
Page 245 ® Mask Testing R&S Reference for Masks ● Insert a new point before the selected point. ● Append a new point at the end of the list. ● Remove the selected point from the list. ● Change the x- and y-values of each point. To scale or move the complete segment, use offset and factor values, see ...
Page 246 ® Mask Testing R&S Reference for Masks To take effect, tap "Recalculate". SCPI command: on page 604 M TESt: S EGMent: R ESCale: Y FACtor Recalculate ← Rescale Multiplies and adds the given x- and y-factors and offsets to the coordinates of all points of the selected mask segment.
Page 247 ® Mask Testing R&S Reference for Masks Common settings: ● " Definition type" on page 226 ● " Source" on page 225 ● " Wfm Arithmetic" on page 34 Create mask Creates the upper and lower mask limit from the envelope of the selected reference waveform.
Page 248 ® Mask Testing R&S Reference for Masks Fig. 8-1: Waveform mask with horizontal width = 0.2 div SCPI command: on page 606 M TESt: W FMRescale: X WIDth Vertical width Sets the width of the waveform mask in vertical direction. The specified number of divi- sions is added to the y-values of the upper mask limit and subtracted from the y-values of the lower mask limit.
Page 249: Event Actions /Reset
® Mask Testing R&S Reference for Masks Fig. 8-3: Waveform mask with vertical width = 0.5 div, vertical position = -0.5 div, vertical stretch = 110% SCPI command: on page 607 M TESt: W FMRescale: Y STRetch Vertical position Moves the mask vertically within the display.
Page 250 ® Mask Testing R&S Reference for Masks Make sure that the correct "Mask Test" tab is selected on the left side before you enter the settings. Beep Generates a beep sound. SCPI command: on page 607 M TESt: O NViolation: B EEP Stop acq.
Page 251: Mask Display
® Mask Testing R&S Reference for Masks Reset Clears all totals and results in all "Mask Test" result boxes. SCPI command: on page 598 M TESt: R ST 8.3.4 Mask Display The "Mask Display" tab contains all settings for mask and hit display. Show mask Switches the display of all mask segments on or off.
Page 252: Search Functions
® Search Functions R&S Search Conditions and Results 9 Search Functions Search functions allow you to detect and analyze specific conditions in the acquired data quickly and simply. This is possible for running acquisitions. Various search conditions are available, including trigger parameters such as edges, windows or states. Search results can then be qualified further by other waveform conditions.
Page 253: Configuring And Performing Searches
® Search Functions R&S Configuring and Performing Searches Search Results box Search results are displayed in a "Search Results" box with a tab for each search con- dition and one for the combined results. Each tab contains a table with the position and, if available, further parameters for each result.
Page 254: Configuring A Frequency Marker Search
® Search Functions R&S Configuring and Performing Searches 3. Enter a name for the search configuration using the displayed on-screen keyboard. 4. Select the "Source" waveform on which you want to perform the search. To perform a trigger search, select a time-based waveform. 5.
Page 255: Configuring The Search Results Presentation
® Search Functions R&S Configuring and Performing Searches To configure the frequency marker search manually 1. Press the SEARCH key to open the "Search" dialog box. 2. Tap the "Add" icon to create a new tab for the new search configuration, or the "Copy"...
Page 256 ® Search Functions R&S Configuring and Performing Searches To move the position of the search results display By default, the "Search Results" box is displayed in front of the other diagrams. Alterna- tively, you can display it in its own area on the screen, like another diagram. For details see "Working with Waveforms"...
Page 257: Clearing Search Results
® Search Functions R&S Reference for Search Settings The zoom area is indicated in the diagram that displays the source waveform of the search. It can also be moved manually, as with other zoom areas, thus changing the settings of the zoom window. Be aware, however, that the zoom window settings are valid for all search zoom windows, so if you change the settings drastically for one result, they may not be correct for the next search result you switch to.
Page 258: Setup Tab
® Search Functions R&S Reference for Search Settings on page 611 S EARch: A DD on page 612 S EARch: R EMove 9.3.1 Setup Tab The "Setup" tab contains the basic search settings, including the source, search condi- tions and search control.
Page 259 ® Search Functions R&S Reference for Search Settings Clear results Clears the search results once to start a new search. SCPI command: on page 612 S EARch: C LEar Search conditions Defines the search conditions, depending on the search type (spectrum or trigger). For trigger searches, most parameters available for trigger event definition can also be con- figured as search conditions.
Page 260: Scope Tab
® Search Functions R&S Reference for Search Settings Select ← Search conditions Includes the search conditions for the selected trigger event type in the next search. SCPI command: on page 614 S EARch: T RIGger: E DGE[: S TATe] ...
Page 261 ® Search Functions R&S Reference for Search Settings Use Gate Performs the search only on the defined gate area of the source waveform. SCPI command: on page 632 S EARch: G ATE[: S TATe] Show gate Displays the gate area in the source diagram. SCPI command: ...
Page 262: Result Presentation
® Search Functions R&S Reference for Search Settings (Relative) Stop Defines the end value for the gate. SCPI command: on page 584 C ALCulate: M ATH<m>: F FT: G ATE: A BSolute: S TOP on page 585 C ALCulate: M ATH<m>: F FT: G ATE: R ELative: S TOP ...
Page 263 ® Search Functions R&S Reference for Search Settings Show result table ← Result table Displays or hides the search result table. SCPI command: on page 640 S EARch: R ESult: S HOW Sort mode ← Result table Sorts the search result table by x-value position or value of the result. SCPI command: ...
Page 264: Noise Reject
® Search Functions R&S Reference for Search Settings Position / Relative position ← Search zoom window Defines the y-value of the centerpoint of the zoom area. SCPI command: on page 506 L AYout: Z OOM: V ERTical: A BSolute: P OSition ...
Page 265 ® Search Functions R&S Reference for Search Settings Enable If enabled, the noise reject settings for the waveform are considered for the search. SCPI command: on page 643 S EARch: T RIGger: L EVel: N OISe[: S TATe] Absolute/Relative Defines whether values absolute or relative to the vertical scaling are used.
Page 266: Protocol Analysis
LIN - decoding and triggering requires option R&S RTO-K3 ● FlexRay - decoding and triggering requires option R&S RTO-K4 Triggering on SPI, I²C and UART is available with the main R&S RTO without any options. ● Basics of Protocol Analysis...................250 ●...
Page 267: Configuration - General Settings
® Protocol Analysis R&S Basics of Protocol Analysis 10.1.1 Configuration - General Settings For all protocols, configuration starts with the selection of the serial bus and the protocol. The "Trigger Setup" button leads directly to the trigger configuration. Protocol-specific configuration settings are described in the protocol chapters: ●...
Page 268 SPI: c hapter 10.3.3.3, "SPI Decode Results (Option R&S RTO-K1)", on page 276 ● UART: c hapter 10.4.2.3, "UART Decode Results (Option R&S RTO- K2)", on page 283 ● LIN: c hapter 10.6.2.3, "LIN Decode Results", on page 303 ●...
Page 269: Protocol Translation Tables
® Protocol Analysis R&S Basics of Protocol Analysis Binary bit order Select MSB or LSB to define the data bit order in the display of the decoded signal. The setting is only available for the binary data format. Binary bit group size Sets the number of bits that forms a bit group in the display.
Page 270 Translation tables are protocol-specific. Their contents are described in the correspond- ing protocol chapters: ● c hapter 10.2.3.4, "I C Translation Table (Option R&S RTO-K1)", on page 267 ● c hapter 10.5.1.4, "CAN Translation Table", on page 294 ●...
Page 271: Bit Pattern Editor
Translation tables are protocol-specific. Their contents are described in the correspond- ing protocol chapters: ● c hapter 10.2.3.4, "I C Translation Table (Option R&S RTO-K1)", on page 267 ● c hapter 10.5.1.4, "CAN Translation Table", on page 294 ●...
Page 272: I²C
® Protocol Analysis R&S I²C The editor displays the pattern in two columns. The left column always shows binary data. For the right column, you can select the format, the default depends on the data specifics. You can edit data in the left or right column. The keypad adapts itself to the column format, only keys appropriate to the format are enabled.
Page 273: The I²C Protocol
● Acknowledge: takes place after every byte. The receiver of the address or data sends the acknowledge bit to the transmitter. The R&S RTO supports all operating speed modes: high-speed, fast mode plus, fast mode, and standard mode. Data transfer The format of a simple I²C message (frame) with 7 bit addressing consists of the following...
Page 274: Analyzing I²C Signals
Fig. 10-3: 10-bit address, read access Trigger The R&S RTO can trigger on various parts of I²C messages. The data and clock lines must be connected to the input channels, triggering on math and reference waveforms is not possible.
Page 275 ® Protocol Analysis R&S I²C 10.2.2.1 Configuring I²C Protocol The configuration of the I²C is simple - assign the two lines to input channels, and set the thresholds. For details on configuration settings, see c hapter 10.2.3.1, "I²C Configura- tion", on page 260.
Page 276: Reference For I²C
® Protocol Analysis R&S I²C 10.2.3 Reference for I²C 10.2.3.1 I²C Configuration Make sure that the tab of the correct serial bus is selected on the left side. See also: c hapter 10.1.1, "Configuration - General Settings", on page 251. SDA, SCL Set the waveforms of the data line (SDA) and clock line (SCL).
Page 277 ® Protocol Analysis R&S I²C There are three ways to set the threshold: ● "Threshold" Enter the value directly in the field. ● "Set to 50%" Executes the measurement of reference levels and sets the thresholds to the middle reference level of the measured amplitude. ●...
Page 278 ® Protocol Analysis R&S I²C Make sure that: ● the trigger sequence is set to "A only" ● the trigger source is "Serial bus", and the data source(s) of the bus are channel signals ● the correct serial bus is selected ●...
Page 279 ® Protocol Analysis R&S I²C "Address OR" Triggers on one to four address conditions. Description of trigger type specific settings: " Address OR condi- tions" on page 264. Sets the trigger to a combination of address and data condition. The "Address and data"...
Page 280 ® Protocol Analysis R&S I²C For "7 bit" and "10 bit", enter the address bits in the A ddr. min / Addr. max field, and use the " R/W bit" on page 264 field to select the transfer direction. For "7+1 bit", enter the seven address bits and also the R/W bit in the "Address"...
Page 281 654 T RIGger<m>: I 2C: D MAX 10.2.3.3 I²C Decode Results (Option R&S RTO-K1) If the option is installed, the "Decode" function in the "Configuration" tab is available. Enable "Decode" to display the decoded signal below the waveforms.
Page 282 ® Protocol Analysis R&S I²C Additionally, you can display the binary signal and the detailed decoding results, see chapter 10.1.2, "Display", on page 251. Fig. 10-4: Decoded and binary I2C signal, and decode results green brackets [...] = start and end of frame yellow = address blue...
Page 283 662 B US<m>: I 2C: F RAMe<n>: B YTE<o>: V ALue 10.2.3.4 C Translation Table (Option R&S RTO-K1) Translation tables are protocol-specific. An I C protocol translation file contains three values for each bus node. After a file was loaded, these values are shown in the trans- lation table: ●...
Page 284 ® Protocol Analysis R&S I²C ● "ID Value": decimal address value ● "ID Name": symbolic label, name of the bus node, specifiing its function in the bus network. The name can be changed in the table. If "Translation" is enabled, the names ares visible in the "Decode results" table and in the display of the decoded signal.
Page 285: Spi Bus
® Protocol Analysis R&S SPI Bus 7,0x01,Temperature 7,0x12,Pressure 10,0x123,Speed # ID as integer 7,17,Brake # ---------------------------------------------------------------------------- SCPI command ● on page 662 B US<m>: I 2C: F RAMe<n>: T RANslation 10.3 SPI Bus 10.3.1 The SPI Protocol A 4-channel instrument is required for full support of the SPI protocol. The Serial Peripheral Interface SPI is used for communication with slow peripheral devi- ces, in particular, for transmission of data streams.
Page 286: Analyzing Spi Signals
® Protocol Analysis R&S SPI Bus For SPI buses, the R&S RTO provides the following trigger possibilities: ● On frame start ● On a serial pattern ● On a serial pattern at a specified position 10.3.2 Analyzing SPI Signals 10.3.2.1...
Page 287: Reference For Spi
® Protocol Analysis R&S SPI Bus For details, see c hapter 10.3.3.2, "SPI Trigger", on page 273 10.3.3 Reference for SPI 10.3.3.1 SPI Configuration Make sure that the tab of the correct serial bus is selected on the left side. See also: ...
Page 288 ® Protocol Analysis R&S SPI Bus SS, MISO, MOSI Configures the Slave Select, MISO and MOSI lines. Source ← SS, MISO, MOSI Sets the input channel of the selected line. Waveform 1 of channel signals, math wave- forms, reference waveforms, or no waveform can be selected. For triggering on a serial bus, a channel signal is required.
Page 289 ® Protocol Analysis R&S SPI Bus Bit order Defines if the data of the messages starts with msb (most significant bit) or lsb (least significant bit). The display of the decoded signal considers this setting, results are dis- played in the specified order. SCPI command: ...
Page 290 ® Protocol Analysis R&S SPI Bus Make sure that: ● the trigger sequence is set to "A only" ● the trigger source is "Serial bus", and the data source(s) of the bus are channel signals ● the correct serial bus is selected ●...
Page 291 ® Protocol Analysis R&S SPI Bus "Frame start Triggers on the start of the frame when the clock idle time exceeds the "Timeout" time. This trigger type is available if (Timeout)" F rame condition is set to "CLK timeout". "MOSI"...
Page 292 668 T RIGger<m>: S PI: P ALignment 10.3.3.3 SPI Decode Results (Option R&S RTO-K1) If the option is installed, the "Decode" function in the "Configuration" tab is available. Enable "Decode" to display the decoded signal below the waveforms.
Page 293 ® Protocol Analysis R&S SPI Bus Fig. 10-6: Decoded and binary SPI signal with SCLK, MOSI, and SS line green brackets [...] = start and end of complete frame red brackets [...] = start and end of incomplete frame yellow = word = error The "Decode results"...
Page 294: Uart / Rs232
® Protocol Analysis R&S UART / RS232 Example: In the figure above, the first three frames contain two words each. The fourth frame is incomplete, only one word of the frame was recognized SCPI commands: ● on page 671 B US<m>:...
Page 295: Reference For Uart/Rs-232 Interface
® Protocol Analysis R&S UART / RS232 Trigger The R&S RTO can trigger on specified parts of UART serial signals: ● Start bit ● Packet start ● Parity errors, and breaks ● Stop errors ● A serial pattern at any or a specified position 10.4.2 Reference for UART/RS-232 Interface...
Page 296 ® Protocol Analysis R&S UART / RS232 Source: Tx, Rx Select the input channels for the transmitter and receiver signals. Waveform 1 of channel signals, math waveforms, and reference waveforms can be used for decoding. For trig- gering on a serial bus, a channel signal is required. SCPI command: ...
Page 297 ® Protocol Analysis R&S UART / RS232 Bit order Defines if a word starts with msb (most significant bit) or lsb (least significant bit). The display of the decoded signal considers this setting, results are displayed in the specified order. Stop bits Sets the number of stop bits: 1 or 1.5 or 2 stop bits are possible.
Page 298 ® Protocol Analysis R&S UART / RS232 10.4.2.2 UART Trigger The "Events" tab of the "Trigger" dialog box provides the trigger settings for the configured serial buses. Make sure that: ● the trigger sequence is set to "A only" ● the trigger source is "Serial bus", and the data source(s) of the bus are channel signals ●...
Page 299 681 T RIGger<m>: U ART: D PTO 10.4.2.3 UART Decode Results (Option R&S RTO-K2) If the option is installed, the "Decode" function in the "Configuration" tab is available. Enable "Decode" to display the decoded signal below the waveforms.
Page 300 ® Protocol Analysis R&S UART / RS232 Fig. 10-9: Decoded and binary UART signal blue = start and stop bits if ok = start error, stop error, parity error orange = parity bit if ok yellow = word ok violet = word contains error The "Decode results"...
Page 301 ® Protocol Analysis R&S UART / RS232 Fig. 10-10: Decode results of the UART signal Table 10-3: Content of the "Decode results" table Column Description Source Line, Tx or Rx State Decoding state of the word. "Insuffcient waveform length" indicates that the word is not completely contained in the acquisition.
Page 302: Can (Option R&S Rto-K3)
® Protocol Analysis R&S CAN (Option R&S RTO-K3) 10.5 CAN (Option R&S RTO-K3) CAN is the Controller Area Network, a bus system used within automotive network archi- tecture. 10.5.1 Reference for CAN 10.5.1.1 CAN Configuration Make sure that the tab of the correct serial bus is selected on the left side.
Page 303 CAN node to the message. In R&S RTO, tha sample point divides the nominal bit period into two distinct time seg- ments. The length of the time segments is defined in time quanta according to network and node conditions during CAN development.
Page 304 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) To specify the bit timing, enter either "Time seg1" and "Time seg2", or directly the "Sample point". Additionally, set the "Jump width". Set the number of time quanta before the sample point (Time seg1) and "Time seg1,...
Page 305 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) Make sure that: ● the trigger sequence is set to "A only" ● the trigger source is "Serial bus", and the data source(s) of the bus are channel signals ● the correct serial bus is selected ●...
Page 306 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) "Identifier + Sets the trigger to a combination of identifier and data condition. The Data" instrument triggers at the end of the last byte of the specified data pat- tern. The identifier conditions are the same as for the "Identifier" trigger type, see ...
Page 307 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) The trigger point depends on the ID type. "Frame type" Data frames and remote frames contain an identifier. Select the frame type to be triggered on, or select "Any" if the frame type is not relevant.
Page 308 If a CAN detects a bit stuffing error, form error, or ack error, it transmits an error flag at the next bit. The R&S RTO detects errors in the message and triggers on these errors even if no CAN node sends an error flag.
Page 309 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) Fig. 10-11: Decoded and binary CAN signal, and decode results green brackets [...] = Start and end of frame green frame header = Data frame, ok cyan frame header = Remote frame, ok...
Page 310 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) Column Description Values Value of the data bytes. The data format is selected below the table. Remote frames do not transmit data, therefore "- - -" is displayed. CRC (hex) Value of the Cyclic Redundance Check (checksum), hexadecimal value SCPI commands: ●...
Page 311 ® Protocol Analysis R&S CAN (Option R&S RTO-K3) For general information on the "Translation" tab, see c hapter 10.1.3, "Protocol Translation Tables", on page 253. Example: CAN translation file # ---------------------------------------------------------------------------- # PROTOCOL TRANSLATION TABLE # ---- Format information for CAN ----...
Page 312: Lin (Option R&S Rto-K3)
● Synchronization mechanism for clock recovery by slave nodes without crystal or ceramics resonator The R&S RTO supports several versions of the LIN standard: v1.3, v2.0, v2.1 and the american SAE J2602. Data transfer Basic communication concept of LIN: ●...
Page 313: Reference For Lin
Trigger The R&S RTO can trigger on various parts of LIN frames. The data line must be con- nected to an input channel, triggering on math and reference waveforms is not possible. You can trigger on: ●...
Page 314 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) See also: c hapter 10.1.1, "Configuration - General Settings", on page 251. Data Sets the source waveform of the data line. Waveform 1 of channel signals, math wave- forms, and reference waveforms can be used for decoding. For triggering on a serial bus, a channel signal is required.
Page 315 Protocol Analysis R&S LIN (Option R&S RTO-K3) To select a bit rate from list of predefined values, tap the icon beside the "Bit rate" field. To enter a specific value, open the keypad. The list of predefined values is also available in the keypad.
Page 316 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) Make sure that: ● the trigger sequence is set to "A only" ● the trigger source is "Serial bus", and the data source(s) of the bus are channel signals ● the correct serial bus is selected ●...
Page 317 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) "Frame ID min / Defines the bit pattern of the slave identifier. Enter only the 6 bit identifier Frame ID" without parity bits, not the protected identifier. In binary format, use the following characters: 1; 0; or X (don't care).
Page 318 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) "Data length" Sets the length of the bit pattern to be found, in bytes. For "Big Endian" transfer direction, you can trigger on a number of bytes less than the data length of the frame, that means, on the beginning of the data pattern.
Page 319 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) SCPI command: on page 709 T RIGger<m>: L IN: C HKSerror on page 709 T RIGger<m>: L IN: E RRPattern on page 710 T RIGger<m>: L IN: C RCDatalen...
Page 320 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) Fig. 10-13: Decoded and binary LIN signal, and decode results green brackets [...] = start and end of frame green frame header = frame state is ok red frame header = error in frame...
Page 321 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) Column Description Values Value of the data bytes. The data format is selected below the table. Chks (hex) Checksum value SCPI commands: ● on page 710 B US<m>: L IN: F COunt...
Page 322 ® Protocol Analysis R&S LIN (Option R&S RTO-K3) For general information on the "Translation" tab, see c hapter 10.1.3, "Protocol Translation Tables", on page 253. Example: LIN translation file # ---------------------------------------------------------------------------- # PROTOCOL TRANSLATION TABLE # ---- Format information for LIN ---- # Column order and content: ID Value (6 bit,address, integer), Data length (0...8),...
Page 323: Flexray (Option R&S Rto-K4)
700 B US<m>: C AN: F RAMe<n>: T RANslation 10.7 FlexRay (Option R&S RTO-K4) FlexRay is designed for use in safety-related distributed applications in the automotive industry. It is applied in real-time applications when higher data rates and reliable com- munication are required.
Page 324 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Source type Sets the type of measurement. The instrument adjusts the thresholds to the selected source type. "Single-ended" For measurements with single-ended probes, or single-ended voltage measurements with differential probes on the FlexRay bus. Two thresh- olds have to be defined as absolute voltage levels.
Page 325 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Idle Idle Threshold high Bus plus 2.5 V Threshold low Threshold high Bus minus 2.5 V Threshold low Threshold high BP - BM Threshold low For measurements inside the FlexRay node (with "Source type" = "Logic"), each line requires its threshold level.
Page 326 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Bit rate Selects the number of transmitted bits per second from a list. SCPI command: on page 721 B US<m>: F LXRay: B ITRate Channel Selects the FlexRay channel on which the signal is measured, either cahnnel A or channel B.
Page 327 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) "Error condi- Triggers on one or more errors that are detected in the decoded data, see tion" " Error conditions" on page 314. SCPI command: on page 722 T RIGger<m>: F LXRay: T YPE...
Page 328 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) The maximum length of the pattern is 11 bit. The bit pattern editor helps you to enter the pattern in any format, see c hapter 10.1.4, "Bit Pattern Editor", on page 255.
Page 329 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Position, Index (min, max) - Data setup Sets the position of the first byte of data bit pattern within the payload segment. You can define an exact position, or a position range.
Page 330 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Error conditions Triggers on one or more errors in the frame. Trigger type: "Error conditions" "FSS" Error in a Frame Start Sequence. FSS follows the Transmission Start Sequence TSS at the beginning of each frame.
Page 331 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Fig. 10-15: FlexRay - decoded static slot Data is decoded and displayed in the order of its reception. The "Decode results" box shows the detailed decoded data for each frame as it is received.
