3. Fuel System

Precautions in Operation

General Information
Warning
Gasoline is a low ignition point and explosive materials, so always work in a well-ventilated
place and strictly prohibit flame when working with gasoline.
Caution
Do not bend off throttle cable. Damaged throttle cable will make unstable drive-ability.
When disassembling fuel system parts, pay attention to O-ring position, replace with new
one as re-assembly.
There is a drain screw in the float chamber for draining residual gasoline.
Do not disassemble air cut valve arbitrarily.
Specification
Item
Carburetor diameter
I.D. number
Fuel level
Main injector
Idle injector
Idle speed
Throttle handle clearance
Pilot screw
Torque Value:
Carburetor holding nut: 0.7~1.1kgf-m
Special service tools
Vacuum/air pressure pump
General Tool
Float Chamber fuel level gauge
3-2
To this chapter contents
Specification
Ø 35 mm
PTG043B
14.8 mm
# 98
# 35
1500±100 rpm
2~6 mm
1 1/2 turns
