CellPipe IAD 8T

Connecting a CellPipe IAD 8T unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Checking the activity of CellPipe IAD 8T status lights . . . . . . . . . . . . . . . . . . . . . 10
Configuring a CellPipe IAD 8T unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
The CellPipe IAD 8T supports eight POTS lines over ATM, PPP over ATM, Frame
Relay or HDLC (High-Level Data Link Control) over a T1 WAN interface. This
voice-over-T1 solution supports symmetrical transmission and receive rates of 1.544
Mbps.
Connecting a CellPipe IAD 8T unit
The CellPipe IAD box you receive contains the following items:
1 CellPipe IAD unit
2 10BaseT Ethernet crossover cable (yellow)
3 T1 WAN cable (blue)
4 Power supply
5 CellPipe™ IAD User's Guide
6 Hardware Installation Guide
CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide 9