Page 332 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) Fig. 10-16: FlexRay - decoded dynamic slot and results table Table 10-6: Content of the "Decode results" table Column Description State Overall state of the frame. "Insuffcient waveform length" indicates that the frame is not completely contained in the acquisition.
Page 333 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) ● on page 734 B US<m>: F LXRay: F RAMe<n>: D ATA ● on page 734 B US<m>: F LXRay: F RAMe<n>: A DID ● on page 736 B US<m>: F LXRay: F RAMe<n>: C SSTate...
Page 334 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) For general information on the "Translation" tab, see c hapter 10.1.3, "Protocol Translation Tables", on page 253. Example: FlexRay translation file # ---------------------------------------------------------------------------- # PROTOCOL TRANSLATION TABLE # ---- Format information for FlexRay ---- # Column order and content: ID Value (12 bit, slot number, integer), Base cycle (0,1,...,63),...
Page 335 ® Protocol Analysis R&S FlexRay (Option R&S RTO-K4) SCPI command ● on page 738 B US<m>: F LXRay: F RAMe<n>: T RANslation User Manual 1316.0827.02 ─ 06...
Page 336: Mixed Signal Option (Mso, R&S Rto-B1)
R&S 11 Mixed Signal Option (MSO, R&S RTO-B1) The Mixed Signal Option R&S RTO-B1 adds logic analyzer functions to the classical oscilloscope functions. Using the MSO option, you can analyze and debug embedded systems with mixed-signal designs that use analog signals and correlated digital signals simultaneously.
Page 337: About Mso
® Mixed Signal Option (MSO, R&S RTO-B1) R&S About MSO 11.1 About MSO The Mixed Signal Option provides 16 digital channels grouped in two logic probes (pods) with 8 channels each. The instrument ensures that analog and digital waveforms are time- aligned and synchronized so that critical timing interactions between analog and digital signals can be displayed and tested.
Page 338 ® Mixed Signal Option (MSO, R&S RTO-B1) R&S About MSO Display You can adjust the display of the parallel bus signals and the individual digital channels to optimize the analysis of bus data: ● show the digital channels which are assigned to the bus, and drag them to the optimal position ●...
Page 339 ® Mixed Signal Option (MSO, R&S RTO-B1) R&S About MSO For details, see: c hapter 11.3.4, "Trigger Settings for Digital Signals and Parallel Buses", on page 332. Additionally, you can define trigger holdoff conditions in the "Sequence" tab. See also: ...
Page 340: Analyzing Digital Signals
Data", on page 345 ● c hapter 12.2.1.3, "Waveforms", on page 351 11.2 Analyzing Digital Signals This chapter provides step-by-step procedures for working with the MSO R&S RTO-B1 option. ● Using Digital Probes....................324 ● Configuring Digital Channels and Parallel Buses..........325...
Page 341: Configuring Digital Channels And Parallel Buses
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Analyzing Digital Signals 4. Connect the grabber to a node in the circuit you want to test. 5. For high-speed signals, connect a ground lead to the probe lead, and connect the ground lead to ground in the device under test.
Page 342: Setting The Logical Thresholds
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Analyzing Digital Signals 2. Check the signal icon of the bus to monitor the activities on the digital channels even if they are not displayed in the diagram: ● blue: channel is low ●...
Page 343: Performing Measurements On Digital Signals
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Analyzing Digital Signals ● a logic combination of digital channels: "Logic" ● one of the parallel buses "Par. bus1" ... "Par. bus4" 3. Select the trigger "Type". 4. Under "Trigger type dependent settings", configure the trigger.
Page 344: Reference For Mso
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO 11.3 Reference for MSO ● Configuration....................328 ● Display......................332 ● MSO Digital Probes....................332 ● Trigger Settings for Digital Signals and Parallel Buses.........332 ● Resolution....................342 11.3.1 MSO Configuration Access: "Protocol" menu > "Parallel buses" or "Vertical" menu > "Digital Channels"...
Page 345: Enable Bus
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO └ D0-D7, D8-D15.....................331 └ Deskew offset....................331 Threshold setup......................331 Enable bus Enables the selected parallel bus. The corresponding signal icon appears on the signal bar. SCPI command: on page 740 B US<m>:...
Page 346: Bus Clocked
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO "Analog" Displays the bus values as signal amplitudes, similar to an analog waveform. Thus, a quasi-analog waveform is created. SCPI command: on page 741 B US<m>: P ARallel: D ISPlay: B TYP...
Page 347 ® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO D0-D7, D8-D15 ← Signal selection The buttons select or deselect all digital channels of a pod at once. Deskew offset ← Signal selection Sets a general delay for all digital channels. The resulting deskew of a digital channel is the sum of the general "Deskew offset"...
Page 348: Mso Display
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO 11.3.2 MSO Display Access: "Protocol" menu > "Parallel buses" > "Display" tab The Display tab provides settings for clocked buses and analog bus display. Show decode table The setting is relevant only for clocked buses to check the data words. If enabled, a results box opens with decoded values of the bus signal and its time.
Page 349: Edge
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO Make sure that the trigger sequence is set to "A only". Additionally, you can define trigger holdoff conditions in the "Sequence" tab. See also: "Holdoff mode" on page 81.
Page 350: Width
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO Fig. 11-2: Edge trigger settings for trigger source = logical combination of digital channels (Logic) Slope Defines the edge - the state transition - of the signal. "Rising" Means a 0 to 1 transition of the state.
Page 351 ® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO "Within" Triggers on pulses inside a given time range. The time limit is defined ± Delta. by Width "Outside" Triggers on pulses shorter or longer than a given time range. The time limit definition is the same as for "Within"...
Page 352: Timeout
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO 11.3.4.4 Timeout The timeout trigger event checks if the trigger source signal stays above or below the threshold voltage for a specified time lapse. In other words, the event occurs if the state condition remains unchanged for the specified time.
Page 353: Data2Clock
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO 11.3.4.5 Data2Clock The Data2Clock trigger event occurs when the state of the trigger source signal changes inside a given time before the clock edge (setup time) or after the clock edge (hold time).
Page 354: State
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO The hold time can be negative. In this case, the hold time ends before the clock edge, and the setup interval ends when the hold interval starts. Thus, the setup time is always positive.
Page 355: Pattern
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO Logical expression Defines a logic combination of several digital channels as trigger condition if "Logic" is set for "Source". The "Qualification Editor" supports the entry of the expression. SCPI command: ...
Page 356 ® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO "Off" No timing condition, only the logical pattern condition is relevant. "Timeout" Defines a minimum time qualification to avoid triggering on unstable or transitional conditions. Even in best-designed systems, there are slight delays between the signal when digital signals change states.
Page 357: Serial Pattern
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO "Longer" Triggers when the pattern comes false after the given "Width" has expired.. SCPI command: on page 751 T RIGger<m>: P ARallel: P ATTern: W IDTh: R ANGe...
Page 358: Mso Resolution
® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO Clock edge Sets the edge of the clock signal. The bit value is determined at the crossing of the clock edge and the logical threshold. SCPI command: on page 752 T RIGger<m>:...
Page 359 ® Mixed Signal Option (MSO, R&S RTO-B1) R&S Reference for MSO Dig. resolution, Dig. record length The parameter show the current digital record length used by each digital channel, and the digital resolution of the digital channels. The maximum digital record length is always 200 MSa per digital channel.
Page 360: Data And Results Management
Settings................357 12.1 Saving, Loading and Printing Data After a measurement with the R&S RTO you would usually like to save the results for further evaluation or comparison. You can save the results of a measurement as a data file containing the waveform data, or print or save the current measurement display to a printer or a file.
Page 361: Saving And Loading Waveform Data
12.1.2 Saving and Loading Waveform Data You can save the data of one channel, math or reference waveform to an .xml, .csv, or .bin file. Files in .bin format can be reloaded to the R&S RTO as reference wave- forms.
Page 362: Saving And Loading Settings
® Data and Results Management R&S Saving, Loading and Printing Data Tap "Save As" to save the waveform data to a different file or file type. Select the file from the file selection dialog box. To export waveform data of a running acquisition 1.
Page 363 3. Select the "Settings" tab. 4. Tap the required "Recall" button in the "Quick savesets" area. The saved settings are loaded to the R&S RTO. Restoring Default Settings After loading saved instrument settings, you can restore the default settings by pressing the PRESET key or the "Factory Defaults"...
Page 364: Restoring Settings
The instrument settings are reset to their default values, the user-specific settings are reset to the values saved in the SaveSet. To restore all settings on the R&S RTO to the factory-defined values ► Tap the "Factory Reset" button. All settings on the R&S RTO are reset to their factory-defined values.
Page 365: Defining Default File Paths And Names
® Data and Results Management R&S Reference for FILE Settings 12.1.5 Defining Default File Paths and Names When a save or load operation is performed, a default file name and path is provided. You can configure which path is used and how the file name is generated. In the file selection dialog box you can change the folder and name as desired.
Page 366: Save/Recall
® Data and Results Management R&S Reference for FILE Settings ● Save/Recall......................350 ● Autonaming......................354 ● User-defined Preset....................355 ● File Selection Dialog.....................355 12.2.1 Save/Recall In this tab you define the storage settings for each type of data to be saved. ● Settings.........................350 ●...
Page 367 ® Data and Results Management R&S Reference for FILE Settings "Save As..." Opens the file selection dialog box and saves the data to the selected file. ".dfl/.xml" Selects the file format. "Delete" Deletes the selected file. Quick savesets A saveset stores the current measurement and instrument settings at the touch of a but- ton, and reloads them in the same way.
Page 368 ® Data and Results Management R&S Reference for FILE Settings See also: . c hapter 12.1.2, "Saving and Loading Waveform Data", on page 345. Source Selects the source waveform for export from the active waveforms of input channels, math signals and reference waveforms. If an MSO option is installed, you can save also digital channels and parallel buses.
Page 369 ® Data and Results Management R&S Reference for FILE Settings "Manual" Saves the data between user-defined "Start" and "Stop" values. SCPI command: on page 760 E XPort: W AVeform: S COPe on page 761 E XPort: W AVeform: S TARt ...
Page 370: Autonaming
® Data and Results Management R&S Reference for FILE Settings ".bin/.xml/.csv" Selects the file format. Note that reference waveforms can be loaded from .bin files only. SCPI command: on page 762 E XPort: W AVeform: N AME on page 762 E XPort:...
Page 371: User-Defined Preset
® Data and Results Management R&S Reference for FILE Settings 12.2.3 User-defined Preset A user-defined preset contains the complete instrument setup including display settings, except for transparency and intensity. You can save the current configuration to a preset file, and load a previously saved preset file. You can then specify that these settings are to be applied, in addition to the standard instrument settings, with the PRESET function.
Page 372 ® Data and Results Management R&S Reference for FILE Settings Path Tap the path to change the current folder. The default folder is defined in " Default path for all file operations" on page 354. You can save the data in a local folder on the instrument, to an external storage device (usually a USB flash drive), or to an folder on a connected network drive.
Page 373: Reference For Print Settings
® Data and Results Management R&S Reference for PRINT Settings File Name The file name to be loaded or stored to. Double-tap the file name to open the file selection dialog and select a different file name, or enter the file name directly using the online keyboard.
Page 374 Selects a configured printer. You can use a local printer or a network printer. To make a printer available for R&S RTO, add and configure it in the Windows XP "Printers and Faxes" window. The instrument firmware uses the Windows printer configuration, no additional printer setup is required.
Page 375 ® Data and Results Management R&S Reference for PRINT Settings Update image Updates the preview of the print image with the current display view, e.g. after changes to the settings have been made or an additional channel has been activated. Inverse color Inverts the colors of the output, i.e.
Page 376: General Instrument Setup
® General Instrument Setup R&S Setting Up the Instrument 13 General Instrument Setup Some basic instrument settings concerning the user interface and general system are configurable and may need to be adapted to your specific requirements. Furthermore, the input channels may need to be aligned. 13.1 Setting Up the Instrument The following procedures for the general instrument setup are described in the "Getting Started"...
Page 377 ® General Instrument Setup R&S Reference for General Instrument Settings Firmware version Indicates the firmware version currently installed on the instrument. SCPI command: on page 768 D IAGnostic: S ERVice: F WVersion Bios version Indicates the bios version currently installed on the instrument. Image version Indicates the image version currently installed on the instrument.
Page 378 ® General Instrument Setup R&S Reference for General Instrument Settings System Opens the standard Windows "System Properties" dialog box to configure system set- tings. Network Opens the standard Windows "Network Connections" dialog box to configure a network. Screensaver Opens the standard Windows "Display Properties" dialog box to configure a screensaver. Time, date Opens the standard Windows "Date and Time Properties"...
Page 379 ® General Instrument Setup R&S Reference for General Instrument Settings Click capture area size Defines the number of pixels around each element (e.g. button, icon, data point) that create a capture area. If you tap your finger or click the mouse pointer within this capture area, this element is considered to be selected.
Page 380 ® General Instrument Setup R&S Reference for General Instrument Settings Dialog transparency Defines the transparency of the dialog box background. For high transparency values, you can see the waveform display in the background, and possibly check the effect of the changed setting. For lower transparency values, readability in the dialog box improves.
Page 381 ® General Instrument Setup R&S Reference for General Instrument Settings 13.2.1.3 SW Options This tab provides information on installed software options and functions to install new options via license keys. The "State" of the option indicates whether the installed option is an official or merely a beta-release version.
Page 382 ® General Instrument Setup R&S Reference for General Instrument Settings Install from file Alternatively to entering the option key manually, it can be read from a special option file provided with the option. Load ← Install from file Loads the specified file. Open ←...
Page 383 The settings are only relevant if the SCPI emulation mode is set to Tektronix emulation (requires option R&S RTO-K301). 13.2.1.6 This tab provides settings for LXI, which allows you to connect your R&S RTO to other devices in a network. For details, see c hapter 14.4.2, "LXI Configuration", on page 379.
Page 384: Front Panel Setup
"MAC address" Media Access Control address (MAC address), a unique identifier for the network card in the R&S RTO "IP address" IP address of the R&S RTO as defined in the operating system. "Auto MDIX" Enables the use of the built-in Auto-MDI(X) Ethernet functionality.
Page 385: Self-Alignment
® General Instrument Setup R&S Reference for General Instrument Settings LCD Intensity Changes the background luminosity of the touch screen. LED Intensity Defines the luminosity of illuminated front panel keys and rotary knobs. 13.2.3 Self-alignment When data from several input channels is displayed at the same time, it may be necessary to align the data vertically or horizontally in order to synchronize the time bases or ampli- tudes and positions.
Page 386 ® General Instrument Setup R&S Reference for General Instrument Settings User Manual 1316.0827.02 ─ 06...
Page 387: Software And Network Operation
14 Software and Network Operation 14.1 Operating System The R&S RTO contains the Windows XP operating system which has been configured according to the instrument's features and needs. To ensure that the instrument software functions properly, certain rules must be adhered to when using the operating system.
Page 388: Logon
c hapter 14.4.1.1, "Connecting the Instrument to the Network", on page 377). After the R&S RTO is started, the operating system boots and the instrument firmware is started automatically. 14.1.3 Logon Windows XP requires that users identify themselves by entering a user name and pass- word in a logon window.
Page 389: Firmware Update
14.2 Firmware Update The firmware on your R&S RTO may need to be updated in order to enable additional new features or if reasons for improvement come up. Ask your sales representative or check the Rohde&Schwarz website for availability of firmware updates. A firmware update package includes at least a setup file and release notes.
Page 390: Software Options
"Setting Up the Instrument". 14.3 Software Options Additional options for the R&S RTO can be enabled using a license key. To obtain the license key, consult your sales representative. You need the material number and serial number of your instrument to get a license key. No additional installation is required.
Page 391: Mode
® Software and Network Operation R&S Software Options To install an option using a license key 1. Press the SETUP key and select the "SW options" tab. 2. If you received a key in written form, enter the key in the "Enter new option key" field. If you received a key in digital form as a file, enter the path and file name in the "Install from file"...
Page 392: Operation In A Network
Network", on page 377 ● c hapter 14.4.1.2, "Assigning the IP Address", on page 377 The R&S RTO complies with LXI Class C. LXI gives you direct access to the LAN settings described below. User Manual 1316.0827.02 ─ 06...
Page 393 ® Software and Network Operation R&S Operation in a Network 14.4.1.1 Connecting the Instrument to the Network There are two methods to establish a LAN connection to the instrument: ● A non-dedicated network (Ethernet) connection from the instrument to an existing network made with an ordinary RJ-45 network cable.
Page 394 ® Software and Network Operation R&S Operation in a Network Risk of network errors Connection errors can affect the entire network. If your network does not support DHCP, or if you choose to disable dynamic TCP/IP configuration, you must assign valid address information before connecting the instrument to the LAN.
Page 395: Lxi Configuration
® Software and Network Operation R&S Operation in a Network Note that changing firewall settings requires administrator rights. 14.4.2 LXI Configuration LAN eXtensions for Instrumentation (LXI) is an instrumentation platform for measuring instruments and test systems that is based on standard Ethernet technology. LXI is intended to be the LAN-based successor to GPIB, combining the advantages of Ethernet with the simplicity and familiarity of GPIB.
Page 396 Software and Network Operation R&S Operation in a Network The R&S RTO complies with LXI Class C. In addition to the general class C features described above, it provides the following LXI-related functionality: ● Integrated "LXI Configuration" dialog box for LXI activation and reset of the LAN con- figuration (LAN Configuration Initialize, LCI).
Page 397 ► Press the "Device Indicator" button to activate or deactivate the LXI status icon on the toolbar of the R&S RTO. A green LXI status symbol indicates that a LAN con- nection has been established; a red symbol indicates an error, for exmaple, that no LAN cable is connected.
Page 398 ® Software and Network Operation R&S Operation in a Network 14.4.2.4 LAN Configuration The LAN configuration consists of three parts: ● "IP configuration" provides all mandatory LAN parameters. ● "Advanced LAN Configuration" provides LAN settings that are not declared manda- tory by the LXI standard.
Page 399 ® Software and Network Operation R&S Operation in a Network Advanced LAN Configuration The "LAN Configuration > Advanced LAN Configuration" parameters are used as follows: ● The "Negotiation" configuration field provides different Ethernet speed and duplex mode settings. In general, the "Auto Detect" mode is sufficient. ●...
Page 400 ® Software and Network Operation R&S Operation in a Network 3. Click "Submit". User Manual 1316.0827.02 ─ 06...
Page 401: Maintenance
To protect the front panel and to transport the instrument to another workplace safely and easily, two accessories are provided: ● Soft case (R&S RTO-Z3, order number 1304.9118.02) ● Front cover (R&S RTO-Z1, order number 1304.9101.02) Follow the instructions in the service manual and the safety instructions when exchanging modules or ordering spares.
Page 402: Troubleshooting With Rtoservicereporter
In case of a firmware failure, contact one of the Rohde & Schwarz support centers and send the report file for fast problem analysis. 1. On the R&S RTO display, open the "File" menu and tap "Minimize Application". 2. On the Windows desktop, execute the "RTOServiceReporter".
Page 403: Reference For Maintenance Settings
15.6 Reference for Maintenance Settings 15.6.1 Board Detection/Maintenance The "Board Detection/Maintenance" dialog box in the "File" menu provides service infor- mation for your R&S RTO. In case you require support, you may be asked to provide this information. 15.6.1.1 System Info This tab provides general information on the hardware configuration, and indicates where system information can be found on the instrument.
Page 404 ® Maintenance R&S Reference for Maintenance Settings Selftest Starts the selftest. SCPI command: on page 426 * TST State Shows the summary result of the selftest: Pass or Fail. SCPI command: on page 771 D IAGnostic: S ERVice: S TST: S TATe Result Opens a log file with detailed information on the selftest steps and hardware components operation.
Page 405: Remote Control
® Remote Control R&S Basics 16 Remote Control 16.1 Basics This chapter provides basic information on operating an instrument via remote control. 16.1.1 Remote Control Interfaces and Protocols The instrument supports different interfaces for remote control. The following table gives an overview.
Page 406 IP address identifies the instrument in the network ● inst0 is the LAN device name. VISA supports several devices running on the instru- ment. On R&S RTO, only one device is configured, so the LAN device name can be omitted. ●...
Page 407: Starting And Stopping Remote Control
® Remote Control R&S Basics The TCP/IP network protocol and the associated network services are preconfigured. TCP/IP ensures connection-oriented communication, where the order of the exchanged messages is adhered to and interrupted links are identified. With this protocol, messages cannot be lost. 16.1.1.3 GPIB Interface (IEC/IEEE Bus Interface) To be able to control the instrument via the GPIB bus, the instrument and the controller...
Page 408: Messages
® Remote Control R&S Basics 16.1.2.2 Using the display during remote control You can observe the screen while a remote control script is executed. This is helpful for program test purposes but tends to slow down the measurement. Therefore it is recom- mended that you switch off the display in real measurement applications where a tested program script is to be executed repeatedly.
Page 409 ® Remote Control R&S Basics – Common commands: their function and syntax are precisely defined in standard IEEE 488.2. They are employed identically on all instruments (if implemented). They refer to functions such as management of the standardized status registers, reset and self test.
Page 410 ® Remote Control R&S Basics Command Effect on the instrument LLO (Local Lockout) The LOC/IEC ADDR key is disabled. SPE (Serial Poll Enable) Ready for serial poll. SPD (Serial Poll Disable) End of serial poll. PPU (Parallel Poll Unconfig- End of the parallel-poll state. ure) *) IFC is not a real universal command, it is sent via a separate line;...
Page 411: Scpi Command Structure
® Remote Control R&S Basics Command Long term Effect on the instrument &NREN Not Remote Enable Enables switchover from remote control to manual opera- tion by means of the front panel keys &POL Serial Poll Starts a serial poll. 16.1.4 SCPI Command Structure SCPI commands consist of a so-called header and, in most cases, one or more param- eters.
Page 412 ® Remote Control R&S Basics 16.1.4.2 Syntax for Device-Specific Commands Not all commands used in the following examples are necessarily implemented in the instrument. For demonstration purposes only, assume the existence of the following commands for this section: ● DISPlay[:WINDow<1...4>]:MAXimize <Boolean> ●...
Page 413 ® Remote Control R&S Basics Example: Definition: HCOPy:PAGE:DIMensions:QUADrant[<N>] Command: HCOP:PAGE:DIM:QUAD2 This command refers to the quadrant 2. Different numbering in remote control For remote control, the suffix may differ from the number of the corresponding selection used in manual operation. SCPI prescribes that suffix counting starts with 1. Suffix 1 is the default state and used when no specific suffix is specified.
Page 414 ® Remote Control R&S Basics Special characters Parameters A vertical stroke in parameter definitions indicates alternative possibilities in the sense of "or". The effect of the command differs, depending on which parameter is used. Example: Definition:HCOPy:PAGE:ORIentation LANDscape | PORTrait Command HCOP:PAGE:ORI LAND specifies landscape orientation Command HCOP:PAGE:ORI PORT specifies portrait orientation Mnemonics A selection of mnemonics with an identical effect exists for several commands.
