DripMaster
COnneCt Drip tubing tO
OutsiDe HOse FauCet
GROUND COVER
Supply Line Placement- Run the 1/2" Drip Tubing Supply Line
1
down the center of the Ground Cover area and install a 1/2" End
Cap at the end of the tubing.
Identify Sprinkler Head Locations- Following the
2
illustrated example, place quarter sprinkler heads in the cor-
ners, half sprinkler heads along the sides, and full spray pattern
sprinkler heads in the center of your ground cover area.
TIP- Spacing should be no more that 10' from one sprinkler to the next.
Using the Hole Punch, make a hole in the top of the 1/2" Drip
3
Tubing Supply line where you want the first sprinkler to begin
and insert a 1/4" Barbed Coupling into the hole.
64
SECTION

Orbit

DripMaster
® ®
2
Installation Guide
|
