- Page 1 OnCell 5000 Series User’s Manual Sixth Edition, July 2015 www.moxa.com/product © 2015 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.
-
Page 2: Copyright Notice
OnCell 5000 Series User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright ©2015 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Trademarks The MOXA logo is a registered trademark of Moxa Inc. -
Page 3: Table Of Contents
Product Specifications ......................... 1-3 Specification Comparison Chart ..................... 1-3 Getting Started ..........................2-1 Panel Layout ............................2-2 OnCell 5004-HSPA ........................2-2 OnCell 5104-HSPA ........................2-3 DIN-Rail and Rack Mounting ......................... 2-4 Wall or Cabinet Mounting ......................2-4 DIN-Rail Mounting ........................2-4 Connecting the Hardware ........................ - Page 4 Tools ..............................5-9 Manual SMS ..........................5-9 PING Test ........................... 5-9 Certificate ............................5-10 Ethernet SSL Certificate Import ....................5-10 Certificate/Key Delete ........................ 5-10 System Monitoring ..........................5-10 Network Connections ......................... 5-10 Network Statistics ........................5-11 Routing ............................ 5-11 DHCP Client List ........................5-11 Internet Sessions List ........................
- Page 5 Auto IP Report Protocol ........................C-1...
-
Page 6: Introduction
The OnCell 5000 cellular routers use a WAN connection to allow you to access your network from virtually anywhere within the operating range of your WAN network. There are currently three OnCell 5000 models: The OnCell 5004-HSPA, OnCell 5104-HSPA, and OnCell 5104-HSPA-T. The main differences between the models are the mechanical design, and I/O. -
Page 7: Overview
OnCell 5000 cellular routers are shipped with the following items: Standard Accessories • Rubber SMA antenna • Rubber stand (OnCell 5004-HSPA only) • Wallmount Kit (OnCell 5004-HSPA only) • Din-Rail Kit (OnCell 5104-HSPA only) • Terminal block (screw type) •... -
Page 8: Product Specifications
OnCell 5000 Series Introduction Product Specifications Specification Comparison Chart Cellular Router OnCell 5004-HSPA OnCell 5104-HSPA Cellular Interface Standards GSM/GPRS/EDGE/UMTS/HSPA UMTS/HSPA band Options 800/850/AWS/1900/2100 MHz HSPA Data Rate 14.4 Mbps DL, 5.76 Mbps UL GSM/GPRS/EDGE band Options 850/900/1800/1900 MHz EDGE Data Rate... - Page 9 OnCell 5000 Series Introduction Standards and Certifications Safety UL 60950-1 FCC Part 15 Subpart B Class A EN 55022 Class A, EN 55024 Radio FCC Part 22H, FCC Part 24E EN 301 489-1, EN 301 489-7, EN 301 489-24 EN 301 511, EN 301 908 Reliability Warranty 5 years (see www.moxa.com/warranty)
-
Page 10: Getting Started
This chapter covers the hardware installation of the OnCell 5000. Software installation is covered in the next chapter. The following topics are covered in this chapter: Panel Layout OnCell 5004-HSPA OnCell 5104-HSPA DIN-Rail and Rack Mounting Wall or Cabinet Mounting ... -
Page 11: Panel Layout
OnCell 5000 Series Getting Started Panel Layout OnCell 5004-HSPA... -
Page 12: Oncell 5104-Hspa
OnCell 5000 Series Getting Started OnCell 5104-HSPA... -
Page 13: Din-Rail And Rack Mounting
DIN-Rail and Rack Mounting Wall or Cabinet Mounting The OnCell 5004-HSPA device servers have built-in “ears” for attaching the device server to a wall or the inside of a cabinet. We suggest using two screws per ear to attach the device servers to a wall or the inside of a cabinet. The heads of the screws should be less than 6.0 mm in diameter, and the shafts should be less than 3.5 mm... -
