Room Alert Hardware Features

Internal Temperature Sensor
Internal Humidity Sensor
Room Alert 32E/W
Internal Power Sensor
Room Alert 32E/W
Internal Battery Back-up
Room Alert 32E/W
Power Port
1
Ethernet Port
2
PoE enabled on 32E/W, 12E & 3E
Reset Button
3
4
Switch Sensor Port(s)
5
Digital Port(s)
Custom Light Tower Or Relay Port
6
Room Alert 4E
Light Tower & Relay Adapter Port(s)
7
Room Alert 32E/W, 12E & 3E
Analog Input Port(s)
8
Room Alert 32E/W & 12E
Relay Output Port(s)
9
Room Alert 32E/W & 12E
Power Status LED
10
Room Alert 32E/W
WiSH Signal Strength LEDs
11
Room Alert 32W
4
An internal digital sensor monitors ambient temperature
with a range of -40° to 185° F (-40° to 85° C).
An internal digital sensor monitors relative humidity with a
range of 5% to 95% RH.
An internal sensor monitors the power state (main power
or battery-back up power).
An internal battery back-up can power Room Alert 32E/W
for up to 15 minutes.
A standard power port connects Room Alert to an electrical
outlet with any AVTECH 5V 1A Power Adapter. Models are
available for all countries.
An RJ-45 port connects Room Alert to your network via an
RJ-45 Ethernet cable.
A small push button resets Room Alert to factory default
settings. (Please push softly.)
Dry contacts connect Room Alert to any AVTECH switch
sensor or dry contact on a device (e.g., HVAC, generator,
pump, fan, etc.) via standard speaker wire or low-voltage
2-wire cable.
Standard RJ-11 jack(s) connect any AVTECH digital sensor
to Room Alert via a standard RJ-11 (straight through)
telephone cord.
The custom port allows you to directly connect a light
tower or Relay Switch Sensor to Room Alert 4E.
A standard RJ-11 jack connects a Light Tower & Relay
Adapter to Room Alert 32E/W, 12E or 3E via a standard
RJ-11 (straight through) telephone cord.
Set(s) of contacts connect any low-voltage analog sensor
to your Room Alert 32E/W or 12E via standard speaker
wire.
Set(s) of contacts connect any low-voltage device to your
Room Alert 32E/W or 12E via standard speaker wire.
An LED indicates the power status of Room Alert 32E/W:
Green = Main or PoE,
Three (3) LEDs indicate the signal strength of the last
WiSH or WiSPR sensor to communicate with your
Room Alert 32W: 3 = Strong, 1 = Weak signal.
Red = Internal UPS power.
