CHASSIS TIGHTENING TORQUES

Item
Upper bracket pinch bolt
Steering stem nut
Upper handlebar holder bolt
Lower handlebar holder nut
Lower bracket pinch bolt
Lower ring nut
Cap bolt
Cap bolt locknut
Damper rod assembly bolt
Front brake master cylinder
holder bolt
Front brake master cylinder reser-
voir cap screw
Front brake hose union bolt
Front brake hose holder bolt
Front brake hose bracket and
front brake hose bolt
Left rear view mirror (FZ8NA)
Right rear view mirror (FZ8NA)
Grip end and handlebar bolt
Horn bolt
Lower headlight stay and lower
bracket bolt (FZ8NA)
Lower headlight stay and brake
hose nut (FZ8NA)
Lower headlight stay and brake
hose bolt (FZ8NA)
Upper headlight stay and upper
bracket bolt (FZ8NA)
Cable holder and upper bracket
bolt (FZ8SA)
Horn bracket and under bracket
bolt (FZ8SA)
Horn bracket and brake hose nut
(FZ8SA)
Horn bracket and brake hose bolt
(FZ8SA)
Cowling stay bolt (FZ8SA)
Rear view mirror nut (FZ8SA)
Cowling bracket bolt (FZ8SA)
Front fender bolt
Clutch lever holder pinch bolt
Right front engine mounting bolt 1
Thread
Q'ty
size
M8 2 26 Nm (2.6 m·kgf, 19 ft·lbf)
M28 1 115 Nm (11.5 m·kgf, 83 ft·lbf)
M8 4 24 Nm (2.4 m·kgf, 17 ft·lbf)
M10 2 32 Nm (3.2 m·kgf, 23 ft·lbf)
M8 4 23 Nm (2.3 m·kgf, 17 ft·lbf)
M30 1
M46 2 23 Nm (2.3 m·kgf, 17 ft·lbf)
M10 2 15 Nm (1.5 m·kgf, 11 ft·lbf)
M10 2 23 Nm (2.3 m·kgf, 17 ft·lbf)
M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M4 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M10 5 30 Nm (3.0 m·kgf, 22 ft·lbf)
M6 1 6 Nm (0.6 m·kgf, 4.3 ft·lbf)
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M10 1 17 Nm (1.7 m·kgf, 12 ft·lbf)
M10 1 17 Nm (1.7 m·kgf, 12 ft·lbf)
M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M8 2 33 Nm (3.3 m·kgf, 24 ft·lbf)
M6 4 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
M6 5 6 Nm (0.6 m·kgf, 4.3 ft·lbf)
M6 1 11 Nm (1.1 m·kgf, 8.0 ft·lbf)
M10 1 45 Nm (4.5 m·kgf, 33 ft·lbf)
