Programmable Functions; Analog Outputs; Communication Parameters - GE Optica Operator's Manual

January 2006

Programmable Functions

Analog Outputs

Setting
Output A Parameter
Output A Units
Output A Upper
Output A Lower
Output B Parameter
Output B Units
Output B Upper
Output B Lower
Communication
Parameters
Setting
Serial Mode
Baud
Parity
Number of Data Bits
Number of Stop Bits
Serial Flow Control
5-4
Table 5-2: Analog Output Options
Description
Choose which parameter will be
output on analog channel A.
Choose the units for scaling this
parameter.
Set the parameter value that will
produce full-scale output.
Set the parameter value that will
produce zero output.
Choose which parameter will be
output on analog channel A.
Choose the units for scaling this
parameter.
Set the parameter value that will
produce full-scale output.
Set the parameter value that will
produce zero output.
Table 5-3: Communication Parameter Options
Description
Set whether data is transmitted
continuously or on demand.
Set the baud rate to be compatible
with the receiving device.
Set the parity as required by the
receiving device.
Set the number of data bits as
required by the receiving device.
Set the number of stop bits as required
by the receiving device.
Set the flow control as required by the
receiving device.
Available Options
Humidity, Temperature, Pressure or
User Equation
See Table 4-1 on page 4-4 for the
parameter chosen.
Enter a number.
Enter a number.
Humidity, Temperature, Pressure or
User Equation
See Table 4-1 on page 4-4 for the
parameter chosen.
Enter a number.
Enter a number.
Available Options
All, Query (see Query Mode Format on
page 4-17)
300, 1200, 2400, 4800, 9600, 19200,
38400, 57600
None, Odd, Even, Mark or Space
7 or 8
1, 1.5 or 2
None, Software, Hardware
Programming the 4x40 Optica
