THE CYLINDER HEAD ASSEMBLY (2/3)
NO. PART NAME
1. VALVE (INTAKE)
2. VALVE (EXHAUST)
3. SPRING
4. SRIING CAP
5. VCOTTER
Please clean up correlative parts and lubricate with 10W/40 oil
1.Install valve spring (3) x4 on the valve spring washer
2.Install cotter (5) x2 on the spring cap (4) (4pcs)
3.Install assembled spring cap (3) on the spring , with jig press it into
the valve stems until a clear "clik" sound was heard
4.check the cap is firmly installed on the stem with jig
PART NO.
40050133
40050134
40050135
40050136
40056003
