CellPipe IAD 8T

Configuring a CellPipe IAD 8T unit

Configuring a CellPipe IAD 8T unit
! Caution: If you attempt to manually configure the unit, a Delete Management Port
message appears. The unit disables Lucent TURN-UP to enable you to manually
configure the unit.
The Main menu items for the CellPipe IAD 8T unit are similar to those of other IAD
CellPipe units. Refer to the CellPipe™ IAD User's Guide for a discussion of the Main
menu items. The menu exception for the CellPipe IAD 8T can be found in its
Configure WAN menu.
To configure the WAN interface on the CellPipe IAD 8T unit, proceed as follows:
1
2
3
4
Table 2.
Menu option
Select Frame Mode
12
Select Configure WAN from the Main Menu.
Select Configure Physical Interface under the WAN Configuration
menu.
Set the desired frame mode.
Proceed with the remaining configurations. See Table 2.
T1 Configuration menu
CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide
Description
Choose between ESF (T1) Frame Mode
or D4 Frame Mode.
