Creating Presets

The OPS300 allows the creation of user defined presets very easily. Any setup you have configured on
screen, can be stored into one of the 4 available user presets.
1. After having configured Layers, PIP transitions, logos... on your screen (see 'Working with the OPS300'),
go to the Preset menu by pressing the
Then, press the
corresponding knob, and press the
2. In the sub-menu, choose Save From Main or Save From Preview to determine which screen you want to
memorize the preset from, then set the preset memory (#1 to #4) you wish to use as your "User Preset"
(by default, the
3. By pressing the
as a preset.
In Mixer Mode: In the preset Menu, some already existing preset are available in the preset layout menu.
Choose your layout with associated PIPs and TAKE it to the main to see the result.
You can at any time memorize those presets in one of the preset memory buttons.

Working with Presets

The four user presets of the
1. Press the [PRESET]
memory (#1 to #4) you wish to use. The preset will be displayed on your preview screen.
2. Once you have selected your preset, simply press the
screen.

Working with Audio

The OPS300 allows to work with up to 10 stereo inputs, 1 auxiliary input, and 2 stereo embedded SDI audio
inputs (via the SDI BNC connectors), all accessible via the Audio menu of the OPS300, and which can be
assigned to one or both of the 2 independant symetrical/asymetrical outputs of the device.

Working with Preset Layouts

On the OPS300, a list of pre-saved preset layouts can be recalled at any time:
1. Go in the "Preset Menu" and choose "Preset Layouts"
2. Now you have access to a list of 12 layouts. Select the desired pattern and press OK to apply this
pattern to your current preview.
3. Press [TAKE]
40
[EXIT/MENU]
[ENTER] button to enter the Preset sub-menu. Choose Preset Copy by scrolling with the
[ENTER]
OPS300 will choose the next available preset in the
OPS300
[ENTER] button, the
OPS300 can be recalled at any stage during your show or event.
button, then press one of the four first Input Selection section buttons to choose which
to see the result on the main output.
button, and select Preset by rotating the scroll knob.
button to access the sub-menu.
OPS300
will ask you to confirm. Select Yes, your screen is memorized
[TAKE] button to view the result on your main
memory).
