Procedure: Print Test Tickets; Figure 9-7 Commwrangler - Print Test Tickets - FutureLogic GEN3 Evolution Operator's Manual

Procedure: Print Test Tickets

The installation process copies a set of test tickets into the CommWrangler program folder.
2
4
5
1. Click Open File.
The Select File Type area displays.
2. Select Normal.
a. From the window that displays, browse to the CommWrangler program folder.
b. Select one of the .TKT ticket files (for example, ticket0.tkt).
3. Click File.
The printer prints a standard TITO ticket.
4. For test bench soak-testing, enter the following in the Repeat File To Printer fields:
·
First text box: enter the number of times to repeat the print on the left.
·
Second text box: enter the time in seconds to pause between prints on the right.
5. Click Start Printing to begin the sequence.
ã 2011 – 2014 FutureLogic, Incorporated. All Rights Reserved.
1
3
Figure 9-7 CommWrangler – Print Test Tickets
Operators and Technicians Manual
MNL Page 32 04/10/2014
MNL-000067 REV.X03