Page 415 ® Remote Control R&S Basics Numeric values Numeric values can be entered in any form, i.e. with sign, decimal point and exponent. Values exceeding the resolution of the instrument are rounded up or down. The mantissa may comprise up to 255 characters, the exponent must lie inside the value range -32000 to 32000.
Page 416 ® Remote Control R&S Basics INFinity, Negative INFinity (NINF) represent the numeric values 9.9E37 or -9.9E37, respectively. INF and NINF are only sent as instrument responses. ● Not A Number (NAN) represents the value 9.91E37. NAN is only sent as a instrument response.
Page 417 ® Remote Control R&S Basics Example: HCOP:ITEM:LABel "Test1" or HCOP:ITEM:LABel 'Test1' Block data Block data is a format which is suitable for the transmission of large amounts of data. A command using a block data parameter has the following structure: Example: FORMat:READings:DATA #45168xxxxxxxx...
Page 418 ® Remote Control R&S Basics ● a <New Line> with EOI ● an EOI together with the last data byte Several commands in a command line must be separated by a semicolon ";". If the next command belongs to a different command system, the semicolon is followed by a colon. Example: MMEM:COPY "Test1","MeasurementXY";:HCOP:ITEM ALL This command line contains two commands.
Page 419: Command Sequence And Synchronization
® Remote Control R&S Basics Example: Setting command: HCOPy:DEV:COL ON Query: HCOPy:DEV:COL? Response: 1 ● Text (character data) is returned in a short form. Example: Setting command: HCOPy:PAGE:ORIentation LANDscape Query: HCOP:PAGE:ORI? Response: LAND 16.1.5 Command Sequence and Synchronization IEEE 488.2 defines a distinction between overlapped and sequential commands: ●...
Page 420 ® Remote Control R&S Basics Example: Overlapping command with *OPC The instrument implements SINGle as an overlapped command. Assuming that SINGle takes longer to execute than *OPC, sending the following command sequence results in initiating a sweep and, after some time, setting the OPC bit in the ESR: SINGle;...
Page 421: Status Reporting System
® Remote Control R&S Basics 4. Wait for a service request The service request indicates that the overlapped command has finished. *OPC? with a service request 1. Set bit no. 4 in the SRE: *SRE 16 to enable MAV service request. 2.
Page 422 ® Remote Control R&S Basics 16.1.6.1 Structure of a SCPI Status Register Each standard SCPI register consists of 5 parts. Each part has a width of 16 bits and has different functions. The individual bits are independent of each other, i.e. each hardware status is assigned a bit number which is valid for all five parts.
Page 423 ® Remote Control R&S Basics This part can be written into and read as required. Its contents are not affected by reading. ● EVENt The EVENt part indicates whether an event has occurred since the last reading, it is the "memory" of the condition part. It only indicates events passed on by the transition filters.
Page 424 ® Remote Control R&S Basics Fig. 16-2: Overview of the status registers hierarchy ● STB, SRE The STatus Byte (STB) register and its associated mask register Service Request Enable (SRE) form the highest level of the status reporting system. The STB provides a rough overview of the instrument status, collecting the information of the lower-level registers.
Page 425 ® Remote Control R&S Basics The IST flag ("Individual STatus"), like the SRQ, combines the entire instrument status in a single bit. The PPE fulfills the same function for the IST flag as the SRE for the service request. ● Output buffer The output buffer contains the messages the instrument returns to the controller.
Page 426 ® Remote Control R&S Basics Bit No. Meaning MAV bit (message available) The bit is set if a message is available in the output buffer which can be read. This bit can be used to enable data to be automatically read from the instrument to the controller. ESB bit Sum bit of the event status register.
Page 427 ® Remote Control R&S Basics Bit No. Meaning Device-dependent Error This bit is set if a device-dependent error occurs. An error message with a number between -300 and -399 or a positive error number, which denotes the error in greater detail, is entered into the error queue.
Page 428 ® Remote Control R&S Basics Fig. 16-3: Overview of the STATus:QUEStionable register Table 16-6: Bits in the STATus:QUEStionable register Bit No. Meaning 0 to 2 not used COVerload This bit is set if a questionable channel overload occurs (see "...
Page 429 ® Remote Control R&S Basics Bit No. Meaning NOALigndata This bit is set if no alignment data is available - the instrument is uncalibrated. LIMit This bit is set if a limit value is violated (see " STATus:QUEStionable:LIMit, STATus:QUEStiona- ble:MARGin, STATus:QUEStionable:LAMP registers"...
Page 430 ® Remote Control R&S Basics or additional measurement of assigned measurement are violated. The LAMP (Low AMPlitude) bit is set if the magnitude of the signal is too low to get reliable measurement results. Table 16-9: Bits in the STATus:QUEStionable:LIMit, STATus:QUEStionable.MARGin, and STA- Tus:QUEStionable:AMP registers Bit No.
Page 431 ® Remote Control R&S Basics ● Query of a specific instrument status by means of commands ● Query of the error queue Service Request Under certain circumstances, the instrument can send a service request (SRQ) to the controller. Usually this service request initiates an interrupt at the controller, to which the control program can react appropriately.
Page 432 ® Remote Control R&S Basics Query of an instrument status Each part of any status register can be read using queries. There are two types of com- mands: ● The common commands *ESR?, *IDN?, *IST?, *STB? query the higher-level reg- isters.
Page 433: General Programming Recommendations
® Remote Control R&S Basics SYSTem:PRESet, influence the functional instrument settings. In particular, DCL does not change the instrument settings. Table 16-11: Resest of the status reporting system Event Switching on supply DCL, SDC *RST or STA- *CLS voltage SYS- Tus:PRE- (Device Tem:PRE-...
Page 434: Command Reference
16.2 Command Reference This chapter provides the description of all remote commands available for R&S RTO. 16.2.1 Finding the Appropriate Command In the following chapters, the commands are sorted according to the menu and dialog structure of the instrument.
Page 435 26...34 Measurement results: MRESult1, MRESult2, MRESult3, MRESult4, MRESult5, MRESult6, MRESult7, MRESult8 34 = IMResult, result of immediate measurements available on Tektronix instru- ments. Only relevant for Tektronix emulation (option R&S RTO-K301) 35...38 Serial buses: SBUS1, SBUS2, SBUS3, SBUS4 39...54 Digital channels: D0...D15 (option R&S RTO-B1) 55...58...
Page 436 Serial buses D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D9 | Digital channels (option R&S RTO-B1) D10 | D11 | D12 | D13 | D14 | D15 MSOB1 | MSOB2 | MSOB3 | MSOB4 Digital buses (option R&S RTO-B1)
Page 437 ® Remote Control R&S Command Reference Polarity Description POSitive Positive going pulses. NEGative Negative going pulses. EITHer Both positive and negative going pulses. 16.2.2.5 Event Parameter The event parameter is used with commands defining an action for mask testing, limit checks and margin checks.
Page 438: Common Commands
® Remote Control R&S Command Reference Usually, address and identifier parameter require unique patterns while data paramters may contain wildcards. Query for a pattern The pattern format for the return value of a pattern is defined by the F ORMat: command.
Page 439 IDeNtification: returns the instrument identification. Return values: <ID> "Rohde&Schwarz,<device type>,<serial number>,<firmware ver- sion>" Example: Rohde&Schwarz,RTO,1316.1000k14/200153,1.30.0.25 Usage: Query only *IST? Individual STatus query Returns the contents of the IST flag in decimal form. The IST flag is the status bit which is sent during a parallel poll.
Page 440 ® Remote Control R&S Command Reference Sets bit 0 in the event status register when all preceding commands have been executed. This bit can be used to initiate a service request. The query form writes a "1" into the output buffer as soon as all preceding commands have been executed. This is used for command synchronization.
Page 441 ® Remote Control R&S Command Reference Parameters: <Action> 0 | 1 The contents of the status registers are preserved. Resets the status registers. *RCL <Number> ReCaLl calls up the instrument settings from an intermediate memory identified by the specified number. The instrument settings can be stored to this memory using the com- mand ...
Page 442: General Remote Settings
® Remote Control R&S Command Reference Usage: Query only *TRG TRiGger Triggers all actions waiting for a trigger event. In particular, *TRG generates a manual trigger signal (Manual Trigger). This common command complements the commands of the TRIGger subsystem. Usage: Event *TST? self TeST query...
Page 443: Acquisition And Setup
DPO7000 or TDS540 is used. If one of these emulation modes is used, you can define alternative responses to the IDN*? and OPT*? commands on the SETUP > "Remote settings" tab. SCPI R&S RTO remote command set is used. *RST: SCPI Firmware/Software: V 1.35 Options: R&S RTO-K301...
Page 444 ® Remote Control R&S Command Reference ● Probes........................441 ● Digital Filter......................450 ● Skew........................451 ● Reference (OCXO Option R&S RTO)-B4.............452 16.2.5.1 Starting and Stopping Acquisition .......................428 RUNContinous ..........................428 RUN ........................428 RUNSingle ..........................428 SINGle ...........................428 STOP RUNContinous Starts the continuous acquisition.
Page 445 ® Remote Control R&S Command Reference TIMebase:SCALe <TimeScale> Sets the horizontal scale - the time per division on the x-axis - for all channel and math waveforms. The setting accuracy depends on the current resolution (sample rate) and the setting for resolution enhancement: ●...
Page 446 ® Remote Control R&S Command Reference Parameters: <Offset> Range: -500 to 500 Increment: 0.01 *RST: Default unit: s TIMebase:REFerence <ReferencePoint> Sets the reference point of the time scale in % of the display. The reference point defines which part of the waveform is shown. If the "Trigger offset" is zero, the trigger point matches the reference point.
Page 447 ® Remote Control R&S Command Reference ....................432 ACQuire: P OINts: A RATe ......................432 ACQuire: S RATe .......................432 ACQuire: R ESolution ....................432 ACQuire: P OINts[: V ALue] ......................433 ACQuire: M ODE ......................433 ACQuire: I NTerpolate .
Page 448 ® Remote Control R&S Command Reference ACQuire:POINts:ARATe? Retrieves the sample rate of the ADC, that is the number of points that are sampled by the ADC in one second. Return values: <ADCSampleRate> Range: 10 to 20E+9 Increment: 1 *RST: 10E+9 Default unit: Hz Usage: Query only...
Page 449 ® Remote Control R&S Command Reference ACQuire:MODE <EnhancementMode> Selects the method of adding waveform points to the samples of the ADC in order to fill the record length. See also: " Resolution enhancement" on page 32. Parameters: <EnhancementMode>RTIMe | ITIMe | ETIMe RTIMe Real Time Mode: The sampled points of the input signal are used to build the waveform, no waveform points are added.
Page 450 ® Remote Control R&S Command Reference <n> 1..3 Selects the waveform. For each channel, up to three waveforms can be analyzed. If WAVeform<n> is omitted, waveform 1 is adressed. Parameters: <State> ON | OFF *RST: CHANnel<m>[:WAVeform<n>]:TYPE <DecimationMode> Selects the method to reduce the data stream of the ADC to a stream of waveform points with lower sample rate.
Page 451 ® Remote Control R&S Command Reference <n> 1..3 Selects the waveform. For each channel, up to three waveforms can be analyzed. If WAVeform<n> is omitted, waveform 1 is adressed. Parameters: <TrArith> OFF | ENVelope | AVERage The data of the current acquisition is recorded according to the decimation settings.
Page 452 ® Remote Control R&S Command Reference Parameters: <MaxAcquisitions> ON | OFF The maximum possible number of acquisitions in a series is used. Acquires the number of acquisitions defined using A CQuire: COUNt *RST: 16.2.5.4 Vertical .....................436 CHANnel<m>: S TATe .
Page 453 ® Remote Control R&S Command Reference Parameters: <Coupling> DC | DCLimit | AC Direct connection with 50 Ωtermination. DCLimit Direct connection with 1 MΩ termination. Connection through DC capacitor. *RST: DCLimit CHANnel<m>:GND <State> Connects the signal to the ground. Suffix: <m>...
Page 454 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the input channel. Parameters: <Range> Voltage range value Range: Depends on attenuation factors and coupling. With 1:1 probe and external attenuations and 50 Ω input coupling, the range is 10 mV to 10 V. For 1 MΩ input coupling, it is 10 mV to 100 V.
Page 455 ® Remote Control R&S Command Reference Parameters: <Offset> Negative values move the waveform up, positive values move it down. Range: Depends on attenuation factors, input coupling, and the offset compensation range of active probes. The nominal offset range for 1:1 attenuation and probe offset compensation = 0 is specified in the data sheet.
Page 456 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the input channel. Parameters: <Overload> ON | OFF Use OFF to reset the overload status bit. *RST: CHANnel2:OVERload? Example: Queries the overload status of channel 2. CHANnel2:OVERload OFF Resets the overload status bit. 16.2.5.5 Waveform Data To set the export data format, see ...
Page 457 ® Remote Control R&S Command Reference CHANnel<m>[:WAVeform<n>]:DATA[:VALues]? Returns the data of the channel waveform points. The waveforms data can be used in MATLAB, for example. To set the export format, use F ORMat[: D ATA] Suffix: <m> 1..4 Selects the input channel. <n>...
Page 458 ® Remote Control R&S Command Reference ..................449 PROBe<m>: S ERVice: F W: P ATH ..................450 PROBe<m>: S ERVice: F W: F LASh ..................450 PROBe<m>: S ERVice: S TATe PROBe<m>:SETup:STATe? Queries if the probe at the specified input channel is active (detected) or not active (not detected).
Page 459 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the input channel. Parameters: <PredefinedProbe> ZC10 | ZC20 | FREE ZC10 | ZC20 Current probe R&S RT-ZC10 or R&S RT-ZC20 FREE Any other probe that is not recognized by the instrument. *RST: FREE Firmware/Software: V 1.27...
Page 460 ® Remote Control R&S Command Reference Parameters: <ProbeGainModeManual> Range: 100E-6 to 10 Increment: 0.01 *RST: Default unit: V/V PROBe<m>:SETup:MEASurement <ProbeMeterMeas> Selects the input voltage that is measured by the differential active probe. See also: " Differential active probes" on page 22. Suffix: <m>...
Page 461 ® Remote Control R&S Command Reference PROBe<m>:SETup:OFFSet:AZERo Performs an automatic correction of the zero error. If the DUT is ground-referenced, the Auto Zero function can improve the measurement results. See also: " Auto Zero, AutoZero DC offset, Use AutoZero" on page 46 Suffix: <m>...
Page 462 ® Remote Control R&S Command Reference Parameters: <Mode> RCONtinuous | RSINgle | AUToset | AZERo | SEToffsettomean | PRINt | SITFile | NOACtion RCONtinuous Run continuous: The acquisition is running as long as the probe button is pressed. RSINgle Run single: starts one acquisition. AUTOSET Starts the autoset procedure.
Page 463 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the input channel. Return values: <Name> Name string Usage: Query only PROBe<m>:SETup:IMPedance? Queries the termination of the probe. Suffix: <m> 1..4 Selects the input channel. Return values: <InputImpedance> Range: 100E-15 to 1E+9 Increment: 1E-12 *RST: Default unit: Ohm...
Page 464 ® Remote Control R&S Command Reference Return values: <Bandwidth> Range: 1E+6 to 20E+9 Increment: 10 *RST: 1E+9 Default unit: Hz Usage: Query only PROBe<m>:ID:SWVersion? Queries the version of the probe firmware. Suffix: <m> 1..4 Selects the input channel. Return values: <Softwareversion>...
Page 465 ® Remote Control R&S Command Reference Return values: <SerialNo> Serial number in a string. Usage: Query only PROBe<m>:SERVice:STESt:RUN Starts the selftest of the probe connected to the specified channel input. Suffix: <m> 1..4 Selects the input channel. Usage: Event PROBe<m>:SERVice:STESt:STATus? Queries the status of a probe selftest for the specified channel input.
Page 466 ® Remote Control R&S Command Reference Parameters: <FlashPath> String with the path and file name of the update package. PROBe<m>:SERVice:FW:FLASh Starts the update of the probe firmware. Suffix: <m> 1..4 Selects the input channel. Usage: Event PROBe<m>:SERVice:STATe? Queries the update status of the probe firmware. See also: ...
Page 467 ® Remote Control R&S Command Reference The filter value is applied to two channels in R&S RTO1022 and R&S RTO1024, or applied to all available channels in R&S RTO1012 and R&S RTO1014. Suffix: <m> 1..4 Selects the input channel. Parameters: <CutOffLP>...
Page 468 Range: -100E-9 to 100E-9 Increment: 1E-12 *RST: Default unit: s 16.2.5.9 Reference (OCXO Option R&S RTO)-B4 ..................452 SENSe[: R OSCillator]: S OURce ..............452 SENSe[: R OSCillator]: E XTernal: F REQuency SENSe[:ROSCillator]:SOURce <RefOscillatorSrc> Enables the use of the external reference signal instead of the internal OCXO reference.
Page 469: Trigger
® Remote Control R&S Command Reference 16.2.6 Trigger ● Trigger Events and Trigger Types.................453 ● Trigger Qualification....................478 ● Noise Reject......................481 ● Trigger Sequence....................483 ● Trigger Position.....................489 ● Trigger Control......................490 16.2.6.1 Trigger Events and Trigger Types ● Basic Trigger Settings...................453 ● Edge Trigger......................456 ●...
Page 470 For this source, only the analog edge trigger is available. SBUS Serial bus D0...D15 Digital channels (option R&S RTO-B1) LOGIc Logic combination of digital channels, used as trigger source (option R&S RTO-B1) MSOB1 | MSOB2 | MSOB3 | MSOB4 Parallel bus (option R&S RTO-B1)
Page 471 ® Remote Control R&S Command Reference Parameters: <Type> EDGE | GLITch | WIDTh | RUNT | WINDow | TIMeout | INTerval | SLEWrate | DATatoclock | STATe | PATTern | ANEDge | SERPattern Most of the type values are self-explanatory. DATatoclock Data2Clock: analyzes the relative timimg between a data signal and the synchronous clock signal.
Page 472 ® Remote Control R&S Command Reference TRIGger<m>:ROBust <Robust> The "robust trigger" setting is relevant for all trigger types with an event condition that is based on the time difference between a rising and a falling edge. These trigger types are: glitch, width, runt, timeout, window, data2clock, pattern, and serial pattern.
Page 473 ® Remote Control R&S Command Reference ....................459 TRIGger<m>: A NEDge: G ND ..................459 TRIGger<m>: A NEDge: S LOPe TRIGger<m>:EDGE:SLOPe <Slope> Defines the edge for the edge trigger event. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event. Parameters: <Slope>...
Page 474 ® Remote Control R&S Command Reference Parameters: <AnalogCutOffHP> KHZ5 | KHZ50 | MHZ50 Cut-off frequency KHZ5 5 kHz KHZ50 50 kHz MHZ50 50 MHz *RST: KHZ50 TRIGger<m>:ANEDge:CUToff:LOWPass <AnalogCutOffLP> Frequencies higher than the "Cut-off" frequency are rejected, lower frequencies pass the filter.
Page 475 ® Remote Control R&S Command Reference Parameters: <Filter> OFF | LFReject | RFReject The trigger signal is not filtered. LFReject Frequencies higher than the "Cut-off" frequency are rejected, lower frequencies pass the filter. You can adjust the "Cut-off" frequency using the T RIGger<m>:...
Page 476 ® Remote Control R&S Command Reference ...................460 TRIGger<m>: G LITch: W IDTh TRIGger<m>:GLITch:POLarity <Polarity> Defines the polarity of a pulse, that is the direction of the first pulse slope. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event, 3 = R-event. Parameters: <Polarity>...
Page 477 ® Remote Control R&S Command Reference Width Trigger The width trigger is not available for the B-event (Suffix = 2)..................461 TRIGger<m>: W IDTh: P OLarity ..................461 TRIGger<m>: W IDTh: R ANGe ...................462 TRIGger<m>: W IDTh: W IDTh .
Page 478 ® Remote Control R&S Command Reference TRIGger<m>:WIDTh:WIDTh <Width> For the ranges "Within" and "Outside" (defined using ) , the T RIGger<m>: W IDTh: R ANGe width defines the center of a range which is defined by the limits "±Delta" (see on page 462).
Page 479 ® Remote Control R&S Command Reference Parameters: <Polarity> POSitive | NEGative | EITHer See c hapter 16.2.2.4, "Polarity Parameter", on page 420. *RST: POSitive TRIGger<m>:LEVel<n>:RUNT:UPPer <Level> Sets the upper voltage threshold. Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event.
Page 480 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event. Parameters: <Mode> ANY | LONGer | SHORter | WITHin | OUTSide Triggers on all runts fulfilling the level condition, without time lim- itation.
Page 481 ® Remote Control R&S Command Reference Parameters: <WidthDelta> Range: 100E-12 to 864 Increment: 100E-9 *RST: 100E-12 Default unit: s Window Trigger The window trigger is not available for the B-event (Suffix = 2)................465 TRIGger<m>: L EVel<n>: W INDow: U PPer .
Page 482 ® Remote Control R&S Command Reference Parameters: <Level> Range: -10 to 10 Increment: 1E-3 *RST: -0.1 Default unit: V TRIGger<m>:WINDow:RANGe <RangeMode> Defines the signal run in relation to the window: Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event.
Page 483 ® Remote Control R&S Command Reference Parameters: <TimeRangeMode> WITHin | OUTSide | SHORter | LONGer WITHin Triggers if the signal stays inside or outside the vertical window limits at least for the time Width - Delta and for Width + Delta at the most.
Page 484 ® Remote Control R&S Command Reference Parameters: <WidthDelta> Range: 0 to 432 Increment: 500E-12 *RST: Default unit: s Timeout Trigger The timeout trigger is not available for the B-event (Suffix = 2)..................468 TRIGger<m>: T IMeout: R ANGe ....................468 TRIGger<m>:...
Page 485 ® Remote Control R&S Command Reference ..................469 TRIGger<m>: I NTerval: P OLarity ..................469 TRIGger<m>: I NTerval: R ANGe ..................469 TRIGger<m>: I NTerval: W IDTh ..................470 TRIGger<m>: I NTerval: D ELTa TRIGger<m>:INTerval:POLarity <Polarity> Indicates the polarity of a pulse, that is the direction of the first pulse slope. Suffix: <m>...
Page 486 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event. Parameters: <Width> Range: 100E-12 to 10000 Increment: 100E-9 *RST: 5E-9 Default unit: s TRIGger<m>:INTerval:DELTa <WidthDelta> Defines a range around the "Interval width"...
Page 487 ® Remote Control R&S Command Reference TRIGger<m>:LEVel<n>:SLEW:UPPer <Level> Defines the upper voltage threshold. When the signal crosses this level, the slew rate measurement starts or stops depending on the selected slope. Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event.
Page 488 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event. Parameters: <RangeMode> INSRange | OUTRange | LTHan | GTHan INSRange Triggers on pulses inside a given range. The range is defined by the slew rate ±delta.
Page 489 ® Remote Control R&S Command Reference Parameters: <TimeDelta> Range: 0 to 10 Increment: 100E-9 *RST: Default unit: s Data2Clock Trigger The Data2Clock trigger is only available for the A-event (Suffix = 1)..............473 TRIGger<m>: D ATatoclock: C SOurce[: V ALue] .
