EAS30380

BASIC SERVICE INFORMATION

EAS30390

QUICK FASTENERS

Rivet type

1. Remove:
• Quick fastener
TIP
To remove the quick fastener, push its pin with
a screwdriver, then pull the fastener out.
2. Install:
• Quick fastener
TIP
To install the quick fastener, push its pin so that
it protrudes from the fastener head, then insert
the fastener into the part to be secured and
push the pin "a" in with a screwdriver. Make
sure that the pin is flush with the fastener's
head.
BASIC SERVICE INFORMATION
Screw type
1. Remove:
• Quick fastener
TIP
To remove the quick fastener, loosen the screw
with a screwdriver, then pull the fastener out.
2. Install:
• Quick fastener
TIP
To install the quick fastener, insert the fastener
into the part to be secured and tighten the
screw "a".
EAS30401

ELECTRICAL SYSTEM

Electrical parts handling
ECA16600
Never disconnect a battery lead while the
engine is running; otherwise, the electrical
components could be damaged.
1-28
