2-3 Connecting Lines
1. Connect one end of the telephone line cord to the phone line socket on the bottom of the base unit, and the
other end to a standard phone wall jack.
2. Connect the modular end of the power adapter to the DC power socket on the bottom of the base unit, and
the other end to a standard AC wall outlet.
To AC wall outlet
3. Route the cords through the recessed channel as shown.
Operations & Installation
To phone wall jack
2-4