Page 490 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Indicates the event in a trigger sequence: 1 = A-event, 2 = B-event, 3 = R-event. Parameters: <ClockLevel> Range: -10 to 10 Increment: 1E-3 *RST: Default unit: V TRIGger<m>:DATatoclock:HTIMe <HoldTime> Sets the minimum time after the clock edge while the data signal must stay steady above or below the data level.
Page 491 ® Remote Control R&S Command Reference Pattern Trigger The pattern trigger is only available for the A-event (Suffix = 1)..................475 TRIGger<m>: P ATTern: M ODE ................475 TRIGger<m>: P ATTern: T IMeout: M ODE ................476 TRIGger<m>: P ATTern: T IMeout[: T IME] .
Page 492 ® Remote Control R&S Command Reference TRIGger<m>:PATTern:TIMeout[:TIME] <Time> Defines how long the result of the pattern condition must be true or false. Suffix: <m> 1..3 1 = A-event only Parameters: <Time> Range: 100E-12 to 10000 Increment: 100E-9 *RST: 100E-9 Default unit: s TRIGger<m>:PATTern:WIDTh:RANGe <WidthRangeMode>...
Page 493 ® Remote Control R&S Command Reference Parameters: <Width> Range: 100E-12 to 10000 Increment: 100E-9 *RST: 5E-9 Default unit: s TRIGger<m>:PATTern:WIDTh:DELTa <WidthDelta> Defines a range around the width value specified using T RIGger<m>: P ATTern: WIDTh[: W IDTh] Suffix: <m> 1..3 1 = A-event only Parameters:...
Page 494 ® Remote Control R&S Command Reference Suffix: <m> 1..3 1 = A-event only Parameters: <ClockEdge> POSitive | NEGative | EITHer See c hapter 16.2.2.3, "Slope Parameter", on page 420. *RST: POSitive TRIGger<m>:SPATtern:CSOurce:LEVel <ClockLevel> Defines the voltage level for the clock signal. Suffix: <m>...
Page 495 (ANEDge) currently not used currently not used qualification is not supported (SERPattern) qualification is not supported (MSOState, option R&S RTO-B1) ..................479 TRIGger<m>: Q UALify<n>: S TATe ................480 TRIGger<m>: Q UALify<n>: A [: E NABle]...
Page 496 ® Remote Control R&S Command Reference Parameters: <AddTrigLogic> ON | OFF The qualification expression is considered for the trigger event. The qualification expression is ignored for the trigger event. *RST: TRIGger<m>:QUALify<n>:A[:ENABle] <State> TRIGger<m>:QUALify<n>:B[:ENABle] <State> TRIGger<m>:QUALify<n>:C[:ENABle] <State> TRIGger<m>:QUALify<n>:D[:ENABle] <State> Selects one of the channels and the specified trigger event to be considered for qualifi- cation: ●...
Page 497 ® Remote Control R&S Command Reference ● D: CH4 Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event, 2 = B-event. <n> 1..15 Defines the trigger type, see t able 16-13. Parameters: <Operator> DIRect | NOT DIRect Input value remains unchanged Input value is inverted *RST:...
Page 498 ® Remote Control R&S Command Reference ................482 TRIGger<m>: L EVel<n>: N OISe: M ODE .................483 TRIGger<m>: L EVel<n>: N OISe: A BSolute ................483 TRIGger<m>: L EVel<n>: N OISe: R ELative TRIGger<m>:LEVel<n>:NOISe[:STATe] <HysteresisMode> Selects how the hysteresis is set. Suffix: <m>...
Page 499 ® Remote Control R&S Command Reference TRIGger<m>:LEVel<n>:NOISe:ABSolute <HystAbs> Defines a range in absolute values around the trigger level. If the signal jitters inside this range and crosses the trigger level thereby, no trigger event occurs. Suffix: <m> 1..3 Event in a trigger sequence, the suffix is irrelevant. <n>...
Page 500 ® Remote Control R&S Command Reference ....................487 TRIGger<m>: H OLDoff: M AX ..................488 TRIGger<m>: H OLDoff: A UTotime ..................488 TRIGger<m>: H OLDoff: S CALing TRIGger<m>:SEQuence:MODE <Type> Selects the type of the sequence. See also: c hapter 3.3.4, "Sequence", on page 80.
Page 501 ® Remote Control R&S Command Reference TRIGger<m>:SEQuence:RESet:EVENt <EnabRstEvt> If set to ON, the trigger sequence is restarted by the R-event if the specified number of B-event does not occur. Suffix: <m> 1..3 The suffix is irrelevant. Parameters: <EnabRstEvt> ON | OFF *RST: TRIGger<m>:SEQuence:RESet:TIMeout[:ENABle] <State>...
Page 502 ® Remote Control R&S Command Reference Suffix: <m> 1..3 For holdoff settings, only suffix 1 (A-event) is available. Parameters: <Mode> TIME | EVENts | RANDom | AUTO | OFF TIME Defines the holdoff directly as a time period. The next trigger occurs only after the "Holdoff time"...
Page 503 ® Remote Control R&S Command Reference TRIGger<m>:HOLDoff:EVENts <Events> Defines the number of triggers to be skipped. The next trigger only occurs when this number of events is reached. The setting is relevant if the holdoff mode is set to EVENts. See also: ●...
Page 504 ® Remote Control R&S Command Reference Suffix: <m> 1..3 For holdoff settings, only suffix 1 (A-event) is available. Parameters: <RandomMaxTime> Range: 100E-9 to 10 Increment: 200E-6 *RST: 2E-3 Default unit: s TRIGger<m>:HOLDoff:AUTotime? Returns the resulting holdoff time if the holdoff mode is set to AUTO: Auto time = Auto time scaling * Horizontal scale.
Page 505 ® Remote Control R&S Command Reference Parameters: <AutoTimeScaling> Range: 1E-3 to 1000 Increment: 1 *RST: 16.2.6.5 Trigger Position .....................489 TIMebase: R EFerence ......................489 TIMebase: P OSition ..................489 TRIGger<m>: O FFSet: L IMited TIMebase:REFerence <ReferencePoint> Sets the reference point of the time scale in % of the display. The reference point defines which part of the waveform is shown.
Page 506 ® Remote Control R&S Command Reference Parameters: <State> ON | OFF If ON, the range of the trigger offset is limited considering the acquisition time and the reference point. Thus the trigger cannot be set outside the waveform diagram. *RST: 16.2.6.6 Trigger Control .
Page 507 ® Remote Control R&S Command Reference Usage: Event TRIGger<m>:OUT:STATe <State> Enables/disbales the trigger out signal that is provided to the EXT TRIGGER OUT con- nector on the rear panel when a trigger occurs. Suffix: <m> 1..3 The suffix is irrelevant. Parameters: <State>...
Page 508: Display
® Remote Control R&S Command Reference Return values: <Delay> Constant value: 250 ns Range: 1E-9 to 1 Increment: 1E-9 *RST: 800E-9 Default unit: s Usage: Query only 16.2.7 Display ● Signal Colors / Persistence...................492 ● Color Tables......................494 ● Diagram Layout.....................496 ●...
Page 509 ® Remote Control R&S Command Reference Parameters: <State> ON | OFF *RST: DISPlay:PERSistence:TIME <Time> If persistence is enabled ( ) , each new data point in D ISPlay: P ERSistence[: S TATe] the diagram area remains on the screen for the duration defined here. Parameters: <Time>...
Page 510 ® Remote Control R&S Command Reference DISPlay:COLor:SIGNal<m>:ASSign <ColorTable> Assigns the color table to the specified signal. Suffix: <m> 1..59 Waveform number, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <ColorTable> Color table name to be assigned to the signal. DISPlay:COLor:SIGNal<m>:USE <UseColorTable>...
Page 511 ® Remote Control R&S Command Reference Setting parameters: <Name> color table Usage: Setting only DISPlay:COLor:PALette:COUNt? Queries the number of configured color maps. Usage: Query only DISPlay:COLor:PALette:POINt:ADD <PaletteName> Appends a new row at the end of the color table. Setting parameters: <PaletteName>...
Page 512 ® Remote Control R&S Command Reference Parameters: <Position> cumulative occurance value Range: 0 to 100 Increment: 1 *RST: Default unit: % <Color> ARGB value of the color to be used for the table entry. ARGB=<Opacity(alpha) value><red value><green value><blue value>, in hexadecimal or decimal format. Range: 0 to 4294967295 Increment: 1...
Page 513 ® Remote Control R&S Command Reference DISPlay:DIAGram:GRID <Show> If enabled, a grid is displayed in the diagram area. Parameters: <Show> ON | OFF *RST: DISPlay:DIAGram:CROSshair <Crosshair> If selected, a crosshair is displayed in the diagram area. A crosshair allows you to select a specific data point by its co-ordinates.
Page 514 ® Remote Control R&S Command Reference Parameters: <State> ON | OFF *RST: DISPlay:SIGBar:POSition <Position> The signal bar can be placed vertically at the right (default position) or at the left, or horizontally at the top, bottom or center of the diagram to ensure best visibility of the waveforms.
Page 515 ® Remote Control R&S Command Reference DISPlay:SIGBar:HIDE:TRANsparency <HidingTransparency> Sets the transparency of the signal bar when the signal bar is faded out with DISPlay: S IGBar: H IDE[: A UTO] Parameters: <HidingTransparency>Range: 20 to 70 Increment: 5 *RST: Default unit: % DISPlay:SIGBar:COLor:BORDer <BorderColor>...
Page 516 ® Remote Control R&S Command Reference <ParentType> NONE | HORizontal | VERTical | TAB Position of the new diagram in relation to the existing one. HORizontal Besides the existing diagram VERTical Above or below the existing diagram In a new tab in the existing diagram <InsertBefore>...
Page 517 ® Remote Control R&S Command Reference Setting parameters: <DiagramName> String with the diagram name <Source> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 | XY1 | XY2 | XY3 | XY4 | MRESult1 | MRESult2 | MRESult3 | MRESult4 | MRESult5 | MRESult6 | MRESult7 | MRESult8 | SBUS1 | SBUS2 | SBUS3 | SBUS4 | D0 | D1 | D2 |...
Page 518 ® Remote Control R&S Command Reference 16.2.7.4 Zoom .......................502 LAYout: Z OOM: A DD ...................503 LAYout: Z OOM: A DDCoupled ..................503 LAYout: Z OOM: H ORZ: M ODE .................503 LAYout: Z OOM: H ORZ: A BSolute: P OSition .
Page 519 ® Remote Control R&S Command Reference <YStop> Defines the y-value at the end of the zoom area. <ZoomName> Defines the name of the new zoom diagram. Usage: Setting only SCPI confirmed LAYout:ZOOM:ADDCoupled <ZoomName>, <XOffset>, <YOffset>, <NewZoomName> Creates a new zoom diagram based on the settings of an existing zoom area for the same source.
Page 520 ® Remote Control R&S Command Reference Parameters for setting and query: <DiagramName> Name of the diagram on which the zoom area is based. <ZoomName> Name of the zoom diagram LAYout:ZOOM:HORZ:ABSolute:SPAN <DiagramName>, <ZoomName>,<Span> LAYout:ZOOM:HORZ:ABSolute:SPAN? <DiagramName>, <ZoomName> Defines the width of the zoom area. Parameters: <Span>...
Page 521 ® Remote Control R&S Command Reference LAYout:ZOOM:HORZ:RELative:POSition <DiagramName>, <ZoomName>,<RelPosi> LAYout:ZOOM:HORZ:RELative:POSition? <DiagramName>, <ZoomName> Defines the x-value of the centerpoint of the zoom area. Parameters: <RelPosi> Relative position of the centerpoint (x-value) Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: % Parameters for setting and query: <DiagramName>...
Page 522 ® Remote Control R&S Command Reference LAYout:ZOOM:HORZ:RELative:STOP <DiagramName>, <ZoomName>,<RelativeStop> LAYout:ZOOM:HORZ:RELative:STOP? <DiagramName>, <ZoomName> Defines the upper limit of the zoom area on the x-axis. Parameters: <RelativeStop> Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: % Parameters for setting and query: <DiagramName>...
Page 523 ® Remote Control R&S Command Reference LAYout:ZOOM:VERTical:ABSolute:SPAN <DiagramName>, <ZoomName>,<Span> LAYout:ZOOM:VERTical:ABSolute:SPAN? <DiagramName>, <ZoomName> Defines the height of the zoom area. Parameters: <Span> Range: 0 to 100E+24 Increment: 0.01 *RST: 0.01 Parameters for setting and query: <DiagramName> Name of the diagram on which the zoom area is based. <ZoomName>...
Page 524 ® Remote Control R&S Command Reference Parameters: <RelPosi> Relative position of the centerpoint (y-value) Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: % Parameters for setting and query: <DiagramName> Name of the diagram on which the zoom area is based. <ZoomName>...
Page 525 ® Remote Control R&S Command Reference Parameters: <RelativeStop> Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: % Parameters for setting and query: <DiagramName> Name of the diagram on which the zoom area is based. <ZoomName> Name of the zoom diagram LAYout:ZOOM:REMove <DiagramName>, <ZoomName>...
Page 526 ® Remote Control R&S Command Reference Parameters: <State> ON | OFF *RST: Usage: SCPI confirmed WAVeform<m>:XYCurve:SWAP Replaces the source of the x-axis with the source of the y-axis and vice versa. Suffix: <m> 1..4 XY-diagram Usage: Event SCPI confirmed WAVeform<m>:XYCurve:XSOurce <XYCurveXSource> Defines the signal source that supplies the x-values of the XY-diagram.
Page 527 ® Remote Control R&S Command Reference Usage: SCPI confirmed 16.2.7.6 History ...............511 CHANnel<m>[: W AVeform<n>]: H ISTory[: S TATe] ......................511 ACQuire: A VAilable .............511 CHANnel<m>[: W AVeform<n>]: H ISTory: C URRent ..............512 CHANnel<m>[: W AVeform<n>]: H ISTory: S TARt .
Page 528 ® Remote Control R&S Command Reference If a replay is running, the query returns the number of the currently shown acquisition. Suffix: <m> 1..4 Selects the input channel. <n> 1..3 Selects the waveform. For each channel, up to three waveforms can be analyzed.
Page 529 ® Remote Control R&S Command Reference Parameters: <StopAcqIdx> Number of the stop acquisition. The newest acquisition always has the index "0". Range: 0 to 0 Increment: 1 *RST: CHANnel<m>[:WAVeform<n>]:HISTory:TPACq <TimePerAcq> Sets the display time for one acquisition. The shorter the time, the faster is the replay. Suffix: <m>...
Page 530 ® Remote Control R&S Command Reference <n> 1..3 Selects the waveform. For each channel, up to three waveforms can be analyzed. If WAVeform<n> is omitted, waveform 1 is adressed. Parameters: <AutoRepeat> ON | OFF *RST: Usage: Asynchronous command CHANnel<m>[:WAVeform<n>]:HISTory:TSDate? Returns the date of the current acquisition that is shown in the history viewer ( CHANnel<m>[:...
Page 531: Cursor Measurements
® Remote Control R&S Command Reference CHANnel<m>[:WAVeform<n>]:HISTory:TSRelative? Returns the relative time of the current acquisition - the time difference to the newest acquisition (index = 0). See also: ( C HANnel<m>[: W AVeform<n>]: H ISTory: C URRent Suffix: <m> 1..4 Selects the input channel.
Page 532 ® Remote Control R&S Command Reference CURSor<m>:AOFF This command switches all cursors off. Suffix: <m> 1..4 The numeric suffix is ignored. Usage: Event CURSor<m>:STATe <State> Switches the indicated cursor on or off. Suffix: <m> 1..4 Selects the cursor. Parameters: <State> ON | OFF *RST: CURSor<m>:FUNCtion <Type>...
Page 533 ® Remote Control R&S Command Reference CURSor<m>:SOURce <CursorSource> Defines the source of the cursor measurement. Suffix: <m> 1..4 Selects the cursor. Parameters: <CursorSource> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 | XY1 | XY2 | XY3 | XY4 | D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D9 | D10 | D11 | D12 | D13 | D14 | D15 | MSOB1 | MSOB2 | MSOB3 | MSOB4...
Page 534 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the cursor. Parameters: <Coupling> ON | OFF Moving one cursor line moves the other cursor line too. The cursor lines always remain a fixed distance. Each cursor line is positioned independently. *RST: CURSor<m>:Y1Position <YPosition1>...
Page 535 ® Remote Control R&S Command Reference Parameters: <Coupling> ON | OFF Moving one cursor line moves the other cursor line too. The cursor lines always remain a fixed distance. Each cursor line is positioned independently. *RST: CURSor<m>:X1ENvelope <EnvelopeCurve1> If the waveform arithmetics are set to envelope curve (see C HANnel<m>[:...
Page 536 ® Remote Control R&S Command Reference Parameters: <EnvelopeCurve2> MIN | MAX | BOTH The horizontal cursor is set to the crossing point of the vertical cursor with the minimum waveform envelope. The horizontal cursor is set to the crossing point of the vertical cursor with the maximum waveform envelope.
Page 537 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the cursor. Return values: <Delta> Range: -100E+24 to 100E+24 Increment: 0 *RST: Usage: Query only CURSor<m>:YDELta:SLOPe <DeltaSlope> Returns the inverse value of the voltage difference - the reciprocal of the vertical distance Δ...
Page 538: Automatic Measurements
Measurement selection: MEASurement<m> With R&S RTO you can configure up to eight simultaneous measurements, and each can include several measurement types. For manual operation, these eight measurements are representented as tabs "Meas 1" to "Meas 8" in the "Measurements" dialog box. For remote operation, the measurement is indicated by the suffix <m>, containing the number...
Page 539 R2 | R3 | R4 | D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D9 | D10 | D11 | D12 | D13 | D14 | D15 Source of the measurement, see c hapter 16.2.2.2, "Waveform Parameter", on page 419 Digital channels are provided with option R&S RTO-B1. *RST: NONE User Manual 1316.0827.02 ─ 06...
Page 540 ® Remote Control R&S Command Reference <SignalSource2> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 | D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D9 | D10 | D11 | D12 | D13 | D14 | D15 MEASurement<m>:CATegory <Category>...
Page 541 ® Remote Control R&S Command Reference Parameters: <MeasType> Amplitude/time measurements HIGH | LOW | AMPLitude | MAXimum | MINimum | PDELta | MEAN | RMS | STDDev | POVershoot | NOVershoot | AREA | RTIMe | FTIMe | PPULse | NPULse | PERiod | FREQuency | PDCYcle | NDCYcle | CYCarea | CYCMean | CYCRms | CYCStddev | PULCnt | DELay | PHASe | BWIDth | PSWitching | NSWitching | PULSetrain | EDGecount | SHT | SHR | PROBemeter...
Page 542 ® Remote Control R&S Command Reference Parameters for setting and query: <MeasType> Amplitude/time measurements HIGH | LOW | AMPLitude | MAXimum | MINimum | PDELta | MEAN | RMS | STDDev | POVershoot | NOVershoot | AREA | RTIMe | FTIMe | PPULse | NPULse | PERiod | FREQuency | PDCYcle | NDCYcle | CYCarea | CYCMean | CYCRms | CYCStddev | PULCnt | DELay | PHASe | BWIDth | PSWitching | NSWitching |...
Page 543 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Usage: Event MEASurement<m>:MULTiple <MultiMeas> The measurement is performed repeatedly if the measured parameter occurs several times inside the defined gate. Suffix: <m> 1..9 See ...
Page 544 ® Remote Control R&S Command Reference REFLevel2:LDETection MANual REFLevel2:LMODe ABS REFLevel2:USRLevel UREF REFLevel2:ABSolute:LLEVel 0.001 REFLevel2:ABSolute:BDIStance 0.02 REFLevel2:ABSolute:ULEVel 0.01 REFLevel2:ABSolute:TDIStance 0.03 REFLevel2:ABSolute:MLEVel 0.005 Example: Manual reference level definition using relative values Reference levels are set to 15%, 50%, and 85% of the high signal level for waveform C3W1.
Page 545 ® Remote Control R&S Command Reference Parameters: <LevelDetection> AUTO | MANual *RST: AUTO Example: REFLevel2:LDETection MANual Sets manual level configuration for Channel1/Waveform1. C1W1 corresponds to suffix number 2. See also: " Programming Examples" on page 527 REFLevel<m>:RELative:MODE <RelativeLevels> The lower, middle and upper reference levels, defined as percentages of the high signal level.
Page 546 ® Remote Control R&S Command Reference Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <UserLevel> USIGnal | UREF USIGnal The high and low signal levels are defined by the user. UREF The reference levels are defined by the user.
Page 547 ® Remote Control R&S Command Reference Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <AutoLevelMode> AUTO | PPRobability | MPRobability | ABSolutepeak | UPLM | UMLP AUTO Auto select absolute probability: most suitable signal levels for the selected measurement PPRobability Peak probability: signal levels with the highest probability value...
Page 548 ® Remote Control R&S Command Reference Parameters: <HistgAveraging> ON | OFF *RST: Usage: SCPI confirmed REFLevel<m>:AUTO:COUNt <Weight> Defines the number of histograms to calculate the average from if R EFLevel<m>: is set to ON. AUTO[: S TATe] This function is only available in automatic reference level mode (see R EFLevel<m>:...
Page 549 ® Remote Control R&S Command Reference Example: REFLevel2:ABSolute:HIGH 0.015 Sets the high signal level for Channel1/Waveform1 to 15 mV. C1W1 corresponds to suffix number 2. Usage: SCPI confirmed REFLevel<m>:ABSolute:LOW <SignalLow> The signal value that represents a low level. Suffix: <m> 2...21 Source waveform, see ...
Page 550 ® Remote Control R&S Command Reference Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <BottomDistance> Range: 0 to 100E+24 Increment: 1E-3 *RST: Default unit: V Example: REFLevel2:ABSolute:BDIStance 0.0002 Sets the bottom distance for Channel1/Waveform1 to 0.2 mV. C1W1 corresponds to suffix number 2.
Page 551 ® Remote Control R&S Command Reference REFLevel<m>:ABSolute:MLEVel <MiddleLevel> The middle reference level. Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <MiddleLevel> Range: -100E+24 to 100E+24 Increment: 1E-3 *RST: Default unit: V Example: REFLevel2:ABSolute:MLEVel 0.005 Sets the middle reference level for Channel1/Waveform1 to 5 mV.
Page 552 ® Remote Control R&S Command Reference Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <UppRefLevRel> Percentage of the high signal level. Range: 0 to 100 Increment: 1 *RST: Default unit: % Example: REFLevel8:RELative:LOWer 85 Sets the upper reference level for Channel3/Waveform1 to 85 %.
Page 553 ® Remote Control R&S Command Reference Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <LowRefLevRel> Percentage of the high signal level. Range: 0 to 100 Increment: 1 *RST: Default unit: % Example: REFLevel8:RELative:LOWer 15 Sets the lower reference level for Channel3/Waveform1 to 15 %.
Page 554 ® Remote Control R&S Command Reference Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <RelOuterDist> Range: 0 to 100 Increment: 1 *RST: Default unit: % Usage: SCPI confirmed REFLevel<m>:RELative:ITUBe <RelativeInnDist> Defines a percentage of the signal level by which the absolute signal level may be higher than the low signal level or lower than the high signal level to be considered low or high, respectively.