Page 14: Sim Card Installation
OnCell 5000 Series Getting Started SIM Card Installation In order to protect the SIM card, the SIM card slot is located inside the OnCell 5004 and 5104 series’ housing. You will need to unscrew and remove the outer SIM card cover before installing or removing the SIM card. OnCell 5004 Series OnCell 5104 Series Connecting the Power... -
Page 15: Led Indicators
OnCell 5000 Series Getting Started LED Indicators The following table explains the LED indicators on the front panel of the OnCell 5000 Series: Type Color LED Function Green Activation of DC Power PWR 1 Power is off, or power error condition exists. Green Activation of DC Power PWR 2... -
Page 16: Initial Ip Address Configuration
Initial IP Address Configuration When setting up the OnCell 5000 for the first time, the first thing you should do is configure the IP address. This chapter introduces the different methods that can be used to do this. The following topics are covered in this chapter: ... -
Page 17: Static And Dynamic Ip Addresses
OnCell 5000 Series Initial IP Address Configuration Static and Dynamic IP Addresses Determine whether your OnCell 5000 needs to use a static IP address or dynamic IP address (either DHCP or BOOTP application). • If your OnCell 5000 is used in a static IP environment, you must assign a specific IP address using one of the tools described in this chapter. -
Page 18: Arp
OnCell 5000 Series Initial IP Address Configuration You may use the ARP (Address Resolution Protocol) command to set up an IP address for your OnCell 5004/5104-HSPA. The ARP command tells your computer to associate the OnCell 5004/5104-HSPA’s MAC address with an IP address. Afterwards, use Telnet to access the OnCell 5004/5104-HSPA and its IP address will be reconfigured. - Page 19 OnCell 5000 Series Initial IP Address Configuration 1. From the Windows desktop, select Start Run, and then type the following content in the Run window: telnet 192.168.127.254. If your IP address is different from the default setting, use your IP address instead.
- Page 20 OnCell 5000 Series Initial IP Address Configuration 4. Press N or use the arrow keys to select Network, and then press ENTER. 5. Press L or use the arrow keys to select LAN, and then press ENTER. 6. Use the arrow keys to move the cursor to IP address. Use the DELETE, BACKSPACE, or SPACE keys to erase the current IP address, and then type in the new IP address and press ENTER.
-
Page 21: Serial Console
OnCell 5000 Series Initial IP Address Configuration 8. Press A or use the arrow keys to select Save and then press ENTER. Press ENTER again to confirm the save command. 9. Press R or use the arrow keys to select Restart and then press ENTER. Press ENTER again to restart the OnCell 5000. - Page 22 OnCell 5000 Series Initial IP Address Configuration 4. The Property window opens automatically. Select the Communication Parameter tab, and then select the appropriate COM port for the connection (COM1 in this example). Configure the parameters to 115200 for Baud Rate, 8 for Data Bits, None for Parity, and 1 for Stop Bits. 5.
- Page 23 OnCell 5000 Series Initial IP Address Configuration 6. If the OnCell 5000 has been set up for password protection, you will be prompted to enter the password. After you enter the password, or if password protection was not enabled, you will be prompted to select the terminal mode.
