JAI LQ-050CL User Manual

Rgb color & nir 4ccd line scan camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
LQ-050CL
RGB Color & NIR
4CCD Line Scan Camera
Document Version: Ver.1.2
LQ-050CL_Ver.1.2_Dec2014
1030E-1105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LQ-050CL and is the answer not in the manual?

Questions and answers

Related Manuals for JAI LQ-050CL

Summary of Contents for JAI LQ-050CL

  • Page 1 User's Manual LQ-050CL RGB Color & NIR 4CCD Line Scan Camera Document Version: Ver.1.2 LQ-050CL_Ver.1.2_Dec2014 1030E-1105...
  • Page 2 JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 3 LQ-050CL Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 4: Table Of Contents

    LQ-050CL - Table of contents – General ......................5 Camera nomenclature ..................5 Main features ....................5 Locations and functions ..................6 4.1. Locations and functions ................6 4.2. Rear Panel ....................7 Connectors and pin assignment ................8 5.1.
  • Page 5 Serial communication and command list ............... 37 8.1. Serial communication ................. 37 8.2. Command list ..................38 Camera Control Tool for LQ-050CL ..............43 External appearance and Dimensions ..............47 Specifications ..................... 49 11.1 Typical data ....................49 11.2 Camera Spectral sensitivity ................. 51 Appendix ......................

  • Page 6: General

    General The LQ-050CL is a 4CCD line scan camera using four 512 pixel line sensors mounted on a prism, for the R, G,B and NIR channels. It operates with a 40 MHz pixel clock, resulting in a maximum line rate of 70,922 lines per second.

  • Page 7: Locations And Functions

    LQ-050CL Locations and functions 4.1. Locations and functions Fig. 1 Location of external features 1 Lens mount M52 mount (*1)Note) 2 Camera Link part 1 base connector (1) (*2)Note) 3 Camera Link part2 medium connector (2) (*2)Note) 4 12-pin Hirose connector...

  • Page 8: Rear Panel

    LQ-050CL 4.2. Rear Panel ① POW ER / TRIG W . B . D C IN ② /TRIG S W 1 Fig2. Rear panel ① LED  Green (Steady) Operating, but not receiving external trigger input  Green (Flashing) Operating and receiving external trigger input.

  • Page 9: Connectors And Pin Assignment

    This camera can be used with all Camera Link products that comply with the AIA Camera Link standard. Cables, transmission systems and frame grabbers/acquisition boards that do not comply with the Camera Link standard may work with this camera, but JAI Camera Solutions cannot be held responsible for loss in performance or damage of equipment, including the camera.
  • Page 10 LQ-050CL...

  • Page 11: Input And Output Circuits

    LQ-050CL Connector 2 ( Used only for 4 x 10 Bit output) Pin No In/Out Name Note 1,14 Shield 2(-),15(+) TxOUT0 3(-),16(+) TxOUT1 Data out 4(-),17(+) TxOUT2 5(-),18(+) TxClk Clock for CL 6(-),19(+) TxOUT3 Data out 7(+),20(-) 8(-),21(+) 9(-),22(+) 10(+),23(-)

  • Page 12: Een / Xeen Output (Exposure Enable)

    LQ-050CL 5.3.2 EEN / XEEN output (Exposure ENable) This output corresponds to the exposure (accumulation) time of the camera. It works together with all operation modes. It is, however, not active when the test pattern function is enabled. The EEN signal is available at the...

  • Page 13: Camera Link Interface (Bit Allocation)

    Tx24 FVAL 1 Tx25 LVAL 2 Tx24 FVAL 2 Tx25 DVAL Tx26 DVAL Tx26 Tx23 Tx23 Note: LVAL 1 &2 and DVAL 1&2 are the same signal. As the LQ-050CL is a line sensor camera, FVAL is always LOW. １２...

  • Page 14: Camera Link Output Port

    LQ-050CL 5.3.4 Camera link output port LQ-050CL handles R,G,B and NIR channels. The output ports for 8-bit and 10-bit are different. 8 bit output Input signal Camera link output Out1 Camera Link 1 　　Port 　a – c GREEN Out2 BLUE...

  • Page 15: Functions And Operation

    Fig.9 Signals flow The LQ-050CL uses four high-performance CCD line scan image sensors mounted on a prism block. During exposure, the incoming light is converted to electrons (electric charge) in photodiodes (active pixels). The transfer gate controls the transfer of charge from photodiodes to the shift register.