Page 555 ® Remote Control R&S Command Reference REFLevel<m>:ABSolute:TITube <TopInnerDist> Defines an area beneath the high signal level which is still considered to be high level. Suffix: <m> 2...21 Source waveform, see c hapter 16.2.2.1, "Waveform Suf- fix", on page 419. Parameters: <TopInnerDist>...
Page 556 ® Remote Control R&S Command Reference Results ..............540 MEASurement<m>: R EFLevel: R ESult: L OWer ..............540 MEASurement<m>: R EFLevel: R ESult: M IDDle ..............540 MEASurement<m>: R EFLevel: R ESult: U PPer ..............540 MEASurement<m>: R EFLevel: R ESult: S IGLow .
Page 557 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Return values: <BottomInner> Range: -100E+24 to 100E+24 Increment: 0 *RST: Usage: Query only SCPI confirmed MEASurement<m>:REFLevel:RESult:BOUTer? Returns the area beneath the low signal level which is still considered to be low level. Suffix: <m>...
Page 558 ® Remote Control R&S Command Reference Return values: <TopOuter> Range: -100E+24 to 100E+24 Increment: 0 *RST: Usage: Query only SCPI confirmed 16.2.9.3 Amplitude/Time Measurement The following table lists the measurement suffixes and the <MeasType> parameter value with a short description. For a detailed description, see ...
Page 559 Edge count Number of positive or negative edges of the waveform, or both Only available for digital channels (requires MSO option R&S RTO-B1). SETup Setup time Parameters to query the setup and hold times. Use these parameters only in queries with ...
Page 560 ® Remote Control R&S Command Reference Meas. <MeasType> Meas. type Description/Result suffix parameter value Setup/Hold ratio Setup/Hold ratio measurement. Setup/Hold ratio is the ratio of the setup time to the sum of hold and setup time: / (T Setup Setup Hold Used as setting to activate the Setup/Hold ratio measure- ment with ...
Page 561 ® Remote Control R&S Command Reference MEASurement<m>:DETThreshold <SignDetectThres> Defines the value above which measurement results are displayed. Values beneath the threshold are considered to be noise and they are ignored. Suffix: <m> 1..9 irrelevant Parameters: <SignDetectThres> Range: 0 to 50 Increment: 1 *RST: Default unit: %...
Page 562 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. <n> 1..2 Selects the source number. Parameters: <EdgeCountDirection>FRFI | FRLA FRFI - FRom FIrst, counting starts with the first edge of the wave- form.
Page 563 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. <n> 1..2 Selects the source number. Parameters: <Slope> POSitive | NEGative | EITHer *RST: POSitive MEASurement<m>:AMPTime:PTCount <PulseCount> Sets the number of positive pulses for the pulse train measurement. It measures the duration of N positive pulses from the rising edge of the first pulse to the falling edge of the N-th pulse.
Page 564 ® Remote Control R&S Command Reference Parameters: <SetupHoldClockSlope> POSitive | NEGative | EITHer EITHer The clock edges next to the data edge are considered regardless of the clock slope. *RST: POSitive MEASurement<m>:AMPTime:CLCK<n>:LSELect <ClockLevel> Selects the reference level of the clock on which the time is measured. Reference level and clock slope define the time point for setup and hold measurements.
Page 565 ® Remote Control R&S Command Reference Parameters: <ValidRange> ILIMit | ULIMit | LLIMit | OLIMit ILIMit Inside (within) limit; between the upper and lower limit values ULIMit Upper limit; above the upper limit value LLIMit Lower limit; below the lower limit value OLIMit Outside limit;...
Page 566 ® Remote Control R&S Command Reference 16.2.9.4 Eye/Jitter Measurement The following table lists the measurement suffixes and the <MeasType> parameter value with a short description. For a detailed description, see c hapter 5.2.1.3, "Eye/Jitter Measure- ments", on page 136. Table 16-15: Eye/jitter measurement types Meas.
Page 567 ® Remote Control R&S Command Reference MEASurement<m>:EYEJitter:LCHeck<n>:VALid <ValidRange> Enables or disables limit checking for eye/jitter measurements in the specified measure- ment channel. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. <n> 1..30 Number of eye/jitter measurement type, see t able 16-15.
Page 568 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. <n> 1..30 Number of eye/jitter measurement type, see t able 16-15. Parameters: <Lower Margin> Range: -100 to 100 <UpperMargin> Increment: 10E-6 *RST: 16.2.9.5 Spectrum...
Page 569 ® Remote Control R&S Command Reference MEASurement<m>:SPECtrum:CPOWer:BANDwidth <ChPowBandwidth> Defines the bandwidth over which the channel power is calculated. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <ChPowBandwidth> Range: 0 to 4E+9 Increment: 1 *RST: Default unit: Hz MEASurement<m>:SPECtrum:OBANdwidth <OccupiedBW>...
Page 570 ® Remote Control R&S Command Reference Parameters: <NDbDown> Range: 0 to 100 Increment: 1 *RST: Default unit: dB MEASurement<m>:SPECtrum:NREJect <NoiseReject> Defines the threshold beneath which values are rejected as noise. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <NoiseReject>...
Page 571 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. <n> 1..8 Number of spectrum measurement type, see t able 16-16. Parameters: <LowerLimit> Range: -100 to 100 <UpperLimit> Increment: 10E-6 *RST: MEASurement<m>:SPECtrum:LCHeck<n>:LOWer:MARGin <LowerMargin>...
Page 572 ® Remote Control R&S Command Reference ...................560 LAYout: H ISTogram: R EMove LAYout:HISTogram:ADD <HistogramName>, <Source>, <XStart>, <XStop>, <YStart>, <YStop>, <Relative>, <Orientation> Defines and displays a new histogram for the specified source. Note: To define the mode of the histogram (vertical or horizontal), use the L AYout:...
Page 573 ® Remote Control R&S Command Reference Parameters for setting and query: <HistogramName> String parameter LAYout:HISTogram:MODE <HistogramName>,<Mode> LAYout:HISTogram:MODE? <HistogramName> Defines or queries the type of histogram. Parameters: <Mode> VERTical | HORizontal VERTical Amplitude histogram (horizontal bars across amplitude) HORizontal Time or frequency histogram (vertical bars over time/frequencies) *RST: VERTical Parameters for setting and query:...
Page 574 ® Remote Control R&S Command Reference LAYout:HISTogram:HORZ:ABSolute:STOP <HistogramName>,<Stop> LAYout:HISTogram:HORZ:ABSolute:STOP? <HistogramName> Defines the horizontal stop value of the histogram. Parameters: <Stop> Range: -100E+24 to 100E+24 Increment: 0.01 *RST: 0.01 Parameters for setting and query: <HistogramName> LAYout:HISTogram:HORZ:RELative:STARt <HistogramName>,<RelativeStart> LAYout:HISTogram:HORZ:RELative:STARt? <HistogramName> Defines the horizontal start value of the histogram. Parameters: <RelativeStart>...
Page 575 ® Remote Control R&S Command Reference Parameters: <Mode> ABS | REL *RST: Parameters for setting and query: <HistogramName> LAYout:HISTogram:VERTical:ABSolute:STARt <HistogramName>,<Start> LAYout:HISTogram:VERTical:ABSolute:STARt? <HistogramName> Defines the vertical start value of the histogram. Parameters: <Start> Range: -100E+24 to 100E+24 Increment: 0.01 *RST: 0.01 Parameters for setting and query: <HistogramName>...
Page 576 ® Remote Control R&S Command Reference LAYout:HISTogram:VERTical:RELative:STOP <HistogramName>,<RelativeStop> LAYout:HISTogram:VERTical:RELative:STOP? <HistogramName> Defines the vertical stop value of the histogram. Parameters: <RelativeStop> Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: % Parameters for setting and query: <HistogramName> Usage: SCPI confirmed LAYout:HISTogram:RESet <HistogramName> Resets the values to begin a new histogram.
Page 577 ® Remote Control R&S Command Reference Meas. <MeasType> Meas. type Description/Result suffix parameter value HPEak Histogram peak Maximum sample value in the histogram PEAK Peak value Signal value at the histogram peak UPEakvalue Upper peak value Signal value at the maximum sample value in the upper half of the histogram LPEakvalue Lower peak value...
Page 578 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <HistogramName> Name of the histogram MEASurement<m>:HISTogram:PROBability:TYPE <Marker> Defines the marker reference in the probability domain. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522.
Page 579 ® Remote Control R&S Command Reference Parameters: <Limit> Range: 0 to 100 Increment: 10 *RST: Default unit: % MEASurement<m>:HISTogram:LCHeck<n>:VALid <ValidRange> Enables or disables limit checking for histogram measurements in the specified mea- surement channel. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522.
Page 580 ® Remote Control R&S Command Reference MEASurement<m>:HISTogram:LCHeck<n>:LOWer:MARGin <LowerMargin> MEASurement<m>:HISTogram:LCHeck<n>:UPPer:MARGin <UpperMargin> Define the lower and upper margins for the limit check, respectively. Margins are not as strict as limits and must be within the valid value range. The valid range is defined using the ...
Page 581 ® Remote Control R&S Command Reference MEASurement<m>:DISPlay:STYLe <DisplayStyle> Selects the style in which the measurement waveform is displayed. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <DisplayStyle> LINE | MARKer LINE The individual data points are connected by a line. MARKer Only the individual data points are displayed as markers.
Page 582 ® Remote Control R&S Command Reference 16.2.9.9 Statistics and Long-term Measurements ................566 MEASurement<m>: S TATistics[: E NABle] ...............566 MEASurement<m>: S TATistics: H ISTogram ................566 MEASurement<m>: S TATistics: M ODE ................567 MEASurement<m>: S TATistics: R COunt ................567 MEASurement<m>:...
Page 583 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <ResetMode> NONE | TIME | WFMS NONE No reset, the number of measurements considered by the statis- tics is not limited. Time Resets the statistics after the time defined using ...
Page 584 ® Remote Control R&S Command Reference Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Usage: Event MEASurement<m>:VERTical:OFFSet <VerticalOffset> Defines a vertical offset for the long term measurement. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522.
Page 585 ® Remote Control R&S Command Reference MEASurement<m>:STATistics:WEIGht <Weight> Defines the number of measurements for which the statistical average is calculated. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <Weight> Statistics average count Range: 2 to 2147483647 Increment: 10 *RST: 10000...
Page 586 ® Remote Control R&S Command Reference Parameters: <MeasurementTime> Range: 0.01 to 2.14748E+9 Increment: 1 *RST: Default unit: s MEASurement<m>:LTMeas:ENVSensor:STATe <EnvState> Enables the evaluation of a connected environment sensor. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <EnvState>...
Page 587 ® Remote Control R&S Command Reference MEASurement<m>:RESult:WFMCount? [<MeasType>] MEASurement<m>:RESult:STDDev? [<MeasType>] Returns the specified statistic result of the specified measurement type. If no parameter is specified, the result of the main measurement is returned. The main measurement is defined using M EASurement<m>:...
Page 588 ® Remote Control R&S Command Reference 16.2.9.11 Gating ..................572 MEASurement<m>: G ATE[: S TATe] ..................572 MEASurement<m>: G ATE: M ODE ..............572 MEASurement<m>: G ATE: A BSolute: S TARt ...............572 MEASurement<m>: G ATE: A BSolute: S TOP .
Page 589 ® Remote Control R&S Command Reference MEASurement<m>:GATE:RELative:STARt <RelativeStart> MEASurement<m>:GATE:RELative:STOP <RelativeStop> Define the relative start and end values for the gate, respectively. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <RelativeStart> Range: 0 to 100 <RelativeStop> Increment: 0.1 *RST: Default unit: %...
Page 590 ® Remote Control R&S Command Reference 16.2.9.12 Event Actions ................574 MEASurement<m>: O NViolation: B EEP ................574 MEASurement<m>: O NViolation: A CQStop ................574 MEASurement<m>: O NViolation: P RINt ...............575 MEASurement<m>: O NViolation: W FMSave MEASurement<m>:ONViolation:BEEP <Beep> Generates a beep sound for the specified event. Suffix: <m>...
Page 591: Mathematics
® Remote Control R&S Command Reference MEASurement<m>:ONViolation:WFMSave <SaveWfm> Saves the waveform data. Suffix: <m> 1..9 See " Measurement selection: MEASurement<m>" on page 522. Parameters: <SaveWfm> NOACtion | SUCCess | VIOLation See c hapter 16.2.2.5, "Event Parameter", on page 421 *RST: NOACtion Usage:...
Page 592 ® Remote Control R&S Command Reference CALCulate:MATH<m>:STATe <State> Enables the math waveform display. Suffix: <m> 1..4 math waveform Parameters: <State> ON | OFF *RST: Usage: SCPI confirmed CALCulate:MATH<m>:ARIThmetics <Arithmetics> Selects the method to build the resulting math waveform from consecutive acquisitions. The processing is similar to the waveform arithmetics - instead of the acquired waveforms the math waveforms are used to create envelope and average.
Page 593 ® Remote Control R&S Command Reference Suffix: <m> 1...4 math waveform Parameters: <VerticalRange> Range: 0 to 100E+24 Increment: 0.01 *RST: Default unit: div Usage: SCPI confirmed CALCulate:MATH<m>:VERTical:SCALe <VerticalScale> Defines the scale of the y-axis in the math function diagram. The value is defined as "V per division", e.g.
Page 594 ® Remote Control R&S Command Reference ............585 CALCulate: M ATH<m>: F FT: G ATE: R ELative: S TARt ............585 CALCulate: M ATH<m>: F FT: G ATE: R ELative: S TOP ................585 CALCulate: M ATH<m>: F FT: G ATE: S HOW .
Page 595 R&S Command Reference Various different window functions are provided in the R&S RTO to suit different input signals. Each of the window functions has specific characteristics, including some advan- tages and some trade-offs. These characteristics need to be considered carefully to find the optimum solution for the measurement task.
Page 596 ® Remote Control R&S Command Reference Suffix: <m> 1..4 math waveform Parameters: <CenterFreq> center frequency Range: 0 to 2E+12 Increment: 1 *RST: 2.5E+9 Default unit: Hz CALCulate:MATH<m>:FFT:FULLspan Performs FFT calculation for the full frequency span. Suffix: <m> 1..4 math waveform Usage: Event CALCulate:MATH<m>:FFT:SPAN <FreqSpan>...
Page 597 ® Remote Control R&S Command Reference Return values: <AdjResBW> effective resolution bandwidth Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: Hz Usage: Query only CALCulate:MATH<m>:FFT:BANDwidth[:RESolution]:AUTO <State> Couples the frequency span to the RBW. Suffix: <m> 1..4 math waveform Parameters: <State>...
Page 598 ® Remote Control R&S Command Reference CALCulate:MATH<m>:FFT:GATE:COUPling <GateRBWCoupling> Defines the behaviour of the record length or RBW value in dependancy to the other FFT parameters. See also: ● " Record Length/RBW Coupling" on page 207 ● c hapter 6.3.1, "Fundamentals of FFT Analysis", on page 192 Suffix: <m>...
Page 599 ® Remote Control R&S Command Reference Suffix: <m> 1...4 Selects the math waveform. Parameters: <Arithmetics> OFF | ENVelope | AVERage *RST: CALCulate:MATH<m>:FFT:FRAMe:COVerage? Due to the restriction of the number of frames (see C ALCulate: M ATH<m>: F FT: on page 583), the waveform may only be analyzed partially. This FRAMe:...
Page 600 ® Remote Control R&S Command Reference The higher the overlap factor, the more frames are used. This leads to more individual results and improves detection of transient signal effects. However, it also extends the duration of the calculation. Suffix: <m> 1...4 math waveform Parameters:...
Page 601 ® Remote Control R&S Command Reference Parameters: <Mode> ABS | REL *RST: Usage: SCPI confirmed CALCulate:MATH<m>:FFT:GATE:RELative:STARt <RelativeStart> Defines the starting value for the gate in percent. Suffix: <m> 1...4 math waveform Parameters: <RelativeStart> Range: -100E+24 to 100E+24 Increment: 0.1 *RST: Default unit: % Usage: SCPI confirmed...
Page 602 ® Remote Control R&S Command Reference CALCulate:MATH<m>:FFT:GATE:ZCOupling <ZoomCoupling> If enabled, the gate area is defined identically to the zoom area for the zoom diagram. Suffix: <m> 1...4 math waveform Parameters: <ZoomCoupling> ON | OFF *RST: Usage: SCPI confirmed CALCulate:MATH<m>:FFT:GATE[:STATe] <State> Enables FFT gating.
Page 603 ® Remote Control R&S Command Reference Parameters: <Range> Range: 1 to 500 Increment: 1 *RST: Default unit: dB Usage: SCPI confirmed CALCulate:MATH<m>:FFT:MAGNitude:SCALe <MagnitudeScale> Defines the scaling of the y-axis. The display values are valid for 50Ω termination impend- ance. For details on the available scaling modes, see "...
Page 604 ® Remote Control R&S Command Reference Parameters: <Suppression> ON | OFF *RST: Usage: SCPI confirmed CALCulate:MATH<m>:FFT:PHASe:THReshold <SupprThres> Defines the minimum frequency magnitude for which phases are calculated. This setting is only available if is set to "ON". C ALCulate: M ATH<m>: F FT: P HASe: S UPPression Suffix: <m>...
Page 605 ® Remote Control R&S Command Reference Return values: <SignalType> SOUR | SPEC | CORR | MEAS | NONE SOURce = normal signal SPECtrum = FFT spectrum, specific math signal CORRelation = correlated signal, specific math signal MEAsurement = result of a measurement XY = XY-signal SBUS = Serial bus NONE = undefined...
Page 606: Reference Waveforms
® Remote Control R&S Command Reference Return values: <Data> Comma-separated value list of vertical values - voltages, or mag- nitudes of a spectrum. Usage: Query only 16.2.11 Reference Waveforms ● Reference......................590 ● Scaling........................592 ● Waveform Data.....................596 16.2.11.1 Reference ....................590 REFCurve<m>:...
Page 607 ® Remote Control R&S Command Reference Parameters: <State> ON | OFF *RST: REFCurve<m>:NAME <Name> Defines the name of the reference waveform file to be loaded, saved or deleted. Suffix: <m> 1..4 Reference waveform Parameters: <Name> Path and name of the file that contains the reference waveform or to which the reference waveform is to be stored (.xml or .bin format), enclosed in single quotes.
Page 608 ® Remote Control R&S Command Reference REFCurve<m>:DELete Deletes the reference waveform file selected by on page 591. R EFCurve<m>: N AME Suffix: <m> 1..4 Reference waveform Usage: Event REFCurve<m>:CLEar The selected reference waveform is no longer displayed, its memory is deleted. Suffix: <m>...
Page 609 ® Remote Control R&S Command Reference Parameters: <VerticalMode> COUPled | INDependent COUPled Vertical position and scale of the source are used. INDependent Scaling and position can be set specific to the reference waveform. *RST: INDependent REFCurve<m>:SCALe <VerticalScale> Sets the scale factor for the reference waveform if vertical scaling is set to "Independ- ent"...
Page 610 ® Remote Control R&S Command Reference Parameters: <State> ON | OFF *RST: REFCurve<m>:RESCale:VERTical:FACTor <ScaleFactor> Defines the vertical stretching factor. A factor greater than 1 stretches the waveform ver- tically, a factor lower than 1 compresses the curve. Suffix: <m> 1..4 Reference waveform Parameters: <ScaleFactor>...
Page 611 ® Remote Control R&S Command Reference Parameters: <HorizontalMode> ORIGinal | COUPled ORIGinal Horizontal scaling and reference point of the source waveform are used. COUPled The current horizontal settings of the diagram are used. *RST: ORIGinal REFCurve<m>:RESCale:HORizontal:STATe <State> Enables and disables the horizontal stretching. Stretching changes the display of the waveform independent of the horizontal settings of the source waveform and of the horizontal diagram settings.
Page 612 ® Remote Control R&S Command Reference Parameters: <Offset> Range: -100E+24 to 100E+24 Increment: 0.01 *RST: Default unit: s 16.2.11.3 Waveform Data ..................596 REFCurve<m>: D ATA: S TYPe ..................596 REFCurve<m>: D ATA: H EADer ..................597 REFCurve<m>: D ATA[: V ALues] REFCurve<m>:DATA:STYPe? Returns the signal type of the source of the reference waveform.
Page 613: Mask Testing
® Remote Control R&S Command Reference Usage: Query only SCPI confirmed REFCurve<m>:DATA[:VALues]? Returns the data of the channel waveform points. The waveform data can be used in MATLAB, for example. To set the export format, use F ORMat[: D ATA] Suffix: <m>...
Page 614 ® Remote Control R&S Command Reference MTESt:REMove <MaskTestName> Deletes the mask test definition with the specified name. Setting parameters: <MaskTestName> Usage: Setting only SCPI confirmed MTESt[:STATe] <MaskTestName>,<State> MTESt[:STATe]? <MaskTestName> Activates and deactivates the mask test. If the acquisition is running, the test starts immediately.
Page 615 ® Remote Control R&S Command Reference MTESt:CONDition <MaskTestName>,<PassFailMode> MTESt:CONDition? <MaskTestName> Sets the first criteria for a failed test, the kind of hits to be considered for test evaluation. A test has failed if the number of sample hits or acquisition hits exceeds the limit defined by ...
Page 616 ® Remote Control R&S Command Reference Parameters: <DefinitionType> USER | WFML USER The mask segments are created by entering the numerical x- and y-values of the mask points. See: c hapter 16.2.12.2, "Mask Definition: User Mask", on page 600 WFML The mask is created from the envelope of an existing waveform.
Page 617 ® Remote Control R&S Command Reference Parameters for setting and query: <MaskTestName> <MaskSegmIdx> Index of the mask segment in the mask definition MTESt:SEGMent:ADD <MaskTestName> Creates a new segment in the mask definition. Setting parameters: <MaskTestName> Usage: Setting only SCPI confirmed MTESt:SEGMent:COUNt? <MaskTestName>, <MaskSegmIdx>...
Page 618 ® Remote Control R&S Command Reference Parameters: <Region> UPPer | LOWer | INNer UPPer the segment points are connected to a line, the display area above this line is the mask segment LOWer the segment points are connected to a line, the display area below this line is the mask segment INNer the segment points form a closed geometrical shape, which is the...
Page 619 ® Remote Control R&S Command Reference <MaskSegmPointIdx> Index of the mask segment point in the mask definition Usage: Setting only MTESt:SEGMent:POINt:COUNt? <MaskTestName>, <MaskSegmIdx> Returns the number of defined points for the specified mask segment. Query parameters: <MaskTestName> <MaskSegmIdx> Index of the mask segment in the mask definition Usage: Query only MTESt:SEGMent:POINt:X <MaskTestName>, <MaskSegmIdx>,...
Page 620 ® Remote Control R&S Command Reference MTESt:SEGMent:RESCale:RECalculate <MaskTestName>, <MaskSegmIdx> Multiplies and adds the given x- and y-factors and offsets to the coordinates of all points of the selected mask segment. Setting parameters: <MaskTestName> <MaskSegmIdx> Index of the mask segment in the mask definition Usage: Setting only MTESt:SEGMent:RESCale:XFACtor <MaskTestName>,...
