BMW R 1200 RT Rider's Manual page 109

The front wheel must be
installed right way round
to rotate in the correct direc-
tion.
Note the direction-of-rotation
arrows on the tyre and the
wheel rim.c
• Roll the front wheel into the
front wheel guide.
• Raise the front wheel, install
quick-release axle 6 com-
plete with the spacer, and
tighten to 50 Nm.
• Tighten axle clamping
screw 5 to 19 Nm.
• Remove the front wheel
stand.
• Ease the brake calipers on to
the brake discs.
The cable of the ABS
sensor could chafe
through if it comes into con-
tact with the brake disc.
Make sure that ABS sensor
cable 7 is routed correctly.c
• Install securing screws 2 for
the left and right brake cali-
pers and tighten to 30 Nm.
6
107