  • Page 16: Operating Mode

    Sensor layout 6.2. Operating mode The LQ-050CL has three operating modes. They are No-Shutter mode, Shutter-Select mode and PWC (Pulse Width Control) mode. The following chapters explain the details of these three modes. The output detail is shown below and is common with all modes.

  • Page 17: No-Shutter Mode With Internal Trigger

    LQ-050CL 6.2.1 No-Shutter mode with internal trigger In this mode the camera does not accept an external trigger signal, as the line rate is generated from an internal clock (user programmable, command LR). The exposure time is directly proportional to the line rate (T = 1/line rate).
  • Page 18 LQ-050CL Line rate 1L to 1024L LV A L E E N φP G φT G φA B φH 1 φH 2 D V A L Effective Video D ata Fig.12 No-Shutter mode with internal line rate generator Important Note ...

  • Page 19: No-Shutter Mode With External Trigger

    LQ-050CL 6.2.2 No-Shutter mode with external trigger In this mode, the exposure time is directly proportional to the line rate. The line rate is generated externally by a trigger signal. This mode is used when an external trigger signal available, e.g. from an encoder, and the scan rate can be controlled by this signal.

  • Page 20: Shutter-Select Mode With Internal Trigger

    LQ-050CL TRI G G ER LVA L φPG φTG φA B φH 1 φH 2 D VA L Effective video D ata Note: If the shutter is OFF, φAB is not output. Fig. 14 No-Shutter mode with external trigger 25CLK...

  • Page 21: Shutter-Select Mode With External Trigger

    LQ-050CL  If using individual exposure, the EEN signal represents the channel with the longest exposure time  The longest shutter operation is the same as the set trigger interval.  If one-push auto white balance is used, using the shutter (command AH) or using the gain (command AW) depends on applications.

  • Page 22: Pulse Width Control (Pwc) Mode

    LQ-050CL  If using individual exposure, the EEN signal represents the channel with the longest exposure time  The minimum trigger interval is 14.2μs.  If one-push auto white balance is used, using the shutter (command AH) or using the gain (Command AW) depends on applications.

  • Page 23: Scan Rate And Exposure Time Range

    LQ-050CL  When the one-push white balance has been initiated and the rear panel LED shows orange, the camera must receive continuous external trigger pulses corresponding to the frequency and duty cycle used in the application. T R IG G ER LV A L φP G...

  • Page 24: Compatibility Of Trigger Modes And Functions

    LQ-050CL 6.3.3 Compatibility of trigger modes and functions Functions Trigger Binning Pixel gain Shading One-Push WB Gain & Trigger Program & black correction black interval exposure Mode Gain Shutter correction level ctr. variable time (Accumu. variable) No-Shutter Internal Yes(*1) External...

  • Page 25: Functions Listed Alphabetically By Command Acronyms

    Settings 0 (off) and 1 (on). Factory default is 0 (off). In this mode, when a trigger pulse does not occur after more than 53ms, the LQ-050CL automatically returns to the internal trigger mode with the line rate of approx. 14.1μsec.

  • Page 26: Command Ah - Activate One-Push Auto White Balance (Awb) - Shutter

    LQ-050CL Command AH - Activate One-Push Auto White Balance (AWB) - Shutter By sending this command via the serial communication, the shutter based One-Push AWB function is activated. The white balance function takes approximately 3 seconds to complete. During this time the rear panel LED will show orange.

  • Page 27: Command Bi - Binning (Horizontal Only)

    “Master Tracking” and the other is “Individual”. The adjustable range for master black is 0 LSB to 255 LSB. The LQ-050CL has an automatic black level clamp function. This circuit is an analog circuit and after the signal level of dummy pixels is clamped at the constant level, it is digitized and the OB level is clamped at 32 LSB (8 LSB) in the digital clamp circuit.

  • Page 28: Command Ei - Interlocked R, G, B & Nir Exposure

    Applicable modes: Shutter-Select mode only (Internal and external) Note: The LQ-050CL has a priority for the line rate setting. If the exposure is use around the longest exposure speed which is nearly equal to the trigger cycle, please note the followings.

  • Page 29: Commands Gar2 , Gag2, Gab2 And Gair2 - Fine Gain (R,G, B And Nir)

     It is recommended to use 52.5μs to 2ms of line rate because the black level is stable in this range. 7.18 Command LUTC - LUT Control The LQ-050CL has an internal LUT(Look Up Table) for setting gamma. Command LUTC selects gamma OFF, Gamma 0.45 or LUT. Settings: 0 = Off 1 = 0.45...

  • Page 30: Command Nr - Noise Reduction

    LQ-050CL γ=User In this mode, R,G,B or NIR can be set individually. Settings: Range: 0 to 8191 LSB (200%) Setting point: 512 Setting point 7.19. Command NR - Noise Reduction Noise levels less than 16 LSB (4LSB) which are superimposed on the video signal will be eliminated.

  • Page 31: 7.22. Command Pbs - Request Status After Pixel Black Correction

    LQ-050CL Principle of Pixel black level correction (DSNU / FPN correction) Dark Signal Non-Uniformity or Fixed Pattern Noise is, as the name implies, fixed pattern on the sensor output, which is not dependent on the incoming light. Before correction: dark signal non-uniformity from pixel to pixel...

  • Page 32: Command Pgc - Enable Flat-Field Correction (Pixel Gain)

    LQ-050CL 7.24. Command PGC – Enable Flat-Field Correction (pixel gain) This command enables (or disables) the “pixel gain” (flat-field) correction function, which compensates for Pixel Response Non Uniformity (PRNU) for individual pixels. The algorithm for compensation is different in No-Shutter mode and Shutter-Select mode.

  • Page 33: 7.26. Command Pgs - Request Status After Pixel Gain Correction

    LQ-050CL To correct for PRNU, the camera’s internal correction circuit captures one or several lines of data under non-saturated illuminated conditions (not more than 80% of maximum - recommend level is half of maximum), and the average across the line is calculated.
  • Page 34 LQ-050CL JAI’s measuring conditions; Ambient temperature : 25°C Light source : 7800K, LED white light source Lens used: f35mm, F2.8 lens (A) Flat shading correction (SDR=0) Shading is calculated and individually compensated for R, G ,B and NIR channels respectively. The compensation range is within 30% as compare with the highest brightness in the previous line.

  • Page 35: Command Sds - Request Status After Executing Shading Correction Command

    LQ-050CL Shading correction tracking the green channel Note:  For this function, no reference value is stored in the camera. Operating procedure for individual R, B and NIR channel shadings correction: 1. Before making adjustment, approximately 30 minutes of warm up is required.

  • Page 36: Command Tp - Trigger Polarity

    LQ-050CL Fig.20 Rear panel 7.32. Command TP – Trigger Polarity Settings: 0=Active Low (factory default) 1=Active High 7.33. Command TR – Trigger Mode Selects the trigger mode of the camera. Depending on the mode used, it allows the scan rate to either be programmed by an internal timing generator or by and external trigger pulse.

  • Page 37: Command Wb - White Balance

    LQ-050CL 890 (222) 10bit (8-bit) Signal (RGB) 32 (8) 10bit (8-bit) Pixel count Fig. 23 Gray bars test pattern 890 (222) 10bit (8-bit) Signal (RGB) 32 (8) 10bit (8-bit) Pixel count Fig. 24 White level test pattern 7.35. Command WB – White Balance...

  • Page 38: Serial Communication And Command List

    8.1. Serial communication The LQ-050CL can communicate by serial communication via the Camera Link connector or via RS232C in the 12-pin Hirose connector. The Baud Rate is fixed at 9600 bps. Switch SW1 at the rear panel of the camera is used to select which way the serial communication is set up.

  • Page 39: Command List

    LQ-050CL Protocol. Transmit setting to camera: NN=[Parameter]<CR><LF> (NN is any kind of command. Capital or small letters.) The camera answers: COMPLETE<CR><LF> To have all communication visible on the emulator screen, start with: EB=1<CR><LF> The camera answers: COMPLETE<CR><LF> Transmit request command to camera: NN?<CR><LF>...
  • Page 40 LQ-050CL FPGA Program 3 digits Version PV?<CR><LF> Example: Request 100 = Version 1.00 Returns the camera’s Camera ID ID?<CR><LF> ID (?). Factory Request setting. Returns the camera’s Model Name MD?<CR><LF> model name. Factory Request setting. UD=[Param.]<CR><LF> User definable field. User ID UD?<CR><LF>...
  • Page 41 LQ-050CL mode TG=[Param.]<CR><LF> 0=Internal TG=0 is available Trigger Origin TG?<CR><LF> 1=External when TR=0 or TR=1 TI=[Param.]<CR><LF> 0=Camera-Link Trigger Input TI?<CR><LF> 1=Hirose12pin Trigger TP=[Param.]<CR><LF> 0=Active-Low Polarity TP?<CR><LF> 1=Active-High Auto reset ARST=[Param.]<CR><LF> 0=OFF ARST mode ARST?<CR><LF> 1=ON D - Image format BI=[Param.]<CR><LF>...
  • Page 42 LQ-050CL one-push AWB finished yet. 1=Succeeded. 2=Error1. Green image was too bright. 3=Error2. Green image was too dark. 4=Error3. Timeout-error occurred. GAR2=[Param.]<CR><LF> 8192=1 GAR2 Fine gain – red 6544 to 9830 GAR2?<CR><LF> Fine gain - GAG2=[Param.]<CR><LF> 8192=1 GAG2 6544 to 9830 Green GAG2?<CR><LF>...
  • Page 43 LQ-050CL Run pixel gain correction, PGR=[Param.]<CR><LF> 0=Run pixel gain correction, Store in user setting. store to user PGR?<CR><LF> store to user area area 0=Pixel gain correction not yet completed. Inquire the 1=Succeeded status after PGS?<CR><LF> 2=Error 1 – Image too bright...