-
Page 24: Web Console Configuration
Web Console Configuration In this chapter, we explain all aspects of the web-based console configuration utility. Moxa’s easy-to-use management functions will help you set up your OnCell 5000 and allow you to maintain your wireless network easily. The following topics are covered in this chapter: ... -
Page 25: Accessing The Web Console
OnCell 5000 Series Web Console Configuration Accessing the Web Console Open your web browser and enter 192.168.127.254 in the website address line. This is the default IP address for the OnCell 5000—if a new address has been assigned, enter the new address instead. Press ENTER to load the page. -
Page 26: Basic Settings
OnCell 5000 Series Web Console Configuration You must click on the Submit button to keep your configuration changes. The Submit button is located at the bottom of every page that has configurable settings. If you navigate to another page without clicking the Submit button, your settings will be lost. -
Page 27: Network Settings
OnCell 5000 Series Web Console Configuration Time server: The OnCell 5000 uses SNTP (RFC-1769) for auto time calibration. You may enter a time server IP address or domain name in this optional field. Once the OnCell 5000 is configured with the correct time server address, it will request time information from the time server every 10 minutes. -
Page 28: Lan Port Configuration
OnCell 5000 Series Web Console Configuration LAN Port Configuration LAN Port Configuration settings are included to give the user control over Port Access, Port Transmission Speed, Flow Control, and Port Type (MDI or MDIX). An explanation of each configuration item is given below. Enable (default=Yes): Option Description... -
Page 29: Guaranlink Settings
OnCell 5000 Series Web Console Configuration WAN Preference (default=Cellular): Select either cellular or Ethernet. Note that the WAN preference option on the Ethernet WAN settings page (see below) will be updated automatically. Note: You need to select one of the two WAN preferences. If the line is disconnected, the router will not automatically switch to the other WAN preference. -
Page 30: Common Settings
OnCell 5000 Series Web Console Configuration Background 1. “Register to network” and “Establish PPP with ISP” are two steps for establishing connection with the ISP. 2. If GuaranLink determines that the OnCell cannot establish connection with the ISP, it reboots the OnCell in order to allow the OnCell to retry the connection once rebooted. -
Page 31: Ethernet Wan Settings
OnCell 5000 Series Web Console Configuration • Packet-level connection check action (default=DNS and PING): This setting specifies whether the check action is successful when both of the DNS lookup and the ping action succeed, or if it is successful even if only one of them succeed. Packet-level connection check interval (min) (default=5 min): This setting specifies the interval •... -
Page 32: Dns Settings
OnCell 5000 Series Web Console Configuration PPPoE password: Enter your password. WAN speed (default=Auto): Option Description Auto Allows the port to use the IEEE 802.3u protocol to negotiate with connected devices. The port and connected devices will determine the best speed for that connection. -
Page 33: Dhcp Settings
OnCell 5000 Series Web Console Configuration DHCP Settings DHCP (default=Enable): DHCP stands for Dynamic Host Control Protocol. When you enable the DHCP Server, it will automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.”... -
Page 34: Oncell Central Manager
OnCell 5000 Series Web Console Configuration Report to UDP port (default=63100): This is the UDP port number assignment for the serial port on the OnCell 5000. Report period (default=99): You can use this option to set the automatic report time. OnCell Central Manager Please refer to Chapter 7. -
Page 35: Wan Ip Filter
OnCell 5000 Series Web Console Configuration WAN IP Filter The OnCell 5000 uses an IP address-based filtering method to control access to its Ethernet ports. The WAN IP Filter allows you to restrict network access to the OnCell 5000. Access is controlled by IP address. When the WAN IP Filter list is enabled, a WAN’s IP address must be listed in order to gain access to the OnCell 5000. -
Page 36: Route Table
OnCell 5000 Series Web Console Configuration Route Table You can access the Route Table by expanding Advanced Network Settings in the navigation panel. Use the route table to configure how the OnCell 5000 will connect to an outside network. You are allowed up to 16 entries in the route table. For each entry, you must provide the gateway, destination, netmask type, netmask, metric hops, and interface. -
Page 37: System Management Settings
System Management Settings In this chapter, we describe the OnCell 5000’s system management settings. The same configuration options are also available through the Telnet and serial console. The following topics are covered in this chapter: Misc. Network Settings SNMP Agent Settings ... -
