893-878-B
Bay Networks 58000 Ethernet Switch Model
System Up Time: 1 D-12H-22M-11S
MAC Address: 000081000201
Switch Software Version: 1.4.3
Use cursor keys to choose item. Press <RETURN> to confirm choice.
<CTRL><P>:Main Menu

Figure 6-12. Switch Port Flow Control menu

4. Choose the port you want to change.
The system displays the current flow control setting for that port and
prompts you to change the setting. The current flow control setting is
highlighted, and the other flow control option is displayed unhighlighted.
5. Select the new flow control option, either enable or disable.
The system prompts you for confirmation. The modified ports use the new
port flow control settings immediately.
6. Repeat steps 4 and 5 for additional ports.
Using the System Configuration Menus
Switch Port Flow Control
Port
MDA P1
MDA P2
Enable/Disable MDA Port Flow Control
<CTRL><U>:Previous Menu
IP Address: 134.177.32.98(M)
Default Gateway: 134.177.32.1
Subnet Mask: 255.255.255.0
Flow Control
[Enable]
[Enable]
<CTRL><L>:Refresh Screen
6-25
