80 SERIES
AIR STAPLER
12.8mm
INSTRUCTION MANUAL
SPECIFICATIONS
Min. Pressure:
70PSI
Max. Pressure:
120PSI
Magazine Capacity:
100 Staples
Staple Type:
12.8mm
Staple Length:
6-16mm
Air Inlet:
1/4" BSP
Weight:
0.85 kg
ozito.com.au
WHAT'S IN THE BOX
Air Stapler
Safety Goggles
Oil Pot
200 Staples
Hex Keys
Kit Box
RST-80S
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Ozito 80 series
Summary of Contents for Ozito 80 series
- Page 1 WHAT’S IN THE BOX 80 SERIES Air Stapler AIR STAPLER 12.8mm Safety Goggles INSTRUCTION MANUAL SPECIFICATIONS Oil Pot Min. Pressure: 70PSI Max. Pressure: 120PSI Magazine Capacity: 100 Staples Staple Type: 12.8mm 200 Staples Staple Length: 6-16mm Air Inlet: 1/4” BSP Weight: 0.85 kg...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION AIR STAPLER 1. CONNECTING AIR SUPPLY 1 Striker Pin 5 Magazine Release 2 Trigger Lock-off 6 Magazine WARNING! ENSURE ThE TOOL IS dISCONNECTEd fROM 3 Trigger 7 Air Inlet Connector ThE AIR SUPPLy bEfORE PERfORMING ANy Of ThE 4 Handle fOLLOWING OPERATIONS.
- Page 3 OPERATION 2. LOADING STAPLES 3. CONTROLS 1. Squeeze the magazine release and pull the magazine away from Trigger Lock-off the tool. 1. T o prevent the stapler from firing, rotate the trigger lock-off so that it stops the trigger from being pressed. 2. Place a row of staples into the middle of the magazine so that the staples fit cumfortably in the inner chamber.
- Page 4 4. OPERATING THE STAPLE GUN 5. TROUBLESHOOTING 1. Place the staple gun against the work surface so that the WARNING! ENSURE ThE TOOL IS dISCONNECTEd fROM nosepiece of the tool is where you want the staple to be located. ThE AIR SUPPLy bEfORE PERfORMING ANy Of ThE fOLLOWING OPERATIONS.
- Page 5 Spare parts can be ordered from the Special Orders desk at your local bunnings Warehouse. for further information, or any parts not listed here, visit CARING FOR THE ENVIRONMENT www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486 E-mail: enquires@ozito.com.au Power tools that are no longer usable should not be disposed of with household waste but in an environmentally friendly way.
- Page 6 Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item description Part No. description Part No. how To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any...
- Page 7 GENERAL AIR TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. failure to follow the warnings WARNING! and instructions may result in electric shock, fire and/or serious injury. In the event that an air line is cut or broken, the air supply must be turned off at the compressor. A broken air line which is not supported is extremely dangerous and can whip around Save all warnings and instructions for future reference.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO 0414 Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
