Top & Bottom - Altronix HubWay8D Installation Manual

1U EIA 19" Rack Mount Chassis Mechanical Drawing & Dimensions:
1.625"H x 19.125"W x 8.5"D
1.625"
16 15
8.5"
.75"
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated "DANGEROUS VOLTAGE" within the products enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
HubWay Passiive Unit
14 13 12 11 10
1 2 3 4 CH 1-4 5 6
+ DATA --
1-8
(ON)
Fig. 5
Illuminated master power disconnect circuit breaker:
• OFF position Circuit breaker tripped – Switch not illuminated.
• RESET (ON) position – Switch illuminated.
CAUTION: To reduce the risk of electric shock do not open enclosure. There
are no user serviceable parts inside. Refer servicing to qualified service personnel.
REAR
9 8 7
TOP & BOTTOM
17.625"
FRONT
7 8 CH 5-8
28VAC
OFF
24VAC
19.125"
6 5 4 3 2
9 10 11 12 CH 9-12 13 14
+ DATA --
9-16
1
AC POWER
15 16 CH 13-16
28VAC
OFF
24VAC
- 7 -
