Quick Start; Overview - CipherLab CP30 Series Reference Manual

QUICK START

OVERVIEW

No. Description
1 Receiver
3 Volume Buttons
5 Touch Screen
7 Microphone
9 I/O Connector & Memory Card Slot
11 Digital Camera
13 Stylus (to be tethered)
15 Battery Compartment
No. Description
2 Status LEDs for Battery Charging / Good
Read (left) and Messaging (right)
4 Side Triggers, user-definable
6 Scan Key, user-definable
8 Headset Jack
10 Power Key
12 Scanning Window
14 Speaker
16 Battery Cover Latch
