F 5 : NATIONAL OPTION WRITE
F1:ID READ
In this testcase, If you have error message like ÒEEP initial data is failedÓ, You should check s/w version
of testset because each version has different checksum data.
F 7 : CLOCK SETTING
Current Value : 1C
F1:ID READ
If clock frequency is higher than reference clock(10.368000Mhz), enter the lower value than Current
Value at Adjust Value.
On the contrary, if it is lower than reference clock, enter the higher value than Current Value at Adjust
Value. (Valid Adjust Value : 00~FF)
9-7
SR - R5200(DECT) BASESET v4.8
EEPROM WRITIONG
X-TAL ADJUSTING
F3:ID WRITE F5:NAT OPT
SR - R5200(DECT) BASESET v4.8
EEPROM WRITIONG
X-TAL ADJUSTING
F3:ID WRITE F5:NAT OPT
EEP initial data is written !
RESULT
F7:CLK ADJ
RESULT
F7:CLK ADJ
Test Mode is O K!
F9:RF ALT+X:EXIT
Adjust Value : 1F
F9:RF ALT+X:EXIT
Test Jig Usage
