1073 & 1084 Channel Amplifiers

Dimensions

Stand-alone
Modules
1073 Module
1084 module
19" Rack Mounting
2 Module Version
8 Module Version
*Fully populated rack

Power Requirements

Rack Units
Rated Volt age
Rated Frequency
Rated Cur rent
Primary Protection Fuse:
Operating Voltage
Fuse Rating and Type
Location
Secondary Protection Fuse:
Output Voltage
Fuse Rating and Type
Location
Output Voltage
Fuse Rating and Type
Location
1073 Module
1084 Module
Width
mm (inches)
45 (1.8)
45 (1.8)
U
3
5
100- 230V AC
50- 60 Hz
0.5A Max
100- 230V AC
T0.5A H 250V
20mm x 5mm CERAMIC
IEC Mains connector
Modules
Height
mm (inches)
222 (8.75)
222 (8.75)
Depth
mm (inches)
405 (16)
405 (16)
3U
106mA ±10mA at 24V DC. Negative Earth
106mA ±10mA at 24V DC. Negative Earth
- 5 -
Depth Approx. Weight
mm (inches)
254 (10)
254 (10)
Height Approx. Weight
mm (inches)
133 (5.25
222 (8.75)
5U
100- 230V AC
50- 60Hz
0.8A Max
100- 230V AC
T1A H 250V
20mm x 5mm CE RAMIC
IEC Mains connector
24V DC
T2.0A L 250V
20mm x 5mm GLASS
F1
48V DC
T 250mA L 250V
20mm x 5mm GLASS
F2
Power
kg (lbs)
2.5 (5.5)
2.5 (5.5)
kg (lbs)
11 (24.2)*
30 (66)*
