Lucent Technologies CellPipe IAD 4A Hardware Installation Manual page 23

Table 2.
Menu option
Select Line Build
Enable/Disable B8ZS
Configure Transmit Channels
Configure Receive Channels
Configure Clock Source
Change to E1 Mode
CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide
T1 Configuration menu (continued)
Configuring a CellPipe IAD 8T unit
Description
Displays the Select Line Build Out
submenu, which contains the following
commands that set compensation for
signal or line loss during the T1
connection. Check with your service
provider for the appropriate signal loss
(dB).
– 1. 0 to 133 Feet (0 dB)
– 2. 133 to 266 Feet
– 3. 266 to 399 Feet
– 4. 399 to 533 Feet
– 5. 533 to 655 Feet
– 6.0 – 7.5 dB
– 7.0 – 15 dB
– 8. 0 – 22.5 dB
Enables and disables bipolar 8-zero
substitution (B8ZS) line code.
Allows you to set the number of
transmission channels (maximum 24)
for the WAN interface.
Allows you to set the number of receive
channels (maximum 24) for the WAN
interface.
Choose the Internal or External Clock
Source.
Currently not supported.
CellPipe IAD 8T
13
