4-3-10-4 Report Pages
Measurements/Calculations that are included on the worksheet can also be displayed on Report Pages.
Report Pages can be customized to meet the appropriate needs of the user.
4-3-11

Probe/Connectors Usage

4-3-11-1 Connecting a probe
1.) Place the probe's carrying case on a stable surface and open the case.
2.) Carefully remove the probe and unwrap the probe cable.
3.) DO NOT allow the probe head to hang free. Impact to the probe head could result in irreparable
4.) Align the connector with the probe port and carefully push into place.
5.) Lock the probe.
6.) Carefully position the probe cord so it is free to move and is not resting on the floor.
4-3-11-2 Activating the probe
The probe activates in the currently-selected operating mode. The probe's default settings for the mode
and selected exam are used automatically.
4-3-11-3 Deactivating the probe
1.) Press the Freeze key.
2.) Gently wipe the excess gel from the face of the probe. (Refer to the User Guide for complete
3.) Carefully slide the probe around the right side of the keyboard, toward the probe holder. Ensure
4-3-11-4 Disconnecting the probe
Probes can be disconnected at any time. However, the probe should not be selected as the active
probe.
1.) Unlock the probe.
2.) Pull the probe and connector straight out of the probe port.
3.) Carefully slide the probe and connector away from the probe port and around the right side of the
keyboard.
4.) Ensure the cable is free.
5.) Be sure that the probe head is clean before placing the probe in its storage box.
Take the following precautions with the probe cables: Do not bend, be sure to keep
WARNING WARNING
probe cables free from the wheels.
3
EVISION
damage.
probe cleaning instructions.)
that the probe is placed gently in the probe holder.
