Start System

Starter Specification:
- CECTEK Type: 40196007
- Output: 0.7 kW
- Operation Voltage: 12 V
Ring Gear
- Temperature Range: -10~+120℃
Starter Circuit Diagram :
Key S/W
Starter S/W
GND
Starter
Relay
Spin Nose
-
+
Starter
Rewind Starter Handler
Battery
GND GND
