more descriptive, such as "Current Loop 1" or "Cryogenic Temp."
Room Alert sensor labels may be up to 15 characters and can include the
TIP
following: letters, numbers, spaces, hyphens (-), underscores (_) and periods (.).
• In High and Low, you may leave the default, 0—which means no alarm is configured—
or enter values that fall within the Scale range from the previous step. In our example,
we entered a conversion scale of 0 to 10 (amps) in the previous step for the Current
Loop, and we've chosen to generate alarms at the high and low thresholds of 6 and 2
(amps).
With the custom scale enabled, you may enter positive and negative whole
TIP
numbers in High and Low that fall within the Scale range; with the custom scale
disabled, you may enter decimal numbers in the range of +/-5.0 (for 0-5 VDC).
• In Adjust, you may enter a value to adjust the reading if it differs from a known value.
With the custom scale enabled, you may enter decimal numbers in Adjust in the
TIP
range of +/-12.0; with the custom scale disabled, you may enter decimal numbers
in the range of +/-5.0.
4. In Use Alarm Profile, which controls light towers and relays on your Room Alert, you may
leave the default,
If you have an AVTECH Light Tower, Relay Switch Sensor or built-in relays on your
NOTE
Room Alert, you may configure Alarm Profiles to toggle them on and off when alarms
are detected. Please refer to the
Save Settings
5. Select
automatically reboot and commit your changes.
Room Alert User's Guide
Profile 1, or choose another Alarm Profile from the drop-down menu.
Alarms
at the top or bottom of the page. Your Room Alert will
section in this manual for further information.
