Electrical Specifications - Yamaha FZ8NA Service Manual

EAS20310

ELECTRICAL SPECIFICATIONS

Voltage
System voltage
Ignition system
Ignition system
Ignition timing (B.T.D.C.)
Engine control unit
Model/manufacturer
Ignition coil
Minimum ignition spark gap
Primary coil resistance
Secondary coil resistance
AC magneto
Standard output
Stator coil resistance
Rectifier/regulator
Regulator type
Rectifier/regulator output voltage
Rectifier capacity
Battery
Model
Voltage, capacity
Specific gravity
Manufacturer
Ten hour rate amperage
Headlight
Bulb type
Bulb voltage, wattage × quantity
Headlight
Auxiliary light
Tail/brake light
Front turn signal light
Rear turn signal light
License plate light
Indicator light
Neutral indicator light
Turn signal indicator light
Oil level warning light
High beam indicator light
Coolant temperature warning light
Engine trouble warning light
ABS warning light
Immobilizer system indicator light
ELECTRICAL SPECIFICATIONS
12 V
TCI
5.0°/1200 r/min
TBDFD1/DENSO
6.0 mm (0.24 in)
1.19–1.61 Ω
8.50–11.50 kΩ
14.0 V, 40.0 A at 6500 r/min
0.153–0.187 Ω at 20 °C (68 °F) (W–W)
Semi conductor-short circuit
14.2–14.8 V
50.0 A
YTZ10S
12 V, 8.6 Ah
1.310
GS YUASA
0.86 A
Halogen bulb
12 V, 60 W/55 W × 1
FZ8SA 12 V, 55 W × 1
FZ8NA 12 V, 5.0 W × 1
FZ8SA 12 V, 5.0 W × 2
12 V, 5.0 W/21.0 W × 1
12 V, 10.0 W × 2
12 V, 10.0 W × 2
12 V, 5.0 W × 1
LED
LED
LED
LED
LED
LED
LED
LED
