Orbit WaterMaster Voyager Installation Instruction

Voyager
®
gear DriVe
Sprinkler
Aspersor de
trAnsmisión por
engrAnAjes VoyAger
No Special Key Required
No se requiere llave especial
PN 55461-24 Rev B
Orbit Irrigation Products, Inc.
®
North Salt Lake, Utah 84054 USA
1-800-488-6156
www.orbitonline.com
© 2008 Orbit Irrigation Products, Inc.
®
All rights reserved. All trade names are registered
trademarks of respective manufacturers listed.
READ ALL INSTRUCTIONS
PRIOR TO INSTALLATION
Set the Pattern
Before Installation
The Voyager can be set to rotate
between 40° and 360° (preset at 180°)
1. Turn the top of the head all the
way to the left until it stops and
then all the way to the right. This
is the starting point for the rotation
(Figure 1).
Figure 1
®
2. Insert a flat bladed screwdriver
into the pattern adjustment screw
(Figure 2).
Distance
Pattern
adjustment adjustment
slot
slot
Orbit
®
Figure 2
3. Turn clockwise to increase rota-
tion; counterclockwise to decrease
rotation. Each full turn increases/
decreases rotation by 90˚.
proof no:
date: 10.02.08
des: SM
job no:
client:
sku: 55461
p 801 295 9820
upc:
NA
f 801 951 5815
www.fluid-studio.net
file name:
1065 South 500 West
software:
Bountiful, Utah 84010
ENGLISH
Head Installation 2. Turn clockwise to decrease
distance; counterclockwise to
1. Flush sprinkler lines.
increase distance.
2. Thread the sprinkler onto a riser
Caution: DO NOT turn the adjust-
and set the head flush with the
ment screw too far in either
finished turf height (Figure 3).
direction—screw may come free
Note: DO NOT use pipe dope on the
of threads.
threads. If necessary, use thread
seal tape.
Replace the Nozzle
See Nozzle Specs for other distance
ranges and replace the nozzle if
needed.
1. To access to the nozzle, insert a
flat blade screwdriver into the lift-
Figure 3
ing socket and lift upward (Figure
3. Unscrew the cap and remove the
4)
sprinkler stem from the canister—
be careful of debris falling in canis-
ter.
4. Position the sprinkler stem so that
the arrow points to the right edge
of the rotation.
5. Slide the sprinkler stem back into
the canister and tighten the cap. 2. Firmly grip the sprinkler stem—
Note: the spring inside the canister
is very strong.
Set the Spray Distance
3. Insert a small flat bladed screw-
After Installation
driver into the distance adjustment
Set with water on under system's nor-
slot..
mal operating pressure.
4. Turn the screw counterclockwise
Note: Preinstalled nozzle (# 7) adjusts
until it is just clear of the nozzle.
from 25 ft. to 45 ft. depending on sys-
Caution: DO NOT turn the adjust-
tem water pressure.
ment screw too far in either
1. Insert a small flat bladed screw-
direction—screw may come free
driver key into the distance adjust-
of threads.
ment slot (Figure 2).
8
dimensions:
flat: w: 11.25" h: 5.5"
finished (folded): w 3.75" d: 0" h 5.5"
spck: XX
colors
NA
color
Registration non printing
Orbit
PMS
K ????
additional instructions:
· Translation Proofing code: LB403717
55461-24 rB.indd
·
InDesign CS3
5. Use pliers to grip the "ears" of the
nozzle and pull it out.
6. Insert the replacement nozzle with
the ears on top and turn the screw
back into place (Figure 5).
Figure 5
7. Adjust distance if necessary (see
Set the Spray Distance).
Clean the Filter
1. Remove grass and dirt around the
sprinkler head so you can see the
top 1 ½ in.
2. Unscrew the cap and remove the
stem assembly.
Figure 4
3. Use pliers to extract the filter from
the bottom of the stem assembly.
4. Clean out debris and replace filter.
5. Replace the stem assembly to the
sprinkler body and screw tightly.
CAUTION
For outdoor use with cold water only.
n
Do not spray near electrical
n
connections.
CUSTOMER SERVICE
1-800-488-6156
www.orbitonline.com