Page 38: Misc. Network Settings
OnCell 5000 Series System Management Settings Misc. Network Settings SNMP Agent Settings SNMP: To enable the SNMP Agent function, select the Enable option, and enter a community name (e.g., public). Read community string (default=public): This is a text password that is used to weakly authenticate queries to agents of managed network devices. -
Page 39: Ddns Configuration
OnCell 5000 Series System Management Settings DDNS Configuration DDNS (default=Enable): The Dynamic Domain Name System is a method of keeping a domain name linked to a changing IP Address. Check the box to enable DDNS. Server address: Choose your DDNS provider Dyndns or NO-IP from the drop down menu. Host name: Enter the Host Name that you registered with your DDNS service provider. -
Page 40: E-Mail Alert
OnCell 5000 Series System Management Settings NOTE If you select “enable for SMS,” the receiver will receive the message in the following format: [modelName] alert (S/N: [serial number], LAN: [LAN IP], [LAN MAC Address]): (C-WAN/E-WAN/P-WAN: [WAN IP]): (yyyy-mm-dd hh:mm:ss) [message] indicates the cellular WAN IP address C-WAN: x.x.x.x indicates the Ethernet WAN IP address and “P-WAN: x.x.x.x”... -
Page 41: Snmp Trap
OnCell 5000 Series System Management Settings ATTENTION Consult your Network Administrator or ISP for the proper mail server settings. The Auto warning function may not work properly if it is not configured correctly. The OnCell 5000’s SMTP AUTH supports LOGIN, PLAIN, and CRAM-MD5 (RFC 2554). -
Page 42: Maintenance
OnCell 5000 Series System Management Settings Maintenance Console Settings On this screen, access to different OnCell 5000 configuration console options (HTTP, HTTPS, Telnet, SSH) can be enabled or disabled. Refer to Change Password later in this chapter for more information on passwords. Reset button (default=Always Enable): Select “Always Enable”... -
Page 43: Configuration Import/Export
OnCell 5000 Series System Management Settings The OnCell 5000’s firmware can be upgraded though the web console or the OnCell Search Utility. If you have made any changes to your configuration, remember to save the configuration first before upgrading the firmware. -
Page 44: Change Password
OnCell 5000 Series System Management Settings Change Password For all changes to the OnCell 5000’s password protection settings, you will first need to enter the old password. Leave this blank if you are setting up password protection for the first time. To set up a new password or change the existing password, enter the password under both New password and Confirm password. -
Page 45: Tools
OnCell 5000 Series System Management Settings Remote SMS Control: Enable or disable the ability of the OnCell to be controlled by SMS (default: disabled). Password: Set your password (4-16 characters). Auth type: You can restrict the access by enabling the Caller ID under Auth Type. Caller ID: Enter Caller ID number so that only SMS from specific senders can trigger Remote SMS control. -
Page 46: Certificate
OnCell 5000 Series System Management Settings Certificate Ethernet SSL Certificate Import SSL certificate is used to ensure that the website you are accessing is the one you trust, and to encrypt the data transmitted between you and the website. The SSL certificate contains unique, authenticated information about the certificate owner. -
Page 47: Network Statistics
OnCell 5000 Series System Management Settings Network Statistics Go to System Monitoring under Network Statistics to view network statistics. Routing Go to System Monitoring under Routing to display the routing information. Possible flags include: • U: route is up • D: route is down •... -
Page 48: System Log
OnCell 5000 Series System Management Settings System Log This option displays the system log. You may click Select all to select the entire log if you wish to copy and paste the contents into a text file. Dout State Dout State refers to the relay output status, which can be configured to change upon the occurrence of certain system events through Auto Warning Settings under System Management. -
Page 49: Save Configuration
OnCell 5000 Series System Management Settings Save Configuration Go to Save Configuration and then click Save to save your submitted configuration changes to the OnCell 5000’s flash memory. The configuration changes will be effective when the OnCell 5000 is restarted. If you do not save your changes before restarting, they will be discarded. -
Page 50: Introduction And Configuring Vpn
Introduction and Configuring VPN In this chapter, we explain how to configure a VPN with the OnCell 5000 web console. The following topics are covered in this chapter: What Are VPNs? OnCell VPN Specifications OnCell VPN Web Console Settings ... -
Page 51: What Are Vpns
OnCell 5000 Series Introduction and Configuring VPN What Are VPNs? Computers that are part of a VPN use a second, “virtual” IP address to connect to the Internet. Instead of running across a single private network, some of the links between nodes that are part of a VPN use open network connections or virtual circuits on a larger network, such as the Internet. -
Page 52: Oncell Vpn Web Console Settings
OnCell 5000 Series Introduction and Configuring VPN OnCell VPN Web Console Settings From the left navigation panel, click Network Advanced Network Settings VPN to configure the OnCell VPN Settings. The configuration items are shown below: Manual Key/ESP Configuration VPN tunnel (default = Disable) : Enable or disable the VPN tunnel function. VPN tunnel mode: The type of VPN tunnel policy to be used;... -
Page 53: Incoming Security Settings
OnCell 5000 Series Introduction and Configuring VPN Incoming Security Settings SPI: This sets the VPN manual key incoming SPI between 257 and 4294967295. Encryption mode: Select the incoming encryption mode. Encryption key: Enter the incoming encryption key. Encryption mode Length (Bytes) 3DES AES 128bit AES 192bit... -
Page 54: Isakmp/Psk
OnCell 5000 Series Introduction and Configuring VPN ISAKMP/PSK Configuration VPN tunnel (default = Disable) : Enable or disable the VPN tunnel function. VPN tunnel mode: The type of VPN tunnel policy to be used; either manual key IPsec or ISAKMP with Pre-shared Keys (PSK). -
Page 55: Isakmp (Key Management)
OnCell 5000 Series Introduction and Configuring VPN ISAKMP (Key Management) Pre-shared key (PSK): This sets the VPN ISAKMP Pre-Shared key settings. Perfect forward secrecy (PFS) (default = Disable): Enable or disable the Perfect Forward Secrecy. PFS is an additional security protocol. Local Identity Identity option: Select additional ID authentication requirements for the VPN using a specific IP Address, FQDN, or User FQDN settings. -
Page 56: Vpn System Log Events And Error Codes
OnCell 5000 Series Introduction and Configuring VPN VPN system log events and error codes VPN system log Description VPN init. VPN tunnel initial VPN init. by packet VPN tunnel initial by packet driven VPN stop VPN tunnel stop VPN phase2 SA time out VPN tunnel phase 2 security association time out VPN time out VPN tunnel connect time out... -
Page 57: Configuring Oncell Central Management Software
Configuring OnCell Central Management Software In this chapter, we introduce OnCell Central Management Software, and explain how to configure OnCell Central Management Software with the OnCell 5000 web console, install and set the OnCell Central Driver Manager, and cover all of the equipment specifications. The following topics are covered in this chapter: ... -
Page 58: Step 1: Server Settings
OnCell 5000 Series Configuring OnCell Central Management Software Step 1: Server Settings System Requirements Hardware Requirements Your computer’s hardware must meets the following minimum requirements: • Pentium III or above • 500 MHz CPU (1 GHz recommended) • 256 Mb RAM (1 GB recommended) •... - Page 59 OnCell 5000 Series Configuring OnCell Central Management Software 2. Click Next when the Welcome screen opens to proceed with the installation. 3. Click Next to install program files to the default directory, or click Browse to select an alternate location. 4.
- Page 60 OnCell 5000 Series Configuring OnCell Central Management Software 5. Click Next to proceed with the installation. You will be prompted to select additional tasks. 6. Click Next to proceed with installation. Setup will display a summary of the installation options. 7.
-
Page 61: Using Oncell Central Manager
OnCell 5000 Series Configuring OnCell Central Management Software 8. Click Finish to complete the installation of the OnCell Central Manager. Using OnCell Central Manager After you install OnCell Central Manager, you can set up the OnCell 5000’s OnCell Central Settings for your PC host. - Page 62 OnCell 5000 Series Configuring OnCell Central Management Software 2. Click on Tool Control Ports Settings to modify the port number. To modify the new configuration of control ports, you can make all configuration changes here. The Control Ports Setting’s information must match the web console’s OnCell Central Server Settings. Please refer to Step 2, OnCell Device Web Console Settings, for control port information.
- Page 63 OnCell 5000 Series Configuring OnCell Central Management Software 4. If you need to import/add a long pre-defined device list to the OnCell Central Server, follow the next step, otherwise skip directly to Step 9. 5. To import the configuration from a text file, click on Tool Import OnCell User Ports/Service Forwarding.
- Page 64 OnCell 5000 Series Configuring OnCell Central Management Software 6. Alternatively, for OnCell User Ports and Service Forwarding, you can manually enter the information. Click on Tool Add OnCell User Ports/Service Forwarding. (Same step as Import Service Forwarding.) 7. In order to view the information you have been imported or added, click on View (same step as Import Service Forwarding).
- Page 65 OnCell 5000 Series Configuring OnCell Central Management Software 8. To save All the configuration settings to an xml file format, select Export DataBase from the OnCell Central menu. You will then be able to import this configuration file to another host and use the same OnCell Central settings on the other host.
-
Page 66: Step 2: Oncell Device Web Console Settings
OnCell 5000 Series Configuring OnCell Central Management Software Step 2: OnCell Device Web Console Settings OnCell Central Settings From the left navigation panel, click Network Settings OnCell Central Settings OnCell Central Server to configure the OnCell Central Settings. The configuration items are shown below: OnCell Central Server Configuration Server (default=Disable): If you select Enable, the OnCell will be ready to connect to the OnCell Central... -
Page 67: Service Forwarding
OnCell 5000 Series Configuring OnCell Central Management Software Service Forwarding From the left navigation panel, click Network Settings OnCell Central Settings Service Forwarding to configure the OnCell Central Settings. The configuration items are shown below: Service forwarding (default=Disable): If enabled, this option will establish the Ethernet device connection of the OnCell device to OnCell Central Server. - Page 68 OnCell 5000 Series Configuring OnCell Central Management Software 2. Select Security Settings, select Internet, and then click Custom Level. 3. Enable Download signed ActiveX controls. 4. Enable Run ActiveX controls and plug-ins. 7-12...
- Page 69 OnCell 5000 Series Configuring OnCell Central Management Software 5. Enable Script ActiveX controls marked safe for scripting and then click OK. 6. Select Trusted sites under Security and then click on Sites… 7. Enter your IP address for your OnCell Central’s web page, then click Add. 7-13...
- Page 70 OnCell 5000 Series Configuring OnCell Central Management Software 8. Click on Custom Level… 9. Enable Download signed ActiveX controls 10. Enable Run ActiveX controls and plug-ins 7-14...
-
Page 71: Oncell Central Web Console
OnCell 5000 Series Configuring OnCell Central Management Software 11. Enable Script ActiveX controls marked safe for scripting and then click OK OnCell Central Web Console 1. Start the web browser. 2. In the Address input box, enter the OnCell Central’s web IP address follow with the 8080 port (e.g., 192.168.127.111:8080). -
Page 72: Overview
OnCell 5000 Series Configuring OnCell Central Management Software Overview The page shows which OnCell Central Manager version number you are using. Control Ports/User Ports Information. Control Ports Information. Control ports are used to establish a connection between an OnCell device and the OnCell Central Server. This section shows all control port information that has already been configured. -
Page 73: Account Settings
OnCell 5000 Series Configuring OnCell Central Management Software Account Settings For all changes to the OnCell Central’s admin and password protection settings, you will first need to enter the old password. To set up a new password or change the existing password, enter your desired password under both New password and Confirm password. -
Page 74: All Devices
OnCell 5000 Series Configuring OnCell Central Management Software All Devices This table describes All Devices that are connected to OnCell Central Server: Item Description Device MAC Each Device has unique MAC ID that you can find on the device label or web/telnet/serial console Device Name Device’s Name... -
Page 75: All User Ports
OnCell 5000 Series Configuring OnCell Central Management Software After creating the group, you can copy the devices under All Devices folder to create a new folder (e.g., South Remove Device. To maintain the list, you can remove all offline devices. To activate this function, click the right mouse button and select Remove Device. -
Page 76: Service Forwarding
OnCell 5000 Series Configuring OnCell Central Management Software Service Forwarding The Service Forwarding table displays the host’s established Ethernet connection to the OnCell Central Server, and the corresponding OnCell devices. Item Description Status Shows the status of the user’s service ports. Closed: this mean the port is not connected Registered: this mean the OnCell is connected to OnCell Central Server. -
Page 77: Device's Settings And Maintenance
