Connector Pinouts

T1 Connector pinouts

T1 Connector pinouts
Pin
Signal
1
Rx Ring
2
Rx Tip
3
NC
4
Tx Tip
5
Tx Ring
6
NC
7
NC
8
NC

ADSL connector pinouts

Pin
Signal
1
NC
2
NC
3
Tip
4
Ring
5
NC
6
NC
16
CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide
