GAUI R5 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
GAUI
Specifications
Overall Length : 1195 mm
Main Rotation Diameter: 1301 ~ 1337 mm
Main blade length: 580 ~ 598 mm
Overall Height: 332 mm
Overall Width: 90 mm
Tail Blade Length: 82 ~ 95 mm
Tail Rotation Diameter: 238 ~ 258 mm
We recommend downloading and using the latest manual from Official GAUI website's download area.
This product is for a radio controlled (RC) helicopter.Improper operation, maintenance or assembly can
potentially cause a RC helicopter to pose a danger to persons or objects including but not limited to
the possibility of causing serious physical injury and even death.
INSTRUCTION MANUAL
90 mm
Power system (recommended):
ESC: Recommed 160A ESC
LiPo battery: max size: 340 x 46 x 48 mm
Motor: 500KV ~ 540KV
Total weight: 2100g ±3% (kit only, not including
electronics, main blades, tail blades)
1301~1337mm
238~258 mm
1195 mm
© 2015
V 1.1
MADE IN TAIWAN