Page 621 ® Remote Control R&S Command Reference MTESt:SEGMent:RESCale:XOFFset <MaskTestName>, <MaskSegmIdx>,<OffsetX> MTESt:SEGMent:RESCale:XOFFset? <MaskTestName>, <MaskSegmIdx> Moves the mask segment horizontally. The specified offset is added to the x-values of all points of the selected mask segment. Only takes effect after the command. M TESt:...
Page 622 ® Remote Control R&S Command Reference Parameters: <Source> REFerence1 | REFerence2 | REFerence3 | REFerence4 *RST: REFerence1 Parameters for setting and query: <MaskTestName> String containing the name of the mask test Usage: SCPI confirmed MTESt:WFMLupdate <MaskTestName> Creates the upper and lower mask limit from the envelope of the selected reference waveform.
Page 623 ® Remote Control R&S Command Reference Parameters for setting and query: <MaskTestName> String containing the name of the mask test MTESt:WFMRescale:YPOSition <MaskTestName>,<VertPosi> MTESt:WFMRescale:YPOSition? <MaskTestName> Moves the mask vertically within the display. Parameters: <VertPosi> Range: -100E+24 to 100E+24 Increment: 0.05 *RST: Default unit: div Parameters for setting and query: <MaskTestName>...
Page 624 ® Remote Control R&S Command Reference Parameters for setting and query: <MaskTestName> MTESt:ONViolation:STOP <MaskTestName>,<StopAcq> MTESt:ONViolation:STOP? <MaskTestName> Stops data acquisition for the specified event. Parameters: <StopAcq> NOACtion | VIOLation See c hapter 16.2.2.5, "Event Parameter", on page 421 *RST: NOACtion Parameters for setting and query: <MaskTestName>...
Page 625 ® Remote Control R&S Command Reference ................610 MTESt: R ESult: C OUNt: F WAVeforms ..................610 MTESt: R ESult: C OUNt: F AILures ....................610 MTESt: R ESult: F RATe MTESt:RESult:STATe? <MaskTestName> Shows if the test is running or has finished. The state is set to "Finished" if no acquisitions remain (see ...
Page 626 ® Remote Control R&S Command Reference The value is useful if you test a specified number of acquisitions with action "Stop acqui- sition" on violation, or if the acquisition has been stopped manually. See also: c hapter 8.2.4, "Running a Mask Test", on page 222.
Page 627: Search Commands
® Remote Control R&S Command Reference Return values: <FailRate> Range: -100E+24 to 100E+24 Increment: 0 *RST: Default unit: % Usage: Query only 16.2.13 Search Commands ● Programming Examples..................611 ● General Search Settings..................611 ● Search Conditions....................613 ● Trigger Level......................631 ● Search Scope Settings..................632 ●...
Page 628 ® Remote Control R&S Command Reference See Example: " Searching for a pulse of specified width" on page 611 Usage: Setting only SCPI confirmed SEARch:CLEar <SearchName> Clears the search results once to start a new search. Setting parameters: <SearchName> Search definition Usage: Setting only...
Page 629 ® Remote Control R&S Command Reference Parameters: <OnlineState> ON | OFF *RST: Parameters for setting and query: <SearchName> Search definition SEARch:SOURce <SearchName>,<SearchConditionSrc> SEARch:SOURce? <SearchName> Defines the source on which the search conditions are applied. The source can be any input signal, math or reference waveform. Parameters: <SearchConditionSrc>C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 |...
Page 630 ® Remote Control R&S Command Reference ................615 SEARch: T RIGger: D ATatoclock: A COPy ..................615 SEARch: T RIGger: E DGE: A COPy ...................615 SEARch: T RIGger: G LITch: A COPy ..................615 SEARch: T RIGger: I NTerval: A COPy .
Page 631 ® Remote Control R&S Command Reference SEARch:TRIGger:DATatoclock:ACOPy <SearchName> SEARch:TRIGger:EDGE:ACOPy <SearchName> SEARch:TRIGger:GLITch:ACOPy <SearchName> SEARch:TRIGger:INTerval:ACOPy <SearchName> SEARch:TRIGger:RUNT:ACOPy <SearchName> SEARch:TRIGger:SLEWrate:ACOPy <SearchName> SEARch:TRIGger:TIMeout:ACOPy <SearchName> SEARch:TRIGger:WIDTh:ACOPy <SearchName> SEARch:TRIGger:WINDow:ACOPy <SearchName> Copies the trigger event configuration from Trigger A for the selected channel source to the search condition settings. See ...
Page 632 ® Remote Control R&S Command Reference SEARch:TRIGger:DATatoclock:CEDGe <SearchName>,<ClockEdge> SEARch:TRIGger:DATatoclock:CEDGe? <SearchName> Sets the edge of the clock signal to define the time reference point for the setup and hold time. Parameters: <ClockEdge> POSitive | NEGative | EITHer See c hapter 16.2.2.3, "Slope Parameter", on page 420.
Page 633 ® Remote Control R&S Command Reference SEARch:TRIGger:DATatoclock:HTIMe <SearchName>,<HoldTime> SEARch:TRIGger:DATatoclock:HTIMe? <SearchName> Sets the minimum time after the clock edge while the data signal must stay steady above or below the data level. The hold time can be negative. In this case, the setup time is always positive. The setup/ hold interval starts before the clock edge (setup time) and ends before the clock edge (hold time).
Page 634 ® Remote Control R&S Command Reference Parameters: <Slope> POSitive | NEGative | EITHer See c hapter 16.2.2.3, "Slope Parameter", on page 420. *RST: POSitive Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed Glitch ..................618 SEARch: T RIGger: G LITch: P OLarity .
Page 635 ® Remote Control R&S Command Reference You need to know the expected pulse widths of the circuit to set the glitch width correctly. Parameters: <Width> Range: 100E-12 to 1E-3 Increment: 100E-6 *RST: 1E-9 Default unit: s Parameters for setting and query: <SearchName>...
Page 636 ® Remote Control R&S Command Reference SEARch:TRIGger:INTerval:RANGe <SearchName>,<RangeMode> SEARch:TRIGger:INTerval:RANGe? <SearchName> Selects how the range of an interval is defined based on the interval width and delta (see on page 620 and S EARch: T RIGger: I NTerval: W IDTh S EARch:...
Page 637 ® Remote Control R&S Command Reference SEARch:TRIGger:RUNT:DELTa <SearchName>,<WidthDelta> SEARch:TRIGger:RUNT:DELTa? <SearchName> Defines a range around the given runt width. Parameters: <WidthDelta> Range: 100E-12 to 864 Increment: 100E-9 *RST: 100E-12 Default unit: s Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:TRIGger:RUNT:POLarity <SearchName>,<Polarity>...
Page 638 ® Remote Control R&S Command Reference Parameters: <Mode> ANY | LONGer | SHORter | WITHin | OUTSide Triggers on all runts fulfilling the level condition, without time lim- itation. LONGer Triggers on runts longer than the given "Runt width". SHORter Triggers on runts shorter than the given "Runt width".
Page 639 ® Remote Control R&S Command Reference Parameters for setting and query: <Key> Search definition <SignalSource> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 Source of the search, see ...
Page 640 ® Remote Control R&S Command Reference Parameters: <TimeDelta> Range: 0 to 10 Increment: 100E-9 *RST: Default unit: s Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:TRIGger:SLEWrate:RANGe <SearchName>,<RangeMode> SEARch:TRIGger:SLEWrate:RANGe? <SearchName> Selects how the time limit for the slew rate is defined. The time measurement starts when the signal crosses the first trigger level - the upper or lower level depending on the selected slope - and stops when the signal crosses the second level.
Page 641 ® Remote Control R&S Command Reference SEARch:TRIGger:SLEWrate:TIME <SearchName>,<Time> SEARch:TRIGger:SLEWrate:TIME? <SearchName> For the ranges "Within" and "Outside", the slew rate defines the center of a range which is defined by the limits "±Delta". For the ranges "Shorter" and "Longer", the slew rate defines the maximum and minimum slew rate limits, respectively.
Page 642 ® Remote Control R&S Command Reference Parameters for setting and query: <Key> Search definition <SignalSource> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 Source of the search, see ...
Page 643 ® Remote Control R&S Command Reference Usage: SCPI confirmed Width ..................627 SEARch: T RIGger: W IDTh: D ELTa ..................627 SEARch: T RIGger: W IDTh: P OLarity ..................627 SEARch: T RIGger: W IDTh: R ANGe ..................628 SEARch: T RIGger: W IDTh: W IDTh SEARch:TRIGger:WIDTh:DELTa <SearchName>,<WidthDelta>...
Page 644 ® Remote Control R&S Command Reference Parameters: <RangeMode> WITHin | OUTSide | SHORter | LONGer WITHin Triggers on pulses inside a given range. The range of the pulse width is defined by "Width" and "±Delta". OUTSide Triggers on pulses outside a given range. The range definition is the same as for "Within"...
Page 645 ® Remote Control R&S Command Reference .................631 SEARch: T RIGger: L EVel: W INDow: U PPer SEARch:TRIGger:WINDow:DELTa <SearchName>,<WidthDelta> SEARch:TRIGger:WINDow:DELTa? <SearchName> Defines a range around the "Width" value (see S EARch: T RIGger: W INDow: W IDTh on page 630). Parameters: <WidthDelta>...
Page 646 ® Remote Control R&S Command Reference SEARch:TRIGger:WINDow:TIMerange <SearchName>,<TimeRangeMode> SEARch:TRIGger:WINDow:TIMerange? <SearchName> Selects how the time limit of the window is defined. Time conditioning is available for the vertical conditions "WITHin" and "OUTSide" (see S EARch: T RIGger: W INDow: R ANGe on page 629).
Page 647 ® Remote Control R&S Command Reference SEARch:TRIGger:LEVel:WINDow:LOWer <Key>, <SignalSource>, <Value> SEARch:TRIGger:LEVel:WINDow:LOWer? <Key>, <SignalSource> Sets the lower voltage limit for the window. Parameters: <Value> Voltage value Parameters for setting and query: <Key> Search definition <SignalSource> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 Source of the search, see ...
Page 648 ® Remote Control R&S Command Reference Parameters: <Value> Voltage value Parameters for setting and query: <Key> Search definition <SignalSource> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 Source of the search, see ...
Page 649 ® Remote Control R&S Command Reference Usage: SCPI confirmed SEARch:GATE:MODE <SearchName>,<Mode> SEARch:GATE:MODE? <SearchName> Defines whether the gate settings are configured using absolute or relative values. Parameters: <Mode> ABS | REL *RST: Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:GATE:SHOW <SearchName>,<DisplayState>...
Page 650 ® Remote Control R&S Command Reference Parameters: <Stop> Range: -100E+24 to 100E+24 Increment: 0.01 *RST: 0.01 Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:GATE:RELative:STARt <SearchName>,<RelativeStart> SEARch:GATE:RELative:STARt? <SearchName> Defines the starting value for the gate. Parameters: <RelativeStart> Range: -100E+24 to 100E+24 Increment: 0.1...
Page 651 ® Remote Control R&S Command Reference Usage: SCPI confirmed SEARch:HISTory:ALL <SearchName>,<AllHistoryElems> SEARch:HISTory:ALL? <SearchName> If enabled, all available stored waveforms are included in the search. Parameters: <AllHistoryElems> ON | OFF *RST: Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:HISTory:STARt <SearchName>,<StartIndex>...
Page 652 ® Remote Control R&S Command Reference See also: c hapter 4.4, "History", on page 114. Parameters: <State> ON | OFF *RST: Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed 16.2.13.6 Search Results ..............636 SEARch: R ESDiagram: H ORZ: A BSolute: P OSition .
Page 653 ® Remote Control R&S Command Reference Parameters: <Span> Range: 0 to 100E+24 Increment: 0.01 *RST: 0.01 Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:RESDiagram:HORZ:MODE <SearchName>,<Mode> SEARch:RESDiagram:HORZ:MODE? <SearchName> Defines whether absolute or relative values are used to specify the x-axis values. Parameters: <Mode>...
Page 654 ® Remote Control R&S Command Reference Usage: SCPI confirmed SEARch:RESDiagram:SHOW <SearchName>,<ShowSearchWind> SEARch:RESDiagram:SHOW? <SearchName> If enabled, a zoom window is displayed for the currently selected search result. The zoom area is indicated in the diagram that displays the source waveform of the search. Parameters: <ShowSearchWind>...
Page 655 ® Remote Control R&S Command Reference Parameters: <Mode> ABS | REL *RST: Parameters for setting and query: <SearchName> Search definition Usage: SCPI confirmed SEARch:RESDiagram:VERT:RELative:POSition <SearchName>,<RelPosi> SEARch:RESDiagram:VERT:RELative:POSition? <SearchName> Defines the y-value of the centerpoint of the zoom area. Parameters: <RelPosi> Range: -100E+24 to 100E+24 Increment: 0.1 *RST:...
Page 656 ® Remote Control R&S Command Reference See Example: " Searching for a pulse of specified width" on page 611 Usage: SCPI confirmed SEARch:RESult:SHOW <SearchName>,<ShowResultTable> SEARch:RESult:SHOW? <SearchName> Displays or hides the search result table. Parameters: <ShowResultTable> ON | OFF *RST: Parameters for setting and query: <SearchName>...
Page 657 ® Remote Control R&S Command Reference SEARch:RESult[:ALL]? <SearchName> Returns all search results. Query parameters: <SearchName> Search definition Return values: <Data> List of search results, separated by commas. For each result, six values are returned: 1. Acquisition index, currently always 0. 2.
Page 658 ® Remote Control R&S Command Reference <SignalSource> NONE | C1W1 | C1W2 | C1W3 | C2W1 | C2W2 | C2W3 | C3W1 | C3W2 | C3W3 | C4W1 | C4W2 | C4W3 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 Source of the search, see ...
Page 659: Protocols
● General Setup.......................643 ● I²C ........................644 ● SPI........................663 ● UART........................675 ● CAN (Option R&S RTO-K3)..................684 ● LIN (Option R&S RTO-K3)..................701 ● FlexRay (Option R&S RTO-K4)................717 16.2.14.1 General Setup See also: on page 427. F ORMat: B PATtern ......................643 BUS<m>:...
Page 660 Suffix: <m> 1..4 Selects the serial bus. Parameters: <ShowResultTable> ON | OFF *RST: Usage: Asynchronous command 16.2.14.2 I²C ● Configuration......................645 ● Trigger........................647 ● Decoding Results (Option R&S RTO-K1).............654 ● Translation (Option R&S RTO-K1)................662 User Manual 1316.0827.02 ─ 06...
Page 661 ® Remote Control R&S Command Reference Configuration ....................645 BUS<m>: I 2C: S CL: S OURce ....................645 BUS<m>: I 2C: S DA: S OURce ..................645 BUS<m>: I 2C: S CL: T HReshold ..................646 BUS<m>: I 2C: S DA: T HReshold .
Page 662 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. Parameters: <SCLThreshold> User-defined clock threshold Range: -12 to 12 Increment: 0.1 *RST: Default unit: V BUS<m>:I2C:SDA:THReshold <SDAThreshold> Sets a user-defined threshold value for the data line. Alternatively, you can set the threshold according to the signal technology with BUS<m>:...
Page 663 ® Remote Control R&S Command Reference BUS<m>:I2C:RWBit <BusConfig> Defines if the R/W bit of a 7-bit address is considered separately or as part of the address. The setting defines which address lengths are available with T RIGger<m>: I 2C: AMODe...
Page 664 ® Remote Control R&S Command Reference Parameters: <Type> STARt | REPStart | STOP | NACK | ADDRess | ADOR | ADAT STARt Start condition REPStart Repeated start - the start condition occurs without previous stop condition. STOP Stop condition, end of frame NACK Missing acknowledge bit.
Page 665 ® Remote Control R&S Command Reference Parameters: <AddressNack> ON | OFF *RST: Usage: Asynchronous command TRIGger<m>:I2C:DWNack <DataWriteNack> Triggers if a date acknowledge bit is missing - the addressed slave does not accept the data. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <DataWriteNack>...
Page 666 ® Remote Control R&S Command Reference Parameters: <AddressType> BIT7 | BIT7_RW | BIT10 | ANY Available address types depend on B US<m>: I 2C: R WBit SEPa- rate | INADdress. BIT7 | BIT10 Only address bits have to be entered for address. BIT7_RW Seven address bits and also the R/W bit have to be entered for address.
Page 667 ® Remote Control R&S Command Reference TRIGger<m>:I2C:ADDTo <AddressTo> Sets the the end value of an address range if the condition is set to an address range with T RIGger<m>: I 2C: A CONdition Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: Numeric or string pattern, see ...
Page 668 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only <n> 1..4 Index of the address in an "address OR" condition (OR slot) Parameters: Numeric or string pattern, see <Address> c hapter 16.2.2.6, "Bit Pattern Parameter", on page 421.
Page 669 ® Remote Control R&S Command Reference TRIGger<m>:I2C:DPOSition <DataPosition> Sets the number of data bytes before the first byte of interest. These bytes are ignored. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <DataPosition> The index 0 is associated with the first data byte. Range: 0 to 4095 Increment: 1...
Page 670 Parameter", on page 421. The string parameter accepts the bit value X (don't care). Usage: Asynchronous command Firmware/Software: V 1.30 Decoding Results (Option R&S RTO-K1) ..................655 BUS<m>: I 2C: F RAMe<n>: D ATA .....................655 BUS<m>: I 2C: F COunt...
Page 671 ® Remote Control R&S Command Reference BUS<m>:I2C:FRAMe<n>:DATA? Returns the data words of the specified frame. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: Comma-separated list of values. To set the value format, use <Data> FORMat:...
Page 672 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: <RWBit> UNDefined | READ | WRITe | EITHer *RST: UNDefined Usage: Query only BUS<m>:I2C:FRAMe<n>:ACOMplete? Returns if the address is completely contained in the acquisition. Suffix: <m>...
Page 673 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: To set the value format, use <AddressValue> F ORMat: B PATtern The values below – range, increment and default – are decimal values.
Page 674 ® Remote Control R&S Command Reference Usage: Query only BUS<m>:I2C:FRAMe<n>:ASTart? Returns the start time of the address for the indicated frame. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: <AddressStart> Range: -100E+24 to 100E+24 Increment: 100E-12 *RST: Default unit: s Usage:...
Page 675 ® Remote Control R&S Command Reference Return values: <FrameState> INComplete | OK | UNEXpstop | INSufficient | ADDifferent INComplete The stop bit is missing. The frame is valid. UNEXpstop A stop bit was detected but clock and data are continued. INSufficient The frame is not completely contained in the acquisition.
Page 676 ® Remote Control R&S Command Reference Return values: <FrameStop> Range: -100E+24 to 100E+24 Increment: 100E-12 *RST: Default unit: s Usage: Query only BUS<m>:I2C:FRAMe<n>:BCOunt? Returns the number of bytes in the specified frame Suffix: <m> 1..4 Selects the input channel. <n> Selects the frame.
Page 677 ® Remote Control R&S Command Reference <o> Selects the byte number. Return values: To set the value format, use <ByteAckBitStart> F ORMat: B PATtern The values below – range, increment and reset – are decimal val- ues. Range: -100E+24 to 100E+24 Increment: 100E-12 *RST: Default unit: s...
Page 678 The values below – range, increment and default – are decimal values. Range: 0 to 255 Increment: 1 *RST: Usage: Query only Translation (Option R&S RTO-K1) BUS<m>:SHOWtrans <UseTranslation> Activates the protocol translation file to be used for decoding. Suffix: <m> 1..4 Selects the serial bus. Parameters: <UseTranslation>...
Page 679 Firmware/Software: FW 1.35 16.2.14.3 ● Configuration......................663 ● Trigger........................668 ● Decoding Results (Option R&S RTO-K1).............671 Configuration ....................663 BUS<m>: S PI: B ORDer ......................664 BUS<m>: S PI: W SIZe ..................664 BUS<m>: S PI: S CLK: S OURce ..................664 BUS<m>:...
Page 680 ® Remote Control R&S Command Reference BUS<m>:SPI:WSIZe <WordLength> Sets the number of bits in a message. Suffix: <m> 1..4 Selects the serial bus. Parameters: <WordLength> Number of bits Range: 4 to 32 Increment: 1 *RST: Usage: Asynchronous command BUS<m>:SPI:SCLK:SOURce <SSsource> Sets the input channel of the clock line.
Page 681 ® Remote Control R&S Command Reference BUS<m>:SPI:SSELect:POLarity <SSPolarity> Selects whether transmitted slave select signal is high active (high = 1) or low active (low = 1). Suffix: <m> 1..4 Selects the serial bus. Parameters: <SSPolarity> ACTLow | ACTHigh *RST: ACTLow Usage: Asynchronous command BUS<m>:SPI:MISO:SOURce <MISOsource>...
Page 682 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. Parameters: <MOSIsource> NONE | C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 See ...
Page 683 ® Remote Control R&S Command Reference BUS<m>:SPI:SCLK:THReshold <SCLKThreshold> BUS<m>:SPI:MISO:THReshold <MISOThreshold> BUS<m>:SPI:MOSI:THReshold <MOSIThreshold> BUS<m>:SPI:SSELect:THReshold <SSThreshold> Set user-defined threshold values for the clock, MISO, MOSI and slave select lines. Alternatively, you can set the thresholds according to the signal technology with BUS<m>:...
Page 684 ® Remote Control R&S Command Reference Parameters: <ClockTimeout> Range: 50E-9 to 10 Increment: 1E-6 *RST: 1E-3 Default unit: s Trigger ....................668 TRIGger<m>: S PI: M ODE ..................668 TRIGger<m>: S PI: P ALignment ..................669 TRIGger<m>: S PI: D POPerator .
Page 685 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <DataAlignment> WORD | BIT WORD The pattern is matched only at word boundaries. Bit-by bit: the pattern can be at any position in the data word. *RST: WORD Usage:...
Page 686 ® Remote Control R&S Command Reference TRIGger<m>:SPI:DPTO <DataPositionTo> Defines the last bit or word of interest, if is set to T RIGger<m>: S PI: D POPerator INRange. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <DataPositionTo>...
Page 687 16.2.2.6, "Bit Pattern Parameter", on page 421. The string parameter accepts the bit value X (don't care). Usage: Asynchronous command Decoding Results (Option R&S RTO-K1) ..................671 BUS<m>: S PI: F RAMe<n>: D ATA .....................671 BUS<m>: S PI: F COunt...
Page 688 ® Remote Control R&S Command Reference Usage: Query only Firmware/Software: V 1.27 BUS<m>:SPI:FRAMe<n>:STATus? Returns the overall state of the specified frame. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: <FrameState> OK | VOID | INCFirst | INCLast | INSufficient OK: the frame is valid.
Page 689 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: <FrameStop> Range: -100E+24 to 100E+24 Increment: 100E-12 *RST: Default unit: s Usage: Query only BUS<m>:SPI:FRAMe<n>:WCOunt? Returns the number of words in the specified frame. Suffix: <m>...
