Orbit Dripmaster Parts List
1/4" TUBING FITTINGS
Barb Elbow
67400, 69400
Barb Tee
67401, 69401
Barb Coupling
67402, 69402
Barb End Plug
67403, 69403
Barb Shut-Off
Valve
67404, 69404
Insect/Water
Distribution Plug
66405, 67405
1/2" DRIPLOCk™
TUBING FITTINGS
Coupler
67451, 69451
Tee
67452, 69452
Elbow
67450, 69450
End Cap
67462, 69462
Shut-Off Valve
67463
1/2" SOAkER TUBE
1 GPH Emitter
Tubing 100'
67366
30
Orbit
9
SECTION
1/2" UNIVERSAL
DRIP FITTINGS
Hose/Faucet
Adapter
67469
Coupler
67467
Elbow
67465
Tee
67466
End Cap
67468
Figure 8
65443, 66443
DISTRIBUTION/SUPPLY
TUBE
1/4" Distribution
Tube
50' 67300, 67303
100' 67301
1/2" Distribution
Tube
50' 67345
100' 67346
500' 67347
1/4" SOAkER TUBE
Drilled Soaker
Tubing 60'
(0.9 GPH @ 25 PSI)
61073, 67321
1/4" Porous
Soaker Tube
(0.5 GPH @ 25 PSI)
50' 67330, 69330
100' 67331
DripMaster | Installation Guide
® ®
Orbit Dripmaster Parts List
SPRINkLER STAkES
12" Tubing Stake
with 12" Riser
67722
1/4" Inline Stake
67720, 69720
Female Hose x
1/2" Pipe Thread
67990
1/2" Drip Inline x
1/2" Pipe Thread
67991
1/2" Barb x 1/2"
Male Pipe Thread
x End Cap
67992
TUBING STAkES
1/2" Tubing Stake
67732
1/4" Stake Tubing
65721, 69721
1/4" Dripper Stake
67719
Loop Stake
1/2" 65731, 66731
1/4" 65730, 69730
Orbit DripMaster | Installation Guide
® ®
DripMaster
®
9
SECTION
MISCELLANEOUS
Tubing Strap
1/2" 65716, 69716
1/4" 65715, 69715
1/4" High Pressure
Clamp
67710, 69710
Tube
Punch Tool
67756, 69756
Punch Gun
67757