OnCell 5000 Series Configuring OnCell Central Management Software Clear finished and cancelled upgrades: This button clears all firmware upgrades that have been finished and canceled. Cancel selected devices: This button cancels the firmware upgrading process of the selected device(s). Select All: This button makes it easy to select all of your devices for firmware upgrades. Firmware Upgrade: This button will initiate a firmware upgrade for the devices you have selected. -
Page 78: Overview
OnCell 5000 Series Configuring OnCell Central Management Software Overview This page shows the OnCell’s device information: User Ports Telnet Enable: If you click on the enable icon, Telnet will permit the the host to connect to the OnCell device. If no connections are made within 30sec, the port will just close. Change User Port: If you do not want to use the system’s assigned user ports, you may change the User Data Port, User Command Port, and Telnet Port here (does not apply to the OnCell 5004 and 5104). -
Page 79: Service Forwarding
OnCell 5000 Series Configuring OnCell Central Management Software Note: If the data or command port is occupied, an error message will appear at the bottom of the window. Service Forwarding Item Description Status Show the status of the User Service Port. Closed: Means the port is not connected. -
Page 80: Maintenance
OnCell 5000 Series Configuring OnCell Central Management Software Maintenance Configuration Export To save all tconfigurations to an xml file, select Configuration Export and then click Download. Configuration Import Allows you to import this configuration file to another host and use the same OnCell Central settings in the other host. -
Page 81: Logout
OnCell 5000 Series Configuring OnCell Central Management Software Logout 7-25... -
Page 82: Oncell Search Utility
OnCell Search Utility The following topics are covered in this chapter: Installing the Search Utility Configuring the OnCell Search Utility... -
Page 83: Installing The Search Utility
OnCell 5000 Series OnCell Search Utility Installing the Search Utility 1. Click the INSTALL UTILITY button in the OnCell Installation CD auto-run window to install OnCell Search Utility. Once the program starts running, click Yes to proceed. 2. Click Next when the Welcome screen opens to proceed with the installation. 3. -
Page 84: Configuring The Oncell Search Utility
OnCell 5000 Series OnCell Search Utility 5. Click Next to proceed with the installation. The installer then displays a summary of the installation options. 6. Click Install to begin the installation. The setup window will report the progress of the installation. To change the installation settings, click Back and navigate to the previous screen. - Page 85 OnCell 5000 Series OnCell Search Utility 2. When the search is complete, all OnCell 5000 servers that were located will be displayed in the OnCell Search Utility window. 3. Click Locate to cause the selected device to beep. 4. To modify the configuration of the highlighted OnCell 5000, click on the Console icon to open the web console.
- Page 86 OnCell 5000 Series OnCell Search Utility 6. To change the configuration of the IP Address Report, click on the Settings icon to open the IP Location Settings. The Local UDP listen Port number should match the web console Auto IP Report Settings’ port number.
-
Page 87: Default Settings
Default Settings Setting Name Default Name Web Console Login Username admin Password Keep <blank> Network Settings LAN IP address 192.168.127.254 WAN IP address 192.168.126.254 Network 255.255.255.0 WAN Preference Cellular Cellular Settings SIM PIN <blank> NAT service Enable DHCP Service Settings DHCP Server Enable DNS relay... -
Page 88: Dynamic Domain Name Server
Dynamic Domain Name Server This appendix explains how to use the OnCell 5000 with DDNS. When the OnCell 5000 receive its IP address from a DHCP (Dynamic Host Configuration Protocol) server, remote servers will be unable to access it using a fixed IP address. -
Page 89: Configuration
OnCell 5000 Series Dynamic Domain Name Server The above screenshot shows how DHCP can be set up to update the DNS. Currently, the OnCell 5000 supports DNS service as provided by DynDNS. For detailed information on this option, please visit https://www.dyndns.com. Configuration DDNS (default=Disable): Use this field to enable or disable DDNS. - Page 90 Auto IP Report Protocol OnCell Series provides several ways to configure the Ethernet IP addresses. One of them is DHCP Client. When you set up the OnCell to use DHCP Client to configure Ethernet IP addresses, it will automatically send a DHCP request over the Ethernet to find the DHCP Server.
- Page 91 OnCell 5000 Series Auto IP Report Protocol AP ID & Hardware ID Mapping Table AP ID Hardware ID Product 0x80005260 0x5061 5004-HSPA 0x80005260 0x5161 5104-HSPA...
