LDP-9200 series

Quick Guide

Please read this user guide carefully before operating your set.
Retain it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDP-9200 series and is the answer not in the manual?

Questions and answers

emma
March 7, 2025

We have forgotton our password to retrieve voicemails

Summary of Contents for iPECS LDP-9200 series

  • Page 1: Quick Guide

    LDP-9200 series Quick Guide Please read this user guide carefully before operating your set. Retain it for future reference.
  • Page 2: Revision History

    LDP-9208D/9224D/9224DF/9240D Quick Guide Revision History Issue Date Remark Jan, 2016 Initial release Copyright© 2015 Ericsson-LG Enterprise Co., Ltd. All Rights Reserved. This material is copyrighted by Ericsson-LG Enterprise Co., Ltd. Any unauthorized reproductions, use or disclosure of this material, or any part thereof, is strictly prohibited and is a violation of Copyright Laws. Ericsson-LG Enterprise reserves the right to make changes in specifications at any time without notice.
  • Page 3: Important Safety Information

    LDP-9208D/9224D/9224DF/9240D Quick Guide Important Safety Information To prevent unexpected danger or damage please read this information before installing or attempting to repair you phone. Warning and Caution information is provided to alert the consumer of known dangers: Warning: To reduce the possibility of electric shock, do not expose your phone to high humidity areas, such as a bathroom, swimming area, etc.
  • Page 4 LDP-9208D/9224D/9224DF/9240D Quick Guide installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
  • Page 5 Your telephone is connected to an advanced-technology, highly-versatile, fully-featured telecom system designed to make office communications easy and productive. LDP-9200 series (shown) incorporate user interface to provide you with a cost effective, simple to use, productive communications tool. For the detailed specification, refer to the below table.
  • Page 6: Phone Layout And Functions

    LDP-9208D/9224D/9224DF/9240D Quick Guide 1.2 Phone Layout and Functions Figure 1 LDP-9208D button naming Figure 2 LDP-9224D button naming Figure 3 LDP-9224DF button naming...
  • Page 7 Figure 4 LDP-9240D button naming The functions of button Below is a brief description of the elements called out in the above LDP-9200 series Phone diagrams. Ring/Message Indicator: Flashes when receiving a new call or you have a new message waiting.
  • Page 8: Dss Console

    LDP-9208D/9224D/9224DF/9240D Quick Guide  OK: Selects the highlighted choice when navigating through a menu. Fixed buttons LDP-9208D does not support some buttons: Flash, Directory, and Headset among the below buttons.  Flash button: U se to seize the new line without on-hook. So you can make a call by dialing the desired number.
  • Page 9: Wall Mount

    Quick Guide Installation Connecting the Phone LDP-9200 series have 3 connection ports (refer to following figure). Each port is for connecting to: Handset, Ear Mic. headset, and the line cable.  Connect the telephone cord (curly cord) to the handset and the other end to the handset jack at the bottom of the telephone.
  • Page 10: Dss (Direct Station Select) Console Installation

    It may be necessary to remove the phone and tighten or loosen the screws for a secure mounting. 2.2 DSS (Direct Station Select) Console Installation A DSS console can be installed with LDP-9200 series phone. As we described the available DSS for each phone, the available DSS is as below: ...
  • Page 11: User Operation

    Quick Guide User Operation The following is provided as quick reference for commonly used features / functions. Complete instructions are included in LDP-9200 Series User Guide. Placing a Call: Internal Station to Station Call  Lift the handset, or press the button.
  • Page 12: Using Do Not Disturb (Dnd)

    LDP-9208D/9224D/9224DF/9240D Quick Guide To activate One-time DND:  Press the button. To activate Text message forward:  Press the button. TRANS  Dial the User Program feature code 51.  Dial the two-digit text Message code (00-20). For reference, the message 00 is as the below and the message 11-20 are edited only Attendant (PGM + 0 + 5 + 3) or Web admin ‘System Data: Custom message’.
  • Page 13: Call Hold: Placing A Call In A Waiting State

    LDP-9208D/9224D/9224DF/9240D Quick Guide To retrieve the Conference from Hold:  Select the soft button or press the programmed button (LDP-9208D). Conf Conf To establish an Unsupervised Conference:  Establish conference with two external parties.  Select the soft button or press the programmed button (LDP-9208D).
  • Page 14: Call Transfer: Sending A Call To A Different Destination

    LDP-9208D/9224D/9224DF/9240D Quick Guide To deactivate Call Forward, Remote:  Lift the handset.  Press the soft button or button. FORWARD  Dial 0 (Remote Call Forward code).  Dial your Authorization code (Station number & Password).  Press the # key. Call Transfer: Sending a call to a different destination ...
  • Page 15 LDP-9208D/9224D/9224DF/9240D Quick Guide Activate a queue if the selected/dialed line is busy:  Select the desired CO/IP line button; when the busy notification is returned, press the CALL BACK button.  Return to an idle state by going on-hook; when the line is available, the station will be notified (ringing).
  • Page 16: Using System Speed Dial

    LDP-9208D/9224D/9224DF/9240D Quick Guide Using System Speed Dial:  Lift the handset.  Press the button. SPEED  Dial the desired system speed number. Using Station Speed Dial:  Lift the handset.  Press the button. SPEED  Dial the desired station speed number. Using Dial By Name: To place a call using Dial by Name: ...
  • Page 17 LDP-9208D/9224D/9224DF/9240D Quick Guide In case of LDP-9208D and LDP-9224D, use the following table and press the Soft button or button. SAVE LDP-9208D/9224D Character Entry Chart (D1: 1 Digit, D2: 2 Digit) Char Char Char (SPC: Space) In case of LDP-9224DF and LDP-9240D, use the following table and press the Soft button or button.
  • Page 18 LDP-9208D/9224D/9224DF/9240D Quick Guide 3.1 Flex Button Program Press the button. TRANS Press the flexible button to be programmed. Press the button and User Program Code (refer to the below table). TRANS Press the button. HOLD SAVE 3.2 Station User Program Codes CODE FUNCTION En-block Dialing (1: ON, 2: OFF)
  • Page 19 LDP-9208D/9224D/9224DF/9240D Quick Guide CODE FUNCTION Network configuration (Not available) Display Phone Version Display Serial number & license status Enter Admin (Only Attendant is available) Set Forced Forward Dest Forced Forward to Dest Register Bluetooth (Not available) Bluetooth Usage (Not available)
