6 Configuration Tickets

Introduction

This chapter provides detail description of the Configuration Tickets.

Overview

The Configuration Tickets allow you to identify the current firmware and parameters of each printer.
There are two configuration tickets available for printing: Standard and Extended.
Firmware version
and build date
Printer serial
number
Comm setup
Print control
parameters
Reserved flash
memory
Library Inventory:
TCL™ templates,
print regions,
graphics, fonts

Print Standard Configuration Ticket

·
Press the FEED button 2 times within 2 seconds.

Print Extended Configuration Ticket

·
Immediately after printing the Standard Configuration Ticket, press twice the FEED button.
ã 2011 – 2014 FutureLogic, Incorporated. All Rights Reserved.
Standard
Figure 6-1 Configuration Tickets
Operators and Technicians Manual
Additional ticket
layout details
Extended
MNL Page 15 04/10/2014
MNL-000067 REV.X03
Additional
firmware build
details
