Room Alert 32E/W

Front
10
Power
Status
LED
Wireless Coaxial Port
(RA32W only)
Back
9 8
Relay Analog
Output Input
Ports Ports
(2) (2)
Room Alert User's Guide
2
Ethernet
Port
14
WiSH Signal Strength LEDs
5
Digital
Sensor
Ports
(8)
4
Switch
Sensor
Ports
(16)
Internal Sensors
• Temperature
• Humidity
• Power
• Battery Back-up
(RA32W only)
11
12
13
PoE, Light Tower &
WLAN & Relay Adapter
GSM
LEDs
Alarm
LEDs
3
15
Reset
Button
Battery Back-up
On / Off
Button
7
Ports
(2)
1
Power
Port
3
