Power Supply - Icom F6000 Configuration Manual

• Expandable - Add Additional
Modules to Increase Current
Capacity - Redundancy
• Auto Battery Back-Up Capable-
Charges External Batteries
• 2 RU Rack Occupancy
- Saves Rack Space
• Alarm and Status
Operational Outputs

POWER SUPPLY

The FR5000 series requires 13.6 VDC and 15 amps
vides two external rack mountable power supplies for you to choose from.
The ICT N+1 Redundant Series
The N+1 system offers true redundancy. Its built-in active current shar-
ing capability ensures that load current is distributed to approximately
5% among the modules and the ORing diode prevents any interruption
to the DC bus. The outcome is a highly reliable and efficient power supply
system. Standalone power supplies can be placed in parallel in order to
increase the output power to be equivalent to that of an N+1 system but
with the following drawbacks; external wiring is required, no active current
sharing would be present and the DC output will be pulled down if any of
the standalone units fail.
ICT 22012-35N: One Module Power Supply - Rack Mountable
Retail: $ 1199.00
ICT 22012-70N: Two Module Power Supply - Rack Mountable
Retail: $ 1587.00
ICT 22012-30N: Internal Module - Mounts Inside ICT Chassis
Retail: $ 388.00
(One Module)
FR5000 / FR6000 Configuration Guide / 6
. IAS pro-
