Appendix A Technical Specifications
General Specifications
893-878-B
This appendix lists technical specifications and includes a declaration of
conformity for the Model 58000 switch.
Network Protocol and Standards Compatibility
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-T
Data Rate and Encoding
Built-in ports:
MDA ports:
Interfaces
Built-in ports:
MDA ports:
Electrical Specifications
Power consumption:
Without MDA:
With MDA:
Thermal rating:
Without MDA:
With MDA:
10 Mb/s Manchester Encoding for 10BASE-T
100 Mb/s with 4B5B encoding and
MLT-3 physical interface for 100BASE-TX
100 Mb/s with 4B5B encoding and
NRZI physical interface for 100BASE-FX
RJ-45 connectors for 10BASE-T ports
RJ-45 connectors for 100BASE-TX MDA ports
SC fiber optic connectors for 100BASE-FX MDA ports
60W @ -48VDC
78W @ -48VDC
205 BTU/Hr.
266 BTU/Hr.
A-1