  • Page 44: Camera Control Tool For Lq-050Cl

    Open the Control Tool Connect the camera to the PC on which the software is installed and set the power ON. Then select “All programs” in the Windows start menu, select “JAI A-S” and click “LQ-050CL control tool”. LQ-050CL Camera Control Tool and Communication windows will open.
  • Page 45 LQ-050CL 9.4. Camera control window When the connection between camera and PC is completed, the camera control tool shows the current camera settings. 9.5. LUT setting Open the drop-down menu under “LUT” and click “User”. When you click “LUT setting”, the following four windows for NIR, Red, Blue and Green will be...
  • Page 46 LQ-050CL When you drag the line and move it, the required gamma characteristics can be obtained. 9.6. Menus 9.6.1 File menu Open: Transfer the setting parameters in HDD or other memory devices to the camera. The extension is .cam Save as: Store the setting parameters in HDD other memory devices.
  • Page 47 LQ-050CL 9.5.4 Gamma menu Open Data file: Transfer the LUT data stored in HDD or the other memory devices, to the Control software. The file extension is .csv. Save Data to File: Store the LUT data set in the Control software, to HDD or other memory devices.

  • Page 48: External Appearance And Dimensions

    LQ-050CL External appearance and Dimensions Fig.25 External Appearance and Dimensions for M52 mount...
  • Page 49 LQ-050CL 4- M 4 depth 5.5 Cam era Li nk Connector Por t 1 6. 3 U4- 40: Fi xed scr ew POWER/ TRIG W.B. DC IN /TRIG S W1 4- M 4 HIROSE 12pi n Connector Nikon F- mount depth 5.5...

  • Page 50: Specifications

    LQ-050CL Specifications 11.1 Typical data Scanning system Line Scan Effective pixels :512 pixels Image Sensor Pixel Size : 14.0μm × 14.0μm Effective image length : 7.168mm Pixel clock 40.00 MHz Total pixels per line 564 clocks 14.10μs Internal trigger No-shutter, Shutter select...
  • Page 51 LQ-050CL Binning Horizontal Test pattern 0: Color Bar 1: Gray 1 2: Gray 2 3: White (890 LSB) 1. Pixel gain correction: Pixel Response Non Uniformity(PRNU),Dark Signal Non Uniformity(DSNU) 2. Shading compensation : ON / OFF Signal processing Flat shading compensation, Color shading compensation circuit 3.

  • Page 52: Camera Spectral Sensitivity

    Note 2: LSB numbers shown in parentheses is for 8-bit output. Note 3: This is effective only when specified connector or cable is used. Refer to chapter 5. Connectors. 11.2 Camera Spectral sensitivity LQ-050CL Spectral Transmittance NIRch 1000 1100 wavelength(nm)

  • Page 53: Appendix

    LQ-050CL Appendix Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera.

  • Page 54: Caution When Mounting The Camera

    Attaching the tripod mount Exportation When exporting this product, please follow the export regulation of your own country. References 1. This manual and datasheet for the LQ-050CL can be downloaded from www.jai.com 2. Camera control software can be downloaded from www.jai.com...

  • Page 55: Change History

    LQ-050CL Change history Date Revision Changes May 2011 New release Oct. 2012 Chapter 7.25 Change “flat-field” to “pixel gain” Dec. 2014 Correct default setting for PBC, PGC and SDC...

  • Page 56: User's Record

    Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