Page 690 ® Remote Control R&S Command Reference Usage: Query only BUS<m>:SPI:FRAMe<n>:WORD<o>:STOP? Returns the end time of the specified data word. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. <o> Selects the word number. Return values: <WordStop> Range: -100E+24 to 100E+24 Increment: 100E-12 *RST: Default unit: s...
Page 691 UART Configuration....................675 ● UART Trigger......................679 ● Decoding Results (Option R&S RTO-K1).............682 UART Configuration ..................675 BUS<m>: U ART: R X: S OURce ...................676 BUS<m>: U ART: T X: S OURce ..................676 BUS<m>: U ART: R X: T HReshold...
Page 692 ® Remote Control R&S Command Reference Parameters: <RxSource> NONE | C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | R1 | R2 | R3 | R4 See c hapter 16.2.2.2, "Waveform Parameter", on page 419 *RST: NONE Usage:...
Page 693 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. Parameters: <TxThreshold> User-defined clock threshold Range: -12 to 12 Increment: 0.1 *RST: Default unit: V BUS<m>:UART:TECHnology <Technology> Sets the threshold voltage Tx and Rx lines as defined for various signal technologies. Suffix: <m>...
Page 694 ® Remote Control R&S Command Reference BUS<m>:UART:BAUDrate <Bitrate> Same as B US<m>: U ART: B ITRate Suffix: <m> 1..4 Parameters: <Bitrate> Range: 300 to 20000000 Increment: 1 *RST: 9600 Default unit: bps Usage: Asynchronous command BUS<m>:UART:PARity <Parity> Defines the optional parity bit that is used for error detection. See also: ...
Page 695 ® Remote Control R&S Command Reference BUS<m>:UART:POLarity <Polarity> Defines the idle state of the bus. The idle state corresponds to a logic 1. The transmitted data on the bus is high (high = 1) or low (low = 1) active. Suffix: <m>...
Page 696 ® Remote Control R&S Command Reference ....................681 TRIGger<m>: U ART: D ATA TRIGger<m>:UART:TYPE <Type> Selects the trigger type for UART analysis. See also: " Type" on page 282 Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <Type>...
Page 697 ® Remote Control R&S Command Reference TRIGger<m>:UART:DPOSition <DataPosition> Sets the number of words before the first word of interest. These offset words are ignored. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <DataPosition> Number of words Range: 0 to 32767 Increment: 1...
Page 698 Parameter", on page 421. The string parameter accepts the bit value X (don't care). Usage: Asynchronous command Decoding Results (Option R&S RTO-K1) ................682 BUS<m>: U ART: W ORD<n>: R XValue ................682 BUS<m>: U ART: W ORD<n>: T XValue...
Page 699 ® Remote Control R&S Command Reference BUS<m>:UART:WORD<n>:SOURce? Returns the line on which the specified word was transferred. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the word. Return values: <WordSource> TX | RX *RST: Usage: Query only BUS<m>:UART:WORD<n>:STARt? Returns the start time of the specified word. Suffix: <m>...
Page 700 PRERror:PaRity ERror, incorrect parity bit. INSufficient: The frame is not completely contained in the acqui- sition. The acquired part of the frame is valid. *RST: Usage: Query only 16.2.14.5 CAN (Option R&S RTO-K3) ● Configuration....................684 ● Trigger......................687 ● CAN Decoding Results..................694...
Page 701 ® Remote Control R&S Command Reference BUS<m>:CAN:TYPE <SignalType> Selects the CAN-High or CAN-Low line. Both lines are required for differential signal transmission used by CAN. Suffix: <m> 1..4 Selects the serial bus. Parameters: <SignalType> CANH | CANL *RST: CANL BUS<m>:CAN:DATA:THReshold <Threshold> Sets a user-defined threshold value.
Page 702 ® Remote Control R&S Command Reference Parameters: <Technology> V25 | V3 | V2 | V0 | MAN 2.5 Volt (CMOS 5.0 V) 3.0 Volt (CAN_H HS / CAN_L LS) 2.0 Volt (CAN_L HS / CAN_H LS) Ground Manual setting of user-defined values with B US<m>:...
Page 703 ® Remote Control R&S Command Reference BUS<m>:CAN:T1Segment <TimeSeg1> BUS<m>:CAN:T2Segment <TimeSeg2> Set the number of time quanta before the sample point (T1Segment) and after the sample point (T2Segment). T1Segment comprises the segments Synch_seg, Prop_seg, and Phase_seg1 which are specified in the CAN standard. T2Segment matches Phase_seg2 specified in the CAN standard.
Page 704 ® Remote Control R&S Command Reference ....................692 TRIGger<m>: C AN: D LC ...................692 TRIGger<m>: C AN: A CKerror ..................693 TRIGger<m>: C AN: B ITSterror ...................693 TRIGger<m>: C AN: C RCerror ..................693 TRIGger<m>: C AN: F ORMerror TRIGger<m>:CAN:TYPE <Type>...
Page 705 ® Remote Control R&S Command Reference For data and remote frames, the identifier format has to be set with T RIGger<m>: CAN: I TYPe See also: " Frame type" on page 290 Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <FrameType>...
Page 706 ® Remote Control R&S Command Reference Parameters: <IdentifierOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan | INRange | OORange EQUal | NEQual | LTHan | LETHan | GTHan | GETHan Equal, Not equal, Less than, Less or equal than, Greater Than, Greater or equal than.
Page 707 ® Remote Control R&S Command Reference Parameters: <DataOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan | INRange | OORange EQUal | NEQual | LTHan | LETHan | GTHan | GETHan Equal, Not equal, Less than, Less or equal than, Greater Than, Greater or equal than.
Page 708 ® Remote Control R&S Command Reference Parameters: <Endianness> BENDian | LENDian BENDian Big endian, most significant byte first. LENDian Little endian, least significant byte first. *RST: BENDian TRIGger<m>:CAN:DLCCondition <DLCOperator> Operator to set the data length code for triggering on CAN data. For big endian transfer direction, you can trigger on a number of bytes less than the DLC of the frame, that means, on the beginning of the data pattern.
Page 709 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <AckError> ON | OFF *RST: TRIGger<m>:CAN:BITSterror <BitStuffingError> Triggers if astuff error occurs - when the 6th consecutive equal bit level in the mentioned fields is detected.
Page 710 ® Remote Control R&S Command Reference CAN Decoding Results ....................694 BUS<m>: C AN: F COunt .................694 BUS<m>: C AN: F RAMe<n>: S TATus ...................695 BUS<m>: C AN: F RAMe<n>: S TARt ..................695 BUS<m>: C AN: F RAMe<n>: S TOP .
Page 711 ® Remote Control R&S Command Reference Return values: <FrameState> OK | BTST | CRCD | ACKD | CRC | EOFD | NOACk | CAERror | FCERor | INSufficient OK: the frame is valid. BTST: Bit stuffing error occured. CRCD: Wrong CRC delimiter occured. ACKD: Wrong ACK delimiter occured.
Page 712 ® Remote Control R&S Command Reference Return values: <FrameType> DATA | REMote | ERR | OVLD Data, remote, error or overload frame. *RST: DATA Usage: Query only BUS<m>:CAN:FRAMe<n>:DATA? Returns the data bytes of the specified frame. Suffix: <m> 1..4 Selects the serial bus. <n>...
Page 713 ® Remote Control R&S Command Reference BUS<m>:CAN:FRAMe<n>:ACKValue? Returns the value of the acknowledge slot for the selected frame. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: To set the value format, use <AckValue> F ORMat: B PATtern The values below –...
Page 714 ® Remote Control R&S Command Reference <n> Selects the frame. Return values: <DataLengthCode> Number of data bytes in decimal values. Range: 0 to 15 Increment: 1 *RST: Usage: Query only BUS<m>:CAN:FRAMe<n>:IDTYpe? Returns the identifier type of the selected frame, the identifier format of data and remote frames.
Page 715 ® Remote Control R&S Command Reference BUS<m>:CAN:FRAMe<n>:BSEPosition? Returns the location of a bit stuffing error. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: <BitStuffingErrorPos> Time when the error occured Range: -100E+24 to 100E+24 Increment: 100E-12 *RST: Default unit: s Usage:...
Page 716 ® Remote Control R&S Command Reference <o> Selects the byte number. Return values: To set the value format, use <ByteValue> F ORMat: B PATtern The values below – range, increment and reset – are decimal val- ues. Range: 0 to 255 Increment: 1 *RST: Usage:...
Page 717 ® Remote Control R&S Command Reference 16.2.14.6 LIN (Option R&S RTO-K3) ● Configuration....................701 ● Trigger......................703 ● LIN Decoding Results...................710 ● Translation......................716 LIN Configuration ..................701 BUS<m>: L IN: D ATA: S OURce ..................701 BUS<m>: L IN: D ATA: T HReshold...
Page 718 ® Remote Control R&S Command Reference BUS<m>:LIN:TECHnology <Technology> Sets the threshold voltage as defined for various signal technologies. Suffix: <m> 1..4 Selects the serial bus. Parameters: <Technology> V15 | V25 | V35 | V6 | V9 | MAN 1.5 Volt (TTL) 2.5 Volt (CMOS 5.0 V) V35 | V6 | V9 3.5 V (7 V supply), 6.0 V (12 V supply), 9.0 V (18 V supply) respec-...
Page 719: Lin Trigger
® Remote Control R&S Command Reference BUS<m>:LIN:STANdard <Standard> Selects the version of the LIN standard. See also: " LIN standard" on page 299 Suffix: <m> 1..4 Selects the serial bus. Parameters: <Standard> V1X | V2X | J2602 | AUTO *RST: AUTO LIN Trigger...
Page 720 ® Remote Control R&S Command Reference Parameters: <Type> SYNC | ID | IDOR | IDDT | WKFR | ERRC SYNC Start of the frame, triggers on the stop bit of the sync field. Sets the trigger to one specific identifier or an identifier range. To set the identifier, use ...
Page 721 ® Remote Control R&S Command Reference Parameters: <IdentifierOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan | INRange | OORange EQUal | NEQual | LTHan | LETHan | GTHan | GETHan Equal, Not equal, Less than, Less or equal than, Greater Than, Greater or equal than.
Page 722 ® Remote Control R&S Command Reference Parameters: <DataOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan | INRange | OORange EQUal | NEQual | LTHan | LETHan | GTHan | GETHan Equal, Not equal, Less than, Less or equal than, Greater Than, Greater or equal than.
Page 723 ® Remote Control R&S Command Reference Parameters: <Endianness> BENDian | LENDian BENDian Big endian, data is analyzed and evaluated in the order of recep- tion. LENDian Little endian, the instrument reads the complete data and then compares it with the data pattern in reverse order. *RST: BENDian TRIGger<m>:LIN:DLECondition <DLCOperator>...
Page 724 ® Remote Control R&S Command Reference Parameters: <WordCount> Range: 1 to 8 Increment: 1 *RST: TRIGger<m>:LIN:IDOR<n>:ENABle <UseIdentifier> Includes the indicated IDOR address in the "identifier OR" trigger condition. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only <n>...
Page 725 ® Remote Control R&S Command Reference TRIGger<m>:LIN:IPERror <IdParityError> Triggers if an error occurs in the identifier parity bits. These are the bits 6 and 7 of the identifier. The trigger type has to be set before: to ERRC. T RIGger<m>: L IN: T YPE Suffix: <m>...
Page 726 ® Remote Control R&S Command Reference TRIGger<m>:LIN:CRCDatalen <CRCDataLength> Sets the number of data bytes to trigger on CRC errors ( is set T RIGger<m>: L IN: T YPE to ERRC and is set ON.) T RIGger<m>: L IN: C HKSerror Suffix: <m>...
Page 727 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. Return values: <Count> Total number of decoded frames. Usage: Query only BUS<m>:LIN:FRAMe<n>:STATus? Returns the overall state of the selected frame. Suffix: <m> 1..4 Selects the serial bus. <n>...
Page 728 ® Remote Control R&S Command Reference Return values: <FrameStart> Range: -100E+24 to 100E+24 <FrameStop> Increment: 100E-12 *RST: Default unit: s Usage: Query only BUS<m>:LIN:FRAMe<n>:VERSion? Returns the version of the LIN standard for the specified frame. Suffix: <m> 1..4 Selects the serial bus. <n>...
Page 729 ® Remote Control R&S Command Reference Return values: <IdentifierState> OK | STERror | SPERror | PRERror | UVAL | NOEXists | INSufficient STERror: start error SPERror: stop error PRERror: parity error UVAL: unexpected value NOEXists: byte does not exist INSufficient: the frame is not completely contained in the acquisi- tion.
Page 730 ® Remote Control R&S Command Reference Return values: To set the value format, use <IdentifierParity> F ORMat: B PATtern The values below – range, increment and reset – are decimal val- ues. Range: 0 to 3 Increment: 1 *RST: Usage: Query only BUS<m>:LIN:FRAMe<n>:SYSTate?
Page 731 ® Remote Control R&S Command Reference Return values: <ChecksumState> OK | STERror | SPERror | UVAL | NOEXists | INSufficient STERror: start error SPERror: stop error UVAL: unexpected value NOEXists: byte does not exist INSufficient: the frame is not completely contained in the acquisi- tion.
Page 732 ® Remote Control R&S Command Reference Return values: <ByteState> OK | STERror | SPERror | UVAL | NOEXists | INSufficient STERror: start error SPERror: stop error UVAL: unexpected value NOEXists: byte does not exist INSufficient: the frame is not completely contained in the acquisi- tion.
Page 733 Selects the frame, number of the frame in the current acquisition, 1...n. Return values: <Translation> String with the ID Name (label) Example: BUS:LIN:FRAMe2:TRANslation? Response: Temperature Usage: Query only Firmware/Software: FW 1.35 16.2.14.7 FlexRay (Option R&S RTO-K4) ● FlexRay Configuration...................717 ● FlexRay Trigger.....................722 ● FlexRay Decoding Results..................732 ● Translation......................737 FlexRay Configuration .
Page 734 ® Remote Control R&S Command Reference Parameters: <SourceType> SINGle | DIFFerential | LOGic SINGle Used for measurements with single-ended probes or single-ended voltage measurements with differential probes on the FlexRay bus. Two thresholds have to be defined as absolute voltage levels, see ...
Page 735 ® Remote Control R&S Command Reference Parameters: <THResholds> Differential or absolute voltage level, depending on the source type. See on page 717. B US<m>: F LXRay: S RCType BUS<m>:FLXRay:THENable <ThresholdEnable> Sets the threshold for the enable line if the source type is LOGic. Suffix: <m>...
Page 736 ® Remote Control R&S Command Reference Parameters: <PresetSingleEnded> CM2500mv150mv | CM2500mv200mv | CM2500mv250mv | CM2500mv300mv | MAN CM2500mv150mv | CM2500mv200mv | CM2500mv250mv | CM2500mv300mv 2.5 ± 0.15 V; 2.5 ± 0.2 V; 2.5 ± 0.25 V; 2.5 ± 0.3 V, respectively Manual setting of user-defined values with ...
Page 737 ® Remote Control R&S Command Reference BUS<m>:FLXRay:POLarity <Polarity> Selects the wire on which the bus signal is measured in case of SINGle source type. The setting affects the digitization of the signal. Suffix: <m> 1..4 Selects the serial bus. Parameters: <Polarity>...
Page 738: Flexray Trigger
® Remote Control R&S Command Reference Parameters: <SeparateHeaderBits> ON | OFF *RST: FlexRay Trigger ...................722 TRIGger<m>: F LXRay: T YPE .................723 TRIGger<m>: F LXRay: P LPReamble ..................724 TRIGger<m>: F LXRay: N UFRame ..................724 TRIGger<m>: F LXRay: S YFRame .
Page 739 ® Remote Control R&S Command Reference Parameters: <Type> STOF | IDDT | SYMBol | ERRC STOF STart Of Frame: triggers on the first rising edge after the trans- mission start sequence (TSS). IDDT IDentifier and DaTa: triggers on the decoded frame content, on header and payload data.
Page 740 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <PayloadPreamble> ONE | ZERO | DC Bit value: 1, 0, or X (don't care) *RST: TRIGger<m>:FLXRay:NUFRame <NullFrame> Triggers on the null frame indicator bit, a frame without usable data. Suffix: <m>...
Page 741 ® Remote Control R&S Command Reference TRIGger<m>:FLXRay:FCONdition <IdentifierOperator> Sets the operator to set a frame ID or a frame ID range. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <IdentifierOperator> OFF | EQUal | NEQual | LTHan | LETHan | GTHan | GETHan | INRange | OORange The frame ID is not relevant for the trigger condition.
Page 742 ® Remote Control R&S Command Reference TRIGger<m>:FLXRay:PCONdition <PLOperator> Sets the operator for the payload length trigger setting. You can defined an exact value, or a range. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <PLOperator> OFF | EQUal | NEQual | LTHan | LETHan | GTHan | GETHan | INRange | OORange The payload length is not relevant for the trigger condition.
Page 743 ® Remote Control R&S Command Reference Parameters: <PayloadLengthTo> Range: 0 to 127 Increment: 1 *RST: TRIGger<m>:FLXRay:CENable <CycleCount> Sets the operator to define a cycle count or a cycle count range. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <CycleCount>...
Page 744 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <CycleCountTo> Range: 0 to 63 Increment: 1 *RST: TRIGger<m>:FLXRay:CSTep <CycleCountStep> Specifies a step to trigger on each n-th cycle inside the given range. This allows for specific triggering if slot multiplexing is used.
Page 745 ® Remote Control R&S Command Reference TRIGger<m>:FLXRay:DPOSition <DataPosition> Sets the number of data bytes to be skipped after start of the payload segment Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <DataPosition> Range: 0 to 255 Increment: 1 *RST: TRIGger<m>:FLXRay:DPTO <DataPositionTo>...
Page 746 ® Remote Control R&S Command Reference TRIGger<m>:FLXRay:DMIN <DataPattern> Specifies a data pattern, or sets the the start value of a data pattern range. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: Numeric or string pattern, see <DataPattern>...
Page 747 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <BSSError> ON | OFF *RST: TRIGger<m>:FLXRay:FESerror <FESError> Triggers on error in Frame End Sequence. FES indicates the end of each frame. Suffix: <m>...
Page 748 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <CRCPayloadError> ON | OFF *RST: FlexRay Decoding Results ....................732 BUS<m>: F LXRay: F COunt ................732 BUS<m>: F LXRay: F RAMe<n>: S TATus .
Page 749 ® Remote Control R&S Command Reference Return values: <FrameState> OK | FSS | BSS | FES | INDicator | HCRCerror | CRCerr | LENER | WAKeup | MTS | INSufficient OK: the frame is valid. FSS: Frame Start Sequence after TSS is missing. BSS: Byte Start Sequence is missing.
Page 750 ® Remote Control R&S Command Reference Return values: <FrameType> UNKNown | STATic | DYNamic | WAKE | SYMBol STATic: frame of the static segment DYNamic: frame of the dynamic segment WAKE: frame contains wakeup pattern SYMBol: frame contains a MTS or CAS symbol *RST: STATic Usage:...
Page 751 ® Remote Control R&S Command Reference Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: To set the value format, use <FrameIDvalue> on page 427. F ORMat: B PATtern The values below – range, increment and default – are decimal values.
Page 752 ® Remote Control R&S Command Reference Usage: Query only BUS<m>:FLXRay:FRAMe<n>:CSSTate? Returns the state of the cyclic redundancy check code of the header data. Suffix: <m> 1..4 Selects the serial bus. <n> Selects the frame. Return values: <HeaderCRCstate> OK | UVAL | INSufficient OK: the CRC is valid.
Page 753 ® Remote Control R&S Command Reference <n> Selects the frame. Return values: <FrameCRCstate> OK | UVAL | INSufficient OK: the CRC is valid. UVAL: unexpected value INSufficient: the frame is not completely contained in the acquisi- tion. The decoded part of the frame is valid. *RST: Usage: Query only...
Page 754: Mixed Signal Option (Mso, R&S Rto-B1)
String with the ID Name (label) Example: BUS:FLXRay:FRAMe2:TRANslation? Response: Temperature Usage: Query only Firmware/Software: FW 1.35 16.2.15 Mixed Signal Option (MSO, R&S RTO-B1) This chaptes decribes the remote commands of MSO option R&S RTO-B1. ● Digital Channels....................738 ● Parallel Bus Configuration..................739 ●...
Page 755 NORMAL The instrument sets a value suitable for the signal and its settings. Firmware/Software: V 1.30 16.2.15.2 Parallel Bus Configuration The following commands configure the four parallel buses of R&S RTO-B1. User Manual 1316.0827.02 ─ 06...
Page 756 ® Remote Control R&S Command Reference ....................740 BUS<m>: P ARallel: S TATe ....................740 BUS<m>: P ARallel: B IT<n> ..................740 BUS<m>: P ARallel: D ISPlay: S HDI ...................741 BUS<m>: P ARallel: D ISPlay: S HBU ..................741 BUS<m>:...
Page 757 ® Remote Control R&S Command Reference Parameters: <ShowDigitalSigns> ON | OFF *RST: Firmware/Software: V 1.30 BUS<m>:PARallel:DISPlay:SHBU <ShowBus> Shows or hides the indicated parallel bus. If enabled, the resulting bus signal and bus values are displayed in the diagram. Suffix: <m> 1..4 Selects the parallel bus.
Page 758 ® Remote Control R&S Command Reference Parameters: <ClockSource> D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D9 | D10 | D11 | D12 | D13 | D14 | D15 Clock channel *RST: Firmware/Software: V 1.30 BUS<m>:PARallel:CLEar...
Page 759 For this source, only the analog edge trigger is available. SBUS Serial bus D0...D15 Digital channels (option R&S RTO-B1) LOGIc Logic combination of digital channels, used as trigger source (option R&S RTO-B1) MSOB1 | MSOB2 | MSOB3 | MSOB4 Parallel bus (option R&S RTO-B1)
Page 760 ® Remote Control R&S Command Reference Parameters: <Type> EDGE | WIDTh | TIMeout | DATatoclock | STATe | PATTern | SERPattern *RST: EDGE TRIGger<m>:PARallel:DATatoclock:CSOurce[:VALue] <ClockSource> TRIGger<m>:PARallel:STATe:CSOurce:VALue <ClockSource> TRIGger<m>:PARallel:SPATtern:CSOurce[:VALue] <ClockSource> Selects the digital channel of the clock signal. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <ClockSource>...
Page 761 ® Remote Control R&S Command Reference TRIGger<m>:PARallel:EDGE:SLOPe <Slope> Defines the edge - the state transition - of the signal to trigger on a single digital channel (a logic bit), or a logical combination of digital channels. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <Slope>...
Page 762 ® Remote Control R&S Command Reference Parameters: <RangeMode> WITHin | OUTSide | SHORter | LONGer WITHin | OUTSide Pulses inside or outside a given time range. The time range Width ± Delta is defined by T RIGger<m>: P ARallel: W IDTh: W IDTh and ...
Page 763 ® Remote Control R&S Command Reference Timeout Trigger See also: ● on page 744 T RIGger<m>: P ARallel: T IMeout: E XPRession[: D EFine] ................747 TRIGger<m>: P ARallel: T IMeout: R ANGe ................747 TRIGger<m>: P ARallel: T IMeout: T IME TRIGger<m>:PARallel:TIMeout:RANGe <TimeoutMode>...
