TEST MAIN SCREEN
F1:ID READ
F1 : When you want to read Current ID(EMC Code) of TestSet
F3 : When you want to write new ID(EMC Code) of TestSet
F5 : When you want to write national option again
F7 : When you want to adjust Clock of TestSet
F9 : When you want to control RF vco voltage
ALT-X : When you want to terminate this program
In all testcases, If you see Òconnenction failÓ message, Check next item.
- testset you selected is identical to testset of program.
- COM port is connected to COM 1 (initial port is fixed to COM 1)
- Converter JIG Mode is setted to IIC mode
- testset is setted to TEST MODE
9-5
SR - R5200(DECT) BASESET v4.8
EEPROM WRITIONG
X-TAL ADJUSTING
F3:ID WRITE F5:NAT OPT
RESULT
F7:CLK ADJ F9:RF ALT+X:EXIT
Test Jig Usage
