Configuring the Model 58000 Switch
6-30
Bay Networks 58000 Ethernet Switch Module
System Up Time: 1 D-12H-22M-11S
MAC Address: 000081000201
Switch Software Version: 1.4.3
Expansion Module-Switch Port Flow Control
Use cursor keys to choose item. Press <RETURN> to confirm choice.
<CTRL><P>: Main Menu
Figure 6-16. Expansion Module-Switch Port Flow Control menu
2. Choose the port you want to change.
The system displays the current flow control setting for that port and
prompts you to change the setting. The current flow control setting is
highlighted and the other flow control option is displayed unhighlighted.
3. Select the new flow control option, either enable or disable.
The system prompts you for confirmation. The modified ports use the new
port flow control settings immediately.
4. Repeat steps 2 and 3 for additional ports.
Port
MDA1 P1
MDA1 P2
MDA2 P1
MDA2 P2
MDA3 P1
MDA3 P2
MDA4 P1
MDA4 P2
Enable/Disable MDA Port Flow Control
<CTRL><U>: Previous Menu
IP Address: 134.177.32.98(M)
Default Gateway: 134.177.32.1
Subnet Mask: 255.255.255.0
Flow Control
[Enable]
[Enable]
[Enable]
[Enable]
[Enable]
[Enable]
[Enable]
[Enable]
<CTRL><L>: Refresh Screen
