Connector Pinouts

TERMINAL pinouts

Pin
Signal
1
GND
2
Tx Data
3
Rx Data

10/100 LAN connector pinouts

Pin
Signal
1
Tx
2
Tx
3
Rx
4
NC
5
NC
6
Rx
7
NC
8
NC
CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide
15