Page 764 ® Remote Control R&S Command Reference TRIGger<m>:PARallel:DATatoclock:CSOurce:EDGE <ClockEdge> Sets the edge of the clock signal. The crossing of the clock edge and the logical threshold defines the time reference point for the setup and hold time measurement. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <ClockEdge>...
Page 765 ® Remote Control R&S Command Reference ● on page 744 T RIGger<m>: P ARallel: S TATe: E XPRession[: D EFine] ..............749 TRIGger<m>: P ARallel: S TATe: C SOurce: E DGE ................749 TRIGger<m>: P ARallel: S TATe: B IT<n> TRIGger<m>:PARallel:STATe:CSOurce:EDGE <Slope>...
Page 766 ® Remote Control R&S Command Reference TRIGger<m>:PARallel:PATTern:MODE <Mode> Sets the mode of the timing condition. Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <Mode> OFF | TIMeout | WIDTh No timing condition, only the logical pattern condition is relevant. TIMeout Defines a minimum time qualification to avoid triggering on unsta- ble or transitional conditions.
Page 767 ® Remote Control R&S Command Reference Suffix: <m> 1..3 Event in a trigger sequence: 1 = A-event only Parameters: <Time> Range: 100E-12 to 10000 Increment: 100E-9 *RST: 100E-9 Default unit: s TRIGger<m>:PARallel:PATTern:WIDTh:RANGe <WidthRangeMode> Selects how the range of a pulse width is defined if T RIGger<m>:...
Page 768 ® Remote Control R&S Command Reference Parameters: <Width> Range: 100E-12 to 10000 Increment: 100E-9 *RST: 5E-9 Default unit: s TRIGger<m>:PARallel:PATTern:WIDTh:DELTa <WidthDelta> Defines a range around the width value set with T RIGger<m>: P ARallel: P ATTern: WIDTh[: W IDTh] Suffix: <m>...
Page 769: Data Management
® Remote Control R&S Command Reference Parameters: Numeric or string pattern, see <Pattern> c hapter 16.2.2.6, "Bit Pattern Parameter", on page 421. The bit value X (don't care) is not allowed. 16.2.16 Data Management ● MMEMory Commands..................753 ● Data Export......................759 ●...
Page 770 ® Remote Control R&S Command Reference MMEMory:DRIVes? Returns a list of the logical drives of the instrument as configured in the operating system. Return values: <Drive> List of strings, for example, "C:\","F:\","H:\" Usage: Query only MMEMory:MSIS [<msus>] Changes the default storage device to the indicated drive or network server. Parameters: <msus>...
Page 771 ® Remote Control R&S Command Reference Example: MMEM:DCAT:LENG? Usage: Query only MMEMory:CDIRectory [<DirectoryName>] Changes the default directory for file access. Parameters: <DirectoryName> String parameter to specify the directory. If the string also contains a drive letter or network server name, the command M MEMory:...
Page 772 ® Remote Control R&S Command Reference Query parameters: <PathName> String parameter to specify the directory. If the directory is omitted, the command queries directory specified with M MEMory: CDIRectory <Format> ALL | WTIMe ALL: Extended result including file, date, time and attributes WTIMe: Extended result including file, date, time Return values: <UsedMemory>...
Page 773 M MEMory: C DIRectory Example: MMEM:COPY 'C:\Documents and Settings\All Users\ Documents\Rohde-Schwarz\RTO\RefWaveforms\ RefCurve_2011-03-16*.bin','E:' Copies all reference waveforms saved on March 16, 2011 to an external storage medium, mapped to drive E:\. Usage:...
Page 774 ® Remote Control R&S Command Reference Usage: Setting only SCPI confirmed MMEMory:DATA <FileName>, <Data> MMEMory:DATA? <FileName> Stores data in the specified file to the storage location specified using M MEMory: CDIRectory Parameters: <Data> <block> 488.2 block data format. The delimiter EOI must be selected to achieve correct data transfer.
Page 775 ® Remote Control R&S Command Reference Example: MMEM:ATTR? 'C:\USER\DATA\*.*' "Datei1.LOG,A", "Datei2.LOG,A", "Datei3.LOG,ASH", "Datei4.DLL,RSH", "Datei5.INI,SH" MMEMory:STORe:STATe <MemoryNumber>, <FileName> Stores the instrument settings from the specified internal memory to the specified file. To store the current instrument settings to the internal memory, use first.
Page 776 ® Remote Control R&S Command Reference ....................761 EXPort: W AVeform: S TOP ....................761 EXPort: W AVeform: Z OOM ..................761 EXPort: W AVeform: C URSorset ....................762 EXPort: W AVeform: M EAS ..................762 EXPort: W AVeform: D LOGging .
Page 777 ® Remote Control R&S Command Reference EXPort:WAVeform:STARt <Start> Sets the start value of the waveform section for export, if E XPort: W AVeform: S COPe set to Manual. Parameters: <Start> Range: -100E+24 to 100E+24 Increment: 0.01 *RST: 0.01 Default unit: s Firmware/Software: V 1.25 EXPort:WAVeform:STOP <Stop>...
Page 778 ® Remote Control R&S Command Reference EXPort:WAVeform:MEAS <MeasGate> Sets the gate to be used for limited data export if is set to E XPort: W AVeform: S COPe GATE. Parameters: <MeasGate> MEAS1 | MEAS2 | MEAS3 | MEAS4 | MEAS5 | MEAS6 | MEAS7 | MEAS8 | IMEAS Measurement for which the gate is defined.
Page 779 ® Remote Control R&S Command Reference 16.2.16.3 Output Control Commands The HCOPy subsystem and some other commands control the output of display infor- mation for documentation purposes on output devices or files. The instrument allows two independent output configurations which can be set separately with the suffix. Programming Examples Saving a screenshot to file Saves three display images in bmp format to the files Print.bmp, Print_001.bmp,...
Page 780 ® Remote Control R&S Command Reference Parameters: <Medium> MMEM | SYST:COMM:PRIN | SYST:COMM:CLIP String parameter MMEM Directs the display image to a file. The command M MEMory: N AME defines the file name. The file format is defined with H COPy:...
Page 781 ® Remote Control R&S Command Reference HCOPy:PAGE:ORIentation<1..2> <Orientation> Defines the page orientation for output of the display image to a printer. To set the output to printer, use with parameter H COPy: D ESTination<1..2> 'SYST:COMM:PRIN'. Suffix: 1..2 Selects the output configuration. Parameters: <Orientation>...
Page 782 ® Remote Control R&S Command Reference Suffix: <m> 1..2 Selects the output configuration. Parameters: <PrintColorSet> DEF1 | DEF4 DEF1 Current screen colors with white background and black grid. DEF4 Current screen colors without any changes (black background). *RST: DEF1 HCOPy:IMMediate<m>[:DUM] Starts the immediate output of the display image to printer, file, or clipboard, depending on the ...
Page 783: General Instrument Setup
® Remote Control R&S Command Reference SYSTem:COMMunicate:PRINter:ENUMerate[:NEXT]? Queries the name of the next printer installed under Windows. The command should be sent S YSTem: C OMMunicate: P RINter: E NUMerate: F IRSt previously to return to the beginning of the printer list and query the name of the first printer.
Page 784 ® Remote Control R&S Command Reference SYSTem:DATE <Year>, <Month>, <Day> Sets the date of the internal calendar. Parameters: <Year> Year, to be entered as a four-digit number (including the century and millenium information) <Month> Month, 1 (January) to 12 (December) <Day>...
Page 785 ® Remote Control R&S Command Reference Parameters: <ComputerName> Name string DIAGnostic:SERVice:PARTnumber <MaterialNumber> Returns the material number of your instrument. This number is required to order a new option, and in case of service. Parameters: <MaterialNumber> Number string DIAGnostic:SERVice:SERialnumber? Returns the serial number of your instrument. This number is required to order a new option, and in case of service.
Page 786 ® Remote Control R&S Command Reference Positive error numbers are instrument-dependent. Negative error numbers are reserved by the SCPI standard. Return values: <Error> List of: Error/event_number,"Error/event_description>[;Device- dependent info]" If the queue is empty, the response is 0,"No error" Usage: Query only SCPI confirmed SYSTem:ERRor[:NEXT]? Queries the error/event queue for the oldest item and removes it from the queue.
Page 787: Maintenance
® Remote Control R&S Command Reference SYSTem:ERRor:COUNt? Queries the number of entries in the error queue. Return values: <Count> If the queue is empty, the response is 0 Usage: Query only SCPI confirmed 16.2.18 Maintenance ................771 DIAGnostic: S ERVice: S TST: E XECute .
Page 788 ® Remote Control R&S Command Reference 16.2.19.1 STATus:QUEStionable Registers The commands of the STATus:QUEStionable subsystem control the status reporting structures of the STATus:QUEStionable registers: Fig. 16-4: Structure of the STATus:QUEStionable register See also: ● c hapter 16.1.6.1, "Structure of a SCPI Status Register", on page 406 ●...
Page 789 ® Remote Control R&S Command Reference ..............773 STATus: Q UEStionable: M ARGin: C ONDition .................773 STATus: Q UEStionable: M ASK: C ONDition ..............773 STATus: Q UEStionable: C OVerload: E NABle ..............773 STATus: Q UEStionable: T EMPerature: E NABle .
Page 790 ® Remote Control R&S Command Reference Example: STATus:QUEStionable:MASK:ENABle 24 Set bits no. 3 and 4 of the STATus:QUEStionable:MASK:ENABle register part: 24 = 8 + 16 = 2 Usage: SCPI confirmed STATus:QUEStionable:COVerload[:EVENt]? STATus:QUEStionable:TEMPerature[:EVENt]? STATus:QUEStionable:LIMit[:EVENt]? STATus:QUEStionable:MARGin[:EVENt]? STATus:QUEStionable:MASK[:EVENt]? Returns the contents of the EVENt part of the status register to check whether an event has occurred since the last reading.
Page 791 ® Remote Control R&S Command Reference Example: STATus:QUEStionable:MASK:PTRansition 24 Set bits no. 3 and 4 of the STATus:QUEStionable:MASK:PTRan- sition register part: 24 = 8 + 16 = 2 Usage: SCPI confirmed User Manual 1316.0827.02 ─ 06...
Page 792: A Menu Overview
Menu item Description Corresponding key Exit Shuts down the firmware. Minimize Application Shows the Windows desktop with the application icon of the R&S RTO firmware. Board Detection / Mainte- c hapter 15.6.1, "Board Detection/Mainte- nance nance", on page 387 ...
Page 793: Horizontal Menu
Segmentation", on page 35 FFT Setup c hapter 6.3.3.1, "FFT Setup", on page 198 Reference c hapter 2.3.5.1, "Reference (OCXO, Option RTO- B4)", on page 51 Skew c hapter 2.3.5.2, "Skew", on page 51 A.3 Trigger Menu...
Page 794: Vertical Menu
® Menu Overview R&S Vertical Menu A.4 Vertical Menu Menu item Description Corresponding key Channels CH<N> c hapter 2.3.2.1, "Channels", on page 38 Power Calculation c hapter 2.3.2.2, "Power Calculation", on page 40 Probe Setup c hapter 2.3.3.1, "Setup", on page 41 Probe Auto Zero Performs an automatic correction of the zero error.
Page 795: A.7 Meas Menu
® Menu Overview R&S Meas Menu A.7 Meas Menu Menu item Description Corresponding key ● Setup MEAS c hapter 5.2.3.2, "Measurements Setup - General Settings", on page 158 Also activates the ● c hapter 5.2.3.3, "Measurements Setup - Ampli- measurement tude/Time ", on page 161...
Page 796: A.10 Protocol Menu
® Menu Overview R&S Protocol Menu Menu item Description Corresponding key Result Presentation c hapter 9.3.3, "Result Presentation", on page 246 Noise Reject c hapter 9.3.4, "Noise Reject", on page 248 A.10 Protocol Menu Menu item Description Corresponding key Serial buses Configuration a PROTOCOL...
Page 797 ® Menu Overview R&S Display Menu Menu item Description Corresponding key Toolbar c hapter 4.1.3.4, "Toolbar", on page 100 Signal Bar State Switches the signal bar on or off. c hapter 4.1.2.2, "Using the Signal bar", on page 91 User Manual 1316.0827.02 ─...
Page 798: List Of Commands
® List of Commands R&S List of Commands *CAL ................................422 *CLS ................................422 *ESE ................................423 *ESR ................................423 *IDN ................................423 *IST ................................423 *OPC ................................423 *OPT ................................424 *PCB ................................424 *PRE ................................424 *PSC ................................424 *RCL...
Page 799 ® List of Commands R&S BUS<m>: C AN: F RAMe<n>: D LCValue ......................697 BUS<m>: C AN: F RAMe<n>: I DSTate ......................696 BUS<m>: C AN: F RAMe<n>: I DTYpe .......................698 BUS<m>: C AN: F RAMe<n>: I DValue .......................698 BUS<m>:...
Page 800 ® List of Commands R&S BUS<m>: I 2C: F RAMe<n>: A DEVice .......................657 BUS<m>: I 2C: F RAMe<n>: A MODe .........................657 BUS<m>: I 2C: F RAMe<n>: A STart ........................658 BUS<m>: I 2C: F RAMe<n>: B COunt .........................660 BUS<m>:...
Page 801 ® List of Commands R&S BUS<m>: P ARallel: D ISPlay: S HDI ........................740 BUS<m>: P ARallel: S TATe ..........................740 BUS<m>: P ARallel: T HCoupling ........................742 BUS<m>: R ESult ............................644 BUS<m>: S HOWtrans ............................662 BUS<m>: S HOWtrans ............................700 BUS<m>:...
Page 802 ® List of Commands R&S BUS<m>: U ART: W ORD<n>: R XValue ......................682 BUS<m>: U ART: W ORD<n>: S OURce ......................683 BUS<m>: U ART: W ORD<n>: S TARt .......................683 BUS<m>: U ART: W ORD<n>: S TATe .......................683 BUS<m>:...
Page 803 ® List of Commands R&S CHANnel<m>: D IGFilter: S TATe ........................450 CHANnel<m>: E ATScale ..........................444 CHANnel<m>: E ATTenuation .........................444 CHANnel<m>: G ND ............................437 CHANnel<m>: I MPedance ..........................439 CHANnel<m>: O FFSet ...........................438 CHANnel<m>: O VERload ..........................439 CHANnel<m>:...
Page 804 ® List of Commands R&S CURSor<m>: Y DELta: S LOPe ........................521 CURSor<m>: Y DELta[: V ALue] ........................520 DIAGnostic: S ERVice: C OMPutername ......................768 DIAGnostic: S ERVice: F WVersion ........................768 DIAGnostic: S ERVice: P ARTnumber .......................769 DIAGnostic:...
Page 805 ® List of Commands R&S EXPort: W AVeform: S COPe ..........................760 EXPort: W AVeform: S OURce ..........................760 EXPort: W AVeform: S TARt ..........................761 EXPort: W AVeform: S TOP ..........................761 EXPort: W AVeform: Z OOM ..........................761 FORMat:...
Page 806 ® List of Commands R&S LAYout: Z OOM: V ERTical: A BSolute: P OSition ....................506 LAYout: Z OOM: V ERTical: A BSolute: S PAN .....................507 LAYout: Z OOM: V ERTical: A BSolute: S TARt ....................507 LAYout: Z OOM: V ERTical: A BSolute: S TOP .....................507 LAYout:...
Page 807 ® List of Commands R&S MEASurement<m>: G ATE: S HOW .........................573 MEASurement<m>: G ATE: Z COupling ......................573 MEASurement<m>: G ATE[: S TATe] .......................572 MEASurement<m>: H ISTogram: L CHeck<n>: L OWer: L IMit ................563 MEASurement<m>: H ISTogram: L CHeck<n>: L OWer: M ARGin ..............564 MEASurement<m>:...
Page 808 ® List of Commands R&S MEASurement<m>: S PECtrum: N DBDown .....................553 MEASurement<m>: S PECtrum: N REJect .......................554 MEASurement<m>: S PECtrum: O BANdwidth ....................553 MEASurement<m>: S TATistics: H ISTogram ....................566 MEASurement<m>: S TATistics: M ODE ......................566 MEASurement<m>:...
Page 809 ® List of Commands R&S MTESt: S EGMent: A DD ...........................601 MTESt: S EGMent: C OUNt ..........................601 MTESt: S EGMent: I NSert ..........................601 MTESt: S EGMent: P OINt: A DD ........................602 MTESt: S EGMent: P OINt: C OUNt ........................603 MTESt:...
Page 810 ® List of Commands R&S PROBe<m>: S ETup: O FFSet: T OMean ......................445 PROBe<m>: S ETup: S TATe ...........................442 PROBe<m>: S ETup: T YPE ..........................446 REFCurve<m>: C LEar ............................592 REFCurve<m>: D ATA: H EADer ........................596 REFCurve<m>:...
Page 811 ® List of Commands R&S REFLevel<m>: U SRLevel ..........................529 RUN ................................428 RUNContinous ...............................428 RUNSingle ..............................428 SEARch: A DD ..............................611 SEARch: A LL ..............................612 SEARch: C LEar ..............................612 SEARch: G ATE: A BSolute: S TARt ........................633 SEARch:...
Page 812 ® List of Commands R&S SEARch: T RIGger: E DGE: B COPy ........................615 SEARch: T RIGger: E DGE: S LOPe ........................617 SEARch: T RIGger: E DGE[: S TATe] .........................614 SEARch: T RIGger: F INDlevel ..........................632 SEARch: T RIGger: G LITch: A COPy .........................615 SEARch:...
Page 813 ® List of Commands R&S SEARch: T RIGger: W IDTh: B COPy .........................615 SEARch: T RIGger: W IDTh: D ELTa ........................627 SEARch: T RIGger: W IDTh: P OLarity .......................627 SEARch: T RIGger: W IDTh: R ANGe .........................627 SEARch:...
Page 814 ® List of Commands R&S SYSTem: E RRor: A LL .............................769 SYSTem: E RRor: C ODE: A LL ..........................770 SYSTem: E RRor: C ODE[: N EXT] ........................770 SYSTem: E RRor: C OUNt ..........................771 SYSTem: E RRor[: N EXT] ..........................770 SYSTem:...
Page 815 ® List of Commands R&S TRIGger<m>: E DGE: S LOPe ..........................457 TRIGger<m>: F INDlevel ..........................455 TRIGger<m>: F LXRay: B SSerror ........................730 TRIGger<m>: F LXRay: C ENable ........................727 TRIGger<m>: F LXRay: C MAX .........................727 TRIGger<m>: F LXRay: C MIN ..........................727 TRIGger<m>:...
Page 816 ® List of Commands R&S TRIGger<m>: I 2C: A DOR<n>[: V ALue] ......................651 TRIGger<m>: I 2C: A MODe ..........................649 TRIGger<m>: I 2C: D CONdition ........................653 TRIGger<m>: I 2C: D MAX ..........................654 TRIGger<m>: I 2C: D MIN ..........................653 TRIGger<m>:...
Page 817 ® List of Commands R&S TRIGger<m>: O UT: P OLarity ..........................491 TRIGger<m>: O UT: S TATe ..........................491 TRIGger<m>: P ARallel: D ATatoclock: C SOurce: E DGE ...................748 TRIGger<m>: P ARallel: D ATatoclock: C SOurce[: V ALue] ................744 TRIGger<m>:...
Page 818 ® List of Commands R&S TRIGger<m>: Q UALify<n>: D : L OGic .......................480 TRIGger<m>: Q UALify<n>: D [: E NABle] ......................480 TRIGger<m>: Q UALify<n>: S TATe .........................479 TRIGger<m>: R FReject<n> ..........................451 TRIGger<m>: R OBust ............................456 TRIGger<m>:...
Page 819 ® List of Commands R&S TRIGger<m>: W INDow: D ELTa ........................467 TRIGger<m>: W INDow: R ANGe ........................466 TRIGger<m>: W INDow: T IME .........................466 TRIGger<m>: W INDow: W IDTh ........................467 WAVeform<m>: X YCurve: R ATio ........................509 WAVeform<m>:...
Page 820: Index
® Index R&S Index Symbols *OPC ................404 Bandwidth *OPC? ................404 instrument ..............15 *RST ................417 probe ................ 15 *WAI ................404 Spectrum measurement .......... 140 Big endian CAN ................ 291 LIN ................301 Acq. completed, mask test result ........216 Bit string Acq.
Page 821 ® Index R&S Comma ..............401 DCL ................393 Command line structure .......... 401 Decimation ..............17, 33 Double dagger ............401 Decoded bus finding a command ..........418 parallel bus display ..........329 GBIP, addressed ............ 394 DEF ................399 GBIP, universal ............
Page 822 ® Index R&S measurements ............163 update ..............373 Envelope wfm Flattop2 window (FFT) ..........201 cursor measurement ..........126 FlexRay Environment sensor configuration settings ..........307 measurement results ..........130 Font size result display ............177 dialog boxes .............. 92 select and enable ............
Page 823 ® Index R&S jitter measurement ..........140 markers ..............170 Jitter measurement results ..........138 toolbar icons ............145 measurement results ........136, 137 measurement via histogram ........140 tubes ................ 157 vertical ..............138 History ................114 export .............. 345, 351 Kaiser Bessel window (FFT) ..........
Page 824 ® Index R&S configuring .............. 143 default .............. 129, 143 Mainboard delay ................ 163 information .............. 387 icons in results table ..........130 Main measurement ............162 main ................ 162 Malfunctions MSO ..............323, 327 reacting ..............418 results ..............130 Margins Setup/Hold ..............
Page 825 Beta state ..............375 Output ..............344 installing ..............374 Paper format ............344 key ................374 Printing ................344 RTO-B4, OCXO ............51 functions ..............357 RTO-K4, FlexRay ............ 307 results ..............344 Output buffer ..............408 screenshots ............344...
Page 826 ® Index R&S Recall intermediate ............425 Recommendations Sample hits, mask test result ........216 remote control programming ........417 Record length ............15, 19, 29 Sample rate ..............15, 29 Samples ................15 Rectangular window (FFT) ..........201 Reference levels history ..............
Page 827 ® Index R&S Search zoom window ..........237, 247 results ..............140 displaying ..............240 settings ..............167 position ..............240 settings ..............240 decode results ............276 Secured environment ............ 386 SPI protocol Self-alignment ..............360 basics ..............269 Selftest ..............
Page 828 ® Index R&S MSO ................ 339 qualification, pattern trigger ........78 Time scale ..............19, 28 Trigger offset ..............19 Time stamp ..............119 Trigger sources Toolbar MSO ................ 332 configuring ..............93 Trigger types Coupled zoom ............108 CAN ................ 289 Hardware zoom ............
Page 829 ® Index R&S Width trigger ..............64 MSO ................ 334 Window search condition ..........67 Windows XP ..............371 accessing ..............372 logon ................ 372 settings ..............372 Window trigger ..............67 XY-diagram displaying ..............112 settings ..............113 Zero adjustment .............. 46 Zoom ................

Save PDF
