Data Fields

Setting
Line 1 Parameter
Line 1 Units
Line 1 Decimals
Line 2 Parameter
Line 2 Units
Line 2 Decimals
Line 3 Parameter
Line 3 Units
Line 3 Decimals

Pressure Input

Setting
Analog Input #
Input Units
Input Upper
Input Lower
Input Default
Process Pressure
Default
Process Pressure
Programming the 4x40 Optica
Table 5-7: Data Field Options
Description
Choose which parameter will be
output on Line 1.
Set the units for the selected
parameter.
Enter the number of decimal places
for displayed data.
Choose which parameter will be
output on Line 2.
Set the units for the selected
parameter.
Enter the number of decimal places
for displayed data.
Choose which parameter will be
output on Line 3.
Set the units for the selected
parameter.
Enter the number of decimal places
for displayed data.
Table 5-8: Pressure Input Options
Description
Choose which pressure input channel
is in use, or disable this input.
Choose the units for pressure units.
Set the pressure that corresponds to
full-scale input.
Set the pressure that corresponds to
zero volts or 4 mA input.
Pressure value to be used if a
measured input is disabled.
Set whether the process pressure is
active (enabled) (see page 3-4).
Enter the process pressure (if this
feature is enabled).
Available Options
Humidity, Temperature, Pressure or
User
See Table 4-1 on page 4-4 for the
parameter chosen.
Enter a number (0-6).
Humidity, Temperature, Pressure or
User
See Table 4-1 on page 4-4 for the
parameter chosen.
Enter a number (0-6).
Humidity, Temperature, Pressure or
User
See Table 4-1 on page 4-4 for the
parameter chosen.
Enter a number (0-6).
Available Options
4-20 mA, 0-5 volt, User Default
See Table 4-1 on page 4-4 for units.
Enter a number.
Enter a number.
Enter a number.
Enabled/Disabled
Enabled/Disabled
January 2006
5-7
