INTRODUCTION

1-1. THE OPS300 OPERATING MODES
Before you start setting up your
OPS300
it. The offers a choice of two operating modes, which results in a versatile video production tool for
live event staging and fixed installation applications.
* NOTE * : We recommend resetting the device to its default values every time you set up your shows or
events (see the "Operating The OPS300" chapter, p25).

MIXER MODE

This mode allows for a single
any other of the inputs, add PIP, titling or logo insertion to the live frame, while previewing your every move
before going live, to avoid embarrassing errors on your main screen. The Mixer mode is the
mode, and with no less than 6 layers (of which 3 live layers). The
have a full Main screen for recording or broadcasting.

MATRIX MODE

This mode turns your
Output #1 and #2 can be set to different resolutions and rates. Switching between any of the inputs can be
done with the various effects (Cut, Fade, Slides...) and synchronized on both outputs.
* NOTE * This mode leads the following restrictions: no PIPs, no logos and no frames.
4
OPS300
for the first time, be sure you know what you actually want to do with
OPS300 to seamlessly switch and blend any of its 12 analog/digital inputs with
OPS300 into a true 12x2 scaled matrix, while preserving seamless switching capabilities.
OPS300 with the Video output allows to
OPS300 native
